Omron D4NS Quick Start Manual page 11

D4NS-1@F + D4DS-K3
(with Front-inserted Operation Key)
45 to 47.5
Operation key
Red
insertion position
Black
45 to 47.5
Operation key
insertion position
D4NS-1@F + D4DS-K5
(with Front-inserted Operation Key)
Red
Black
Horizontal key
insertion radius
R ≥ 50 *
51.9 to 54.4
Operation key
insertion position
Note: Unless otherwise specified, a tolerance of ±0.4 mm applies to all dimensions.
* Insertion radii apply when the rotational center of the Operation Key is in line with a line extending from the front or top Head surface.
Horizontal key
insertion radius
R ≥ 50 *
(30.6)
(40 )
±0.15
Permissible difference
in center lines between
the Operation Key and
key hole is ±1.
(30.6)
Vertical key
insertion radius
R ≥ 200 *
(33.5)
Permissible difference
in center lines between
the Operation Key and
key hole is ±1.
51.9 to 54.4
Operation key
insertion position
(30.6)
(43 )
±0.1
(41 ±0.1 )
Permissible difference
in center lines between
the Operation Key and
key hole is ±1.
(30.6)
Vertical key
insertion radius
R ≥ 50 *
(33.5)
Permissible difference
in center lines between
the Operation Key and
key hole is ±1.
D4NS-1@F + D4DS-K3
(with Top-inserted Operation Key)
Red
55.5 to 58.0
Operation key
Black
insertion position
The permissible difference
in center lines between
the Operation Key
and key hole is ±1.
D4NS-1@F + D4DS-K5
(with Top-inserted Operation Key)
Red
62.4 to 64.9
Operation key
insertion position
Black
The permissible difference
in center lines between
the Operation Key
and key hole is ±1.
Horizontal key insertion
radius R ≥ 50 *
D4NS/D4NS-SK
Horizontal key insertion
radius R ≥ 50 *
40
(41)
Horizontal key insertion
radius R ≥ 200 *
(8)
55.5 to 58.0
Operation key
(41)
insertion position
The permissible difference
in center lines between
the Operation Key
and key hole is ±1.
43 ± 0.1
41 ± 0.1
Horizontal key insertion
(41)
radius R ≥ 50 *
(8)
62.4 to 64.9
Operation key
insertion position
(41)
The permissible difference
in center lines between
the Operation Key
and key hole is ±1.
11
