Omron D4NS Quick Start Manual page 10

With Operation Key Inserted (Relationship between Insertion Radius, Operation Key and Key Hole)
D4NS-1@F + D4DS-K1
(with Front-inserted Operation Key)
44 to 46.5
Operation key
insertion position
Red
Black
44 to 46.5
Operation key
insertion position
D4NS-1@F + D4DS-K2
(with Front-inserted Operation Key)
40 to 42.5
Operation key
insertion position
Red
Black
40 to 42.5
Operation key
insertion position
Note: Unless otherwise specified, a tolerance of ±0.4 mm applies to all dimensions.
* Insertion radii apply when the rotational center of the Operation Key is in line with a line extending from the front or top Head surface.
Horizontal key
insertion radius
(30.6)
R ≥ 200 *
(15)
Permissible difference
in center lines between
the Operation Key and
key hole is ±1.
(30.6)
Vertical key
insertion radius
R ≥ 200 *
(33.5)
Permissible difference
in center lines between
the Operation Key and
key hole is ±1.
Horizontal key
insertion radius
(30.6)
R ≥ 200 *
(15)
Permissible difference
in center lines between
the Operation Key and
key hole is ±1.
(30.6)
Vertical key
insertion radius
R ≥ 200 *
(33.5)
(27.5)
Permissible difference
in center lines between
the Operation Key and
key hole is ±1.
D4NS-1@F + D4DS-K1
(with Top-inserted Operation Key)
Red
Black
D4NS-1@F + D4DS-K2
(with Top-inserted Operation Key)
Red
Black
(6)
D4NS/D4NS-SK
Horizontal key insertion
radius R ≥ 200 *
(15)
54.5 to 57.0
Operation key
(41) insertion position
The permissible difference
in center lines between
the Operation Key
and key hole is ±1.
Vertical key insertion
radius R ≥ 200 *
(8)
54.5 to 57.0
Operation key
(41)
insertion position
The permissible difference
in center lines between
the Operation Key
and key hole is ±1.
Horizontal key insertion
radius R ≥ 200 *
(15)
50.5 to 53.0
Operation key
(41)
insertion position
The permissible difference
in center lines between
the Operation Key
and key hole is ±1.
Vertical key insertion
radius R ≥ 200 *
(8)
50.5 to 53.0
Operation key
(41)
insertion position
The permissible difference
in center lines between
the Operation Key
and key hole is ±1.
10
