- Page 1 ACC-MBCR1 300 lb (136 kg) 2021-03-15 #:126-9259-1...
- Page 2 WARNING ENG - Before installing make sure the supporting surface will support the combined load of the equipment and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail. Never exceed the Maximum Load Capacity. Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
- Page 3 Parts (Before beginning, make sure you have all parts shown below). Parts List Description Part # connector tube 10002743-RBLK support bracket 10002758-RBLK 1/4-20 x 3/4" hex head screw 520-1321 1/4-20 x 1/2" phillips screw 510-9108 A (2) B (4) connector tube support bracket C (36) D (2)
- Page 4 3/8" C (12) (10mm) B (4) ENG Sold separately. A (2) 3/8" (10mm) C (12) 2021-03-15 #:126-9259-1...
- Page 5 7/16" (11mm) ENG Loosen, adjust, tighten. ENG Sold separately. 2021-03-15 #:126-9259-1...
- Page 6 ENG Sold separately. ENG Sold separately. ENG M5 x 10mm socket pin screw (sold separately). ENG #10 x 1/2" phillips screw (sold separately). 2021-03-15 #:126-9259-1...
- Page 7 DS-MBZ942L-2X1 4a-1 DS-MBZ942L-2X1 and ACC-MB0800 4b-1 DS-MBZ947L-2X1 4c-1 DS-MBZ947L-2X1 and ACC-MB0800 4d-1 2021-03-15 #:126-9259-1...
- Page 8 4a-1 4a-2 3/8" (10mm) ENG 1/4-20 x 3/4" hex head screw (sold separately). 2021-03-15 #:126-9259-1...
- Page 9 4b-1 D (2) ENG Sold separately. 4b-2 3/8" (10mm) ENG 1/4-20 x 3/4" hex head screw (sold separately). 2021-03-15 #:126-9259-1...
- Page 10 4c-1 4c-2 3/8" (10mm) ENG 1/4-20 x 3/4" hex head screw (sold separately). 2021-03-15 #:126-9259-1...
- Page 11 4d-1 D (2) ENG Sold separately. 4d-2 3/8" (10mm) ENG 1/4-20 x 3/4" hex head screw (sold separately). 2021-03-15 #:126-9259-1...
- Page 12 Garantia TÜR Garanti̇ Garanzia Záruka www.peerless-av.com/warranty Peerless-AV Peerless-AV Europe Peerless-AV América Latina 2300 White Oak Circle Unit 3 Watford Interchange, Av. de las Industrias 413 Aurora, IL 60502 Colonial Way, Watford, Herts, Parque Industrial Escobedo Email: tech@peerlessmounts.com WD24 4WP, United Kingdom General Escobedo N.L., México 66062...
