- Page 1 ACC-V1500X For VESA 1200 and 1500 Mounting Patterns 200 lb (91 kg) 2022-03-07 #:120-9246-1...
- Page 2 WARNING ENG - Before installing make sure the supporting surface will support the combined load of the equipment and hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail. Never exceed the Maximum Load Capacity. Always use an assistant or mechanical lifting equipment to safely lift and position equipment.
-
Page 3: Parts List
Parts (Before beginning, make sure you have all parts shown below). Parts List Description Part # A adaptor rail 10009122RBLK B M8 x 15mm 520-1068 C 4mm allen wrench 560-9646 D M8 x 20mm 520-1120 E tube cap 590-1334 A ( 2 ) adaptor rail B (4) D (4) - Page 4 A (2) E (4) VESA 1500mm VESA 1200mm 2022-03-07 #:120-9246-1...
- Page 5 A (2) D (4) A (2) D (4) 2022-03-07 #:120-9246-1...
- Page 6 SF680P DS-VW795-QR SR598 M6/M8 washer (included with SF680P) B (4) 2022-03-07 #:120-9246-1...
- Page 7 B (4) B (4) 2022-03-07 #:120-9246-1...
- Page 8 Garantia TÜR Garanti̇ Garanzia Záruka www.peerless-av.com/warranty Peerless-AV Peerless-AV Europe Peerless-AV América Latina 2300 White Oak Circle Unit 3 Watford Interchange, Av. de las Industrias 413 Aurora, IL 60502 Colonial Way, Watford, Herts, Parque Industrial Escobedo Email: tech@peerlessmounts.com WD24 4WP, United Kingdom General Escobedo N.L., México 66062...
