ATTACH GIMBAL

STEP 1: Ensure marks on the top & bottom parts of the gimbal are aligned.
STEP 2:
The mark on the ring should be aligned with the unlocked icon
shown in the first image (below).
STEP 3: Attach the bottom part to the top part (keep arrows aligned).
STEP 4:
Rotate the ring clockwise until the mark on the ring aligns with
the lock icon.
STEP 2 STEP 3 STEP 4
