Appendix L - Technical Specifications And Safety Information; Pinouts For Auxiliary Port Modem Cable - Netopia R3100-U User Reference Manual

Isdn routers
Hide thumbs Also See for R3100-U:
Table of Contents

Advertisement

Pinouts for Auxiliary Port Modem Cable

Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
HD-15
Ground
TDA
TDB
RDA
RDB
(not used)
DTR
CTS
Technical Specifications and Safety Information L-1
DB-25
Pin 1
(not used)
Pin 2
TD
Pin 3
RD
Pin 4
RTS
Pin 5
CTS
Pin 6
DCE Ready
Pin 7
Ground
Pin 8
RLSD
