Data sheet | APP W HC 15 -30
11. Dimensions with motor
unit
IEC 280-315: 265 [10.433]
APP W HC 15-24: 351 [13.833]
APP W HC 15-24: 304 [11.97]
30

11.1 APP W HC 15 -30

The examples of assemblies with motor are only
for IEC motors and couplings . Please make sure
to check required motor power and dimensions
when selecting size of pump and motor . For ad-
vice and calculation tool, please contact Danfoss .
A mm
Pump
(inch)
550
APP W HC 15
(21 .65)
550
APP W HC 21
(21 .65)
660
APP W HC 24/30
(25 . 9 8)
180R9410 | AQ282628894589en-000801 | IOM APP W HC 15-30 Pumps | 01.2022
B mm C mm D mm E mm
(inch) (inch) (inch) (inch)
693 280 457
(27 .28) (11 .02) (17 . 9 9) (14 .49)
693 280 457
(27 .28) (11 .02) (17 . 9 9) (16 .50)
861 315 508
(33 . 9 0) (12 .40) (20 .00) (15 . 9 8)
F mm
IEC Electric motor
(inch)
368 845
75 kW, IEC 280S-4
(33 .37)
419 895
90 kW, IEC 280M-4
(35 .24)
406 1038
110 kW, IEC 315S-4
(40 .87)
