8. Temperature and
corrosion
9.

Installation

26

8.1 Temperature

Fluid temperature:
Min . +2°C to max . +50°C
(Min . +35 .6°F to max . +122°F)
Ambient temperature:
Min . +2°C to max . +50°C
(Min . +35 .6°F to max . +122°F)
In case of lower operating temperatures, please
contact Danfoss High Pressure Pumps .
8.2 Corrosion
80 º
C
70
60
50
316L
40
30
20
1000
100
160 1600
See example below on how to mount the pump
and connect it to an electric motor or combus-
tion engine (special coupling) .
A: Pump
B: Bell housing
C: Flexible coupling
D: Motor shaft
E: Motor
A
C
180R9410 | AQ282628894589en-000801 | IOM APP W HC 15-30 Pumps | 01.2022
in order to minimize the risk of crevice corrosion .
The chart below illustrates the corrosive
resistance of different types of stainless steel
related to NaCl concentration and temperature .
The APP water pump is made of Duplex and
Super Duplex .
If the water pump is operated above the Duplex
line, always flush water pump with fresh water at
operation stop in order to minimize the risk of
crevice corrosion .
Duplex
Super Duplex
10 000
16000
If alternative mounting is required . please
contact your Danfoss sales representative for
further information .
Note: Do not add any axial or radial loads to the
pump shaft.
B
D E
NaCI vs . temperature
CI -
100 000
ppm
NaCI
160000
ppm
