GigE Vision
Monochrome Dual Lines CMOS Line Scanning
PoE Camera
FS-B4KU7DGES-F
FS-B4KU7DGES-M42
FS-B2KU7DGES-F
FS-B2KU7DGES-M42
FS-B2KU7DGES-C
Product Specifications and User's Guide
FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C
Product Specifications and Use's Guide
(4k Monochrome Dual lines 7.0 µm pixel size, F Mount)
(4k Monochrome Dual lines 7.0 µm pixel size, M42 Mount)
(2k Monochrome Dual lines 7.0 µm pixel size, F Mount)
(2k Monochrome Dual lines 7.0 µm pixel size, M42 Mount)
(2k Monochrome Dual lines 7.0 µm pixel size, C Mount)
No.20S048-00
1/62
Advertisement
Table of Contents
Related Manuals for Omron FS-B4KU7DGES-F
Summary of Contents for Omron FS-B4KU7DGES-F
- Page 1 (2k Monochrome Dual lines 7.0 µm pixel size, M42 Mount) FS-B2KU7DGES-C (2k Monochrome Dual lines 7.0 µm pixel size, C Mount) Product Specifications and User’s Guide FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 1/62 Product Specifications and Use’s Guide...
-
Page 2: Table Of Contents
Timing of edge preset trigger mode (Trigger input while exposing or image is out) ......... 29 Camera Functions ..............................30 10.1 Save and load the camera settings .......................... 30 FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 2/62 Product Specifications and Use’s Guide... - Page 3 FileAccessControl ..............................56 11.14 ChunkDataControl ..............................57 11.15 TestControl ................................57 11.16 TransportLayerControl ............................58 11.17 Flat Field Correction Control ..........................60 Revision History ................................. 61 FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 3/62 Product Specifications and Use’s Guide...
- Page 4 Do not wrong wiring. that is specified in the specifications for this This will cause of fire or malfunction. camera. This will cause of fire, electrification or malfunction. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 4/62 Product Specifications and Use’s Guide...
- Page 5 It is turn off the camera when maintaining or This will cause of fire, electrification or inspecting the camera. malfunction. This will cause of electrification. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 5/62 Product Specifications and Use’s Guide...
- Page 6 No.20S048-00 [Disposal] Caution It is necessary to dispose as industrial waste. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 6/62 Product Specifications and Use’s Guide...
-
Page 7: Product Precautions
Exchange or repair the malfunction camera if the malfunction is occurred by our responsibility. “Warranty” mean is warranty for the delivered camera itself. Please accept the induction damage by the camera malfunction is not included. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 7/62 Product Specifications and Use’s Guide... -
Page 8: Software Licensing
CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 8/62 Product Specifications and Use’s Guide... -
Page 9: Introduction
GES: GigE Vision Camera Cell size (Pixel size) U7D: 7.0 (H) x 7.0 (V) µm, Dual lines Resolution 4K: 4k pixels 2K: 2k pixels B: Monochrome FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 9/62 Product Specifications and Use’s Guide... -
Page 10: Specifications
Power Over Ethernet (IEEE802.3af) Consumption +12 V / +24 V: 5.9 W, +12 V / +24 V: 4.8 W, PoE: 6.5 W PoE: 5.3 W Default: Bold FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 10/62 Product Specifications and Use’s Guide... -
Page 11: Quantum Efficiency
(*4) The camera operates with external power when power suppling by external power supply and PoE to camera at same time. Quantum Efficiency FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 11/62 Product Specifications and Use’s Guide... -
Page 12: Mechanical Specifications
Camera Mounting Twenty M4 screw holes (Four on front, top, bottom and both side plates) Weight 290 g 210 g 240 g (*1) Excluding the connectors FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 12/62 Product Specifications and Use’s Guide... -
Page 13: Environmental Specifications
If the camera has a mounted lens and a tripod with an aluminum plate, this could decrease the camera housing temperature for the heat dissipation. Temperature measuring point FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 13/62 Product Specifications and Use’s Guide... -
Page 14: Connector Specifications
Please use 1Gbps supported Network card (NIC), Network Switcher and LAN cable. Check the setting of NIC and Network Switcher being used is “1 Gbps transferring”. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 14/62 Product Specifications and Use’s Guide... -
Page 15: Power Supply Connector
TTL / RS-422 INPUT 3+ (Line2) TTL / RS-422 POWER +10.8 to +26.4 Vdc OUTPUT 2- (Line4) TTL / RS-422 OUTPUT 2+ (Line4) TTL / RS-422 FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 15/62 Product Specifications and Use’s Guide... - Page 16 “High” state of signal is out when camera is line trigger wait condition. 6) Line Trigger The input line trigger signal with trigger delay (camera internal process delay). FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 16/62 Product Specifications and Use’s Guide...
- Page 17 “HIGH” state signal is output when frame does not finish after Frame Timeout is passed. 21) Action 0 Selected signal at “Action Control” is out. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 17/62 Product Specifications and Use’s Guide...
-
Page 18: Input Signal Circuit
2854 8.2kΩ 12Pin Connector Input TTL signal Camera Internal +3.3V Not Connected 10kΩ Input0- To Internal Circuit Input Signal Input0+ 2854 8.2kΩ 12Pin Connector FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 18/62 Product Specifications and Use’s Guide... -
Page 19: Output Signal Circuit
From Internal Circuit Output0+ 2854 8.2kΩ Output TTL signal Camera Internal +3.3V 12Pin Connector Not Connected 10kΩ Output0- From Internal Circuit Output Signal Output0+ 2854 8.2kΩ FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 19/62 Product Specifications and Use’s Guide... -
Page 20: Input And Output Signal Timing (Hardware Trigger)
Parameter “ ExposureTime ” on GenICam Image out FrameTriggerWait ExposureActive DebounceLine3, 4 FramTriggerInternal SensorReadOut Timer0, 1 Parameter “ TimerDelay ” on GenICam Parameter “ TimerDuration ” on GenICam FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 20/62 Product Specifications and Use’s Guide... -
Page 21: Input And Output Signal Timing (Software Trigger)
Parameter “ ExposureTime ” on GenICam Image out Output signals FrameTriggerWait ExposureActive FramTriggerInternal SensorReadOut Timer0, 1 Paramter “ TimerDelay ” on GenICam Parameter “ TimerDuration ” on GenICam FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 21/62 Product Specifications and Use’s Guide... -
Page 22: Dimensions
No.20S048-00 Dimensions FS-B4KU7DGES-F / FS-B2KU7DGES-F Unit: mm FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 22/62 Product Specifications and Use’s Guide... -
Page 23: Fs-B4Ku7Dges-M42 / Fs-B2Ku7Dges-M42
No.20S048-00 FS-B4KU7DGES-M42 / FS-B2KU7DGES-M42 Unit: mm FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 23/62 Product Specifications and Use’s Guide... -
Page 24: Fs-B2Ku7Dges-C
No.20S048-00 FS-B2KU7DGES-C 44.6 35.1 C Mount 4-M4 depth4 (Top, bottom and both side) 4-M4 depth5 Unit: mm FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 24/62 Product Specifications and Use’s Guide... -
Page 25: Image Output Mode
Line1 (Upper line) First, Horizontal Flip = Off 1 (On) 0 (Off) Line2 (Lower line) First, Horizontal Flip = On 1 (On) 1 (On) Line1 (Upper line) First, Horizontal Flip = On FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 25/62 Product Specifications and Use’s Guide... -
Page 26: Camera Operational Modes
Line N-1 Line N Line N Image out * The exposure time for each line is same. * Number of line is “Height” on GenICam setting. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 26/62 Product Specifications and Use’s Guide... -
Page 27: Pulse Width Trigger Mode
When selecting “FrameStart” at TiggerSelector, exposure time of each line is same for one frame (lines of height setting) Timing of pulse width trigger mode Trigger signal (Positive polarity) Line 1 Line 2 Expose Line N-1 Line N Image out FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 27/62 Product Specifications and Use’s Guide... -
Page 28: Edge Preset Trigger Mode
When selecting “FrameStart” at TiggerSelector, exposure time of each line is same for one frame (lines of height setting) Timing of edge preset trigger mode Trigger signal (Positive polarity) Line 1 Line 2 Expose Line N-1 Line N Image out FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 28/62 Product Specifications and Use’s Guide... -
Page 29: Edge Preset Trigger Mode (Trigger Input While Exposing Or Image Is Out)
Timing of edge preset trigger mode (Trigger input while exposing or image is out) Trigger Signal (Positive polarity) Expose Image out *Note: The exposure time is preset “ExposureTime” on GenICam setting. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 29/62 Product Specifications and Use’s Guide... -
Page 30: 10 Camera Functions
Settings “UserSetSelector”. Caution: Default Selector “UserSetSave” CANNOT execute when “Default” was selected at “UserSetSelector” UserSetSelector Setting Procedure 1. Selects “UserSetX” at “UserSetSelector” 2. Execute “UserSetSave” FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 30/62 Product Specifications and Use’s Guide... -
Page 31: Loading Camera Settings
Please follow the procedure in below for camera settings put back to factory default settings. Setting Procedure Selects “Default” at “UserSetSelector”. Executes “UserSetLoad”. Select “UserSetX” at “UserSetSelector”. Executes “UserSetSave”. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 31/62 Product Specifications and Use’s Guide... -
Page 32: Frame Rate
Default: 74.764706 (FS-B4KU7DGES-F / FS-B4KU7DGES-M42) 36.305882 (FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C) (*1) The longest exposure time will be change with AcquisitionLineRate and Pixel Format selection. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 32/62 Product Specifications and Use’s Guide... -
Page 33: Gain
IBoolean Type Vertical flip image ON / OFF selection Selection: “False” (Vertical flip is Off), “True” (Vertical flip is On) Default: “False” (Vertical flip is Off) FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 33/62 Product Specifications and Use’s Guide... -
Page 34: Roi (Region Of Interest)
0 to 2,040 pixels (FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C) Default: 0 pixels Adjustable steps: 8 The ROI region settings are below: Height ROI region OffsetX Width FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 34/62 Product Specifications and Use’s Guide... -
Page 35: Pixel Format
Selects vertical binning mode. Type Sum: summing Average: averaging BinningVertical IInteger Type Sets binning on vertical direction Selection: 1: Disable Binning, 2: x2 Binning Default: Disable Binning FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 35/62 Product Specifications and Use’s Guide... -
Page 36: Decimation
GenICam Parameters DecimationVertical IInteger Type Sets decimation on vertical direction 1: Disable Decimation (Dual lines output), 2: Decimate one of two pixels (Single line output) FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 36/62 Product Specifications and Use’s Guide... -
Page 37: Trigger
Software Signal 0 Software Signal 1 Sensor Logic Block 0 又は Trigger Source The trigger signal is selectable by GenICam commands. TriggerSource: select trigger type FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 37/62 Product Specifications and Use’s Guide... -
Page 38: Flat Field Correction Control
When camera powering on, selected FFC Set data is applying as FFC data. Selection: Default and FFCSet0 to FFCSet7 * Please use “UserSetSave” to save FFCSetDefault setting. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 38/62 Product Specifications and Use’s Guide... -
Page 39: Ffc Procedure
FFCGainMode after proceeding FFC function. *Note4: It is necessary to proceeding FFC function when changing lens, light source or camera settings (AnalogGain, ExposureMode or TriggerMode of LineStart trigger) FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 39/62 Product Specifications and Use’s Guide... -
Page 40: Digital Io Control
IEnumeration Selects UserOuput that applying UserOutputValue Type Selection: UserOutput3, UserOutput4 Default: UserOutput3 UserOutputValue IBoolean Type Sets condition for UserOutput signal Selection: False, True Default: False FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 40/62 Product Specifications and Use’s Guide... -
Page 41: Counter And Timer Control
Selection: RisingEdge, FallingEdge Default: RisingEdge CounterReset ICommand Type Reset switch Activate as switch when selecting “Software” at “CounterResetSource” CounterValue IInteger Type Returns number of counter FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 41/62 Product Specifications and Use’s Guide... -
Page 42: Encoder Control
IInteger Reads or sets current position counter for Rotary Encoder Type EncoderValueAtReset IInteger Read the value of the position counter when reset Rotary Encoder Type FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 42/62 Product Specifications and Use’s Guide... -
Page 43: Logic Block Control
Line0, Line1, Line2 Default: True LogicBlockInputInverter IEnumeration Inverts polarity of input signal that selected at LogicBlockInputSelector Type Selection: False (no invert), True (invert) Default: False FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 43/62 Product Specifications and Use’s Guide... -
Page 44: E.g. Event Control
BlockDiscard, ActionLate, AcquisitionTriggerMissed, FrameTriggerMissed, LineTriggerMissed, FrameTimeout, OverrunEvent Event Notification IEnumeration Event notification ON / OFF selection Type On: Enable event notification Off: Disable event notification FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 44/62 Product Specifications and Use’s Guide... -
Page 45: Chunk Control
Select camera to apply action command Logical AND of Group Mask of camera and Group Mask of action command is 1 for any bit of 32bits, camera executes action command. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 45/62 Product Specifications and Use’s Guide... -
Page 46: Ieee1588
If time difference between master device and slave device is occurred, adjust internal clock of slave device to synchronize to master device. Synchronize clock regularly to correcting time drift. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 46/62 Product Specifications and Use’s Guide... - Page 47 Action Control setting is required when action command generating. IEEE1588 PTP supported Switching HUB M: Master S: Slave e.g. PTP configuration FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 47/62 Product Specifications and Use’s Guide...
-
Page 48: 11 Genicam Command List
DeviceTLVersionSubMinor Sub minor version of the Transport Layer of the device. DeviceMaxThroughput Maximum bandwidth of the data that can be streamed out of the device. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 48/62 Product Specifications and Use’s Guide... - Page 49 Latches the current timestamp counter into Timestamp Latch Value. TimestampLatchValue Returns the latched value of the timestamp counter. DeviceUserMemory Read / Write the user data from / to the non-volatile memory. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 49/62 Product Specifications and Use’s Guide...
-
Page 50: Imageformatcontrol
Selects which test pattern generator is controlled by the Test Pattern feature. TestPattern [TestPatternGeneratorSelector] Selects the type of test pattern that is generated by the device as image source. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 50/62 Product Specifications and Use’s Guide... -
Page 51: Acquisitioncontrol
AnalogControl Name Description GainSelector Selects which Gain is controlled by the various Gain features. Gain [GainSelector] Controls the selected gain as an absolute physical value. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 51/62 Product Specifications and Use’s Guide... -
Page 52: Digitaliocontrol
TimerTriggerSource [TimerSelector] Selects the source of the trigger to start the Timer. TimerTriggerActivation [TimerSelector] Selects the activation mode of the trigger to start the Timer. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 52/62 Product Specifications and Use’s Guide... -
Page 53: Encodercontrol
Selects the source signal for the input into the Logic Block. [LogicBlockSelector] [LogicBlockInputSelector] LogicBlockInputInverter Selects if the selected Logic Block Input source signal is inverted. [LogicBlockSelector] [LogicBlockInputSelector] FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 53/62 Product Specifications and Use’s Guide... -
Page 54: Softwaresignalcontrol
ActionGroupKey [ActionSelector] Provides the key that the device will use to validate the action on reception of the action protocol message. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 54/62 Product Specifications and Use’s Guide... -
Page 55: Eventcontrol
Category that contains all the data features related to the Overrun Event. EventTestData Category that contains all the data features related to the Test Event . FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 55/62 Product Specifications and Use’s Guide... -
Page 56: Usersetcontrol
Represents the file operation execution status. [FileSelector] [FileOperationSelector] FileOperationResult Represents the file operation result. [FileSelector] [FileOperationSelector] FileSize [FileSelector] Represents the size of the selected file in bytes. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 56/62 Product Specifications and Use’s Guide... -
Page 57: Chunkdatacontrol
Indicates the value of the temperature when the image was acquired. 11.15 TestControl Name Description TestPendingAck Tests the device's pending acknowledge feature. TestEventGenerate Generates a Test Event. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 57/62 Product Specifications and Use’s Guide... -
Page 58: Transportlayercontrol
Reports the subnet mask of the given logical link. [GevInterfaceSelector] GevCurrentDefaultGateway Reports the default gateway IP address to be used on the given logical [GevInterfaceSelector] link. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 58/62 Product Specifications and Use’s Guide... - Page 59 DeviceStreamChannelPacketSize and should be kept in sync with it. GevSCPD [GevStreamChannelSelector] Controls the delay (in GEV timestamp counter unit) to insert between each frame for this stream channel. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 59/62 Product Specifications and Use’s Guide...
-
Page 60: Flat Field Correction Control
Save the FFC Set specified by FFCSetSelector to the non-volatile memory of the device. FFCSetDefault Selects the feature FFC Set to load and make active by default when the device is reset. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 60/62 Product Specifications and Use’s Guide... -
Page 61: 12 Revision History
GigE Vision is trademark of AIA. GenICam is trademark of EMVA. Other company names and product names in this document are trademarks of their respective owners. FS-B4KU7DGES-F / FS-B4KU7DGES-M42 / FS-B2KU7DGES-F / FS-B2KU7DGES-M42 / FS-B2KU7DGES-C 61/62 Product Specifications and Use’s Guide... - Page 62 OMRON AUTOMATION AMERICAS HEADQUARTERS • Chicago, IL USA • 847.843.7900 • 800.556.6766 • automation.omron.com OMRON CANADA, INC. • HEAD OFFICE OMRON ELETRÔNICA DO BRASIL LTDA • HEAD OFFICE Toronto, ON, Canada • 416.286.6465 • 866.986.6766 • automation.omron.com São Paulo, SP, Brasil • 55 11 5171-8920 • automation.omron.com OMRON ELECTRONICS DE MEXICO •...
