Chapter 4 – Programming the AC 80
Essential Settings for
ACS 600 Standard Drive
4-6
Note that only the user-adjustable settings are represented here.
DRIDS
NAME Max. 20 characters, e.g. dataset_StdDrive
ACT 1
DS_NO Dataset number (1 or 3)
WR_ENA 1 (Must be forced by a connection from the PC section)
DRISTD
Base part:
NAME Max. 20 characters, e.g. STD_DR_OP_MODULEBUS
POSITION 100 + address of the drive. See below.
IMPL 1
TYPE ACS 600 STD
Defining the value of POSITION:
Position on
Setting of drive
Optical
parameter 70.01
ModuleBus
1 17
2 18
3 19
• • • • • •
12 28
Reference part:
REF1 Max. 20 characters, e.g. dataset_Standard_DR
REF2 Max. 20 characters
DRISTD POSITION setting
(100 × Cluster + Position)
101
102
103
• • •
112
