Winegard WPM-300 Quick Start Manual

Winegard Top Mount WPM-300
®
SET-UP
CONTENTS:
• antenna plate
• 2 thumb bolts
• 2 quick threading nuts
For help, send an email to help@winegard.com or call 1-800-788-4417.
For more
product details,
visit Winegard's
website.
Winegard Company
2736 Mt. Pleasant St.
Printed in U.S.A. © 2022 Winegard Company
a
b
c
d
|
Burlington, IA 52601
1
REMOVE 1 front rubber foot and 1 back rubber
foot (diagonally on opposite sides) from DISH
Playmaker or Carryout
®
antenna over antenna plate, aligning openings
from removed feet with holes on antenna plate (b).
2
PLACE one thumb bolt through aligned hole.
Attach 1 quick thread nut to bolt and hand
tighten (c). Repeat on opposite side with
second bolt and nut.
3
Flip top thumb latch of TPLE-15 up and insert
mount. Flip thumb latch down to lock in place (d).
WARNING: INSTALLATION OF THIS PRODUCT
NEAR POWER LINES IS DANGEROUS. Watch out for
overhead power lines. Check distance to power lines before
installing. Stay a minimum of twice the length of the antenna
plus the length of the mast from all power lines. Pole must
be removed prior to vehicle/camper moving. Failure to do
so may cause damage or death. This product is intended to
be used with Winegard Approved product only. Any other
product will void Product Warranty.
Works with Winegard approved products
and accessories. For complete list see
Winegard website.
products will void Product Warranty.
Quick Start Guide
®
G3 antenna (a). Place
®
Use with any other
2452496 Rev7/22
