User's Guide
TPIC74100EVM User's Guide
1
Introduction.............................................................................................................................................................................2
2
Setup........................................................................................................................................................................................3
2.2
Setup..................................................................................................................................................................................4
2.3 Operation...........................................................................................................................................................................
Layout...........................................................................................................................................................................6
4
Schematic................................................................................................................................................................................8
History......................................................................................................................................................................9
Figure 2-1. Slew Rate Jumper Settings.......................................................................................................................................
Figure 2-3. Enable Jumper Settings............................................................................................................................................
Figure 2-5. Low Pass Filter Inductor Bypass Jumper Settings....................................................................................................
Figure 3-1. Top Assembly Layer..................................................................................................................................................
Figure 3-3. Top Layer Routing.....................................................................................................................................................
Trademarks
PowerPAD
is a trademark of Texas Instruments.
All trademarks are the property of their respective owners.
SLIU002A - SEPTEMBER 2008 - REVISED OCTOBER 2022
Submit Document Feedback

Table of Contents

Description...................................................................................................................................3
List of Figures
Settings............................................................................................................................4
Settings....................................................................................................................4
bottom)..........................................................................................................6
bottom).............................................................................................................7
Schematic.......................................................................................................................................8
List of Tables
Configurations...........................................................................................................................2
Materials.................................................................................................................................9
Copyright © 2022 Texas Instruments Incorporated
Table of Contents
4
3
4
4
6
7
TPIC74100EVM User's Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPIC74100EVM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Texas Instruments TPIC74100EVM

  • Page 1: Table Of Contents

    Figure 3-4. Bottom Layer Routing (viewed from bottom)......................7 Figure 4-1. TPIC74100EVM Schematic............................8 List of Tables Table 1-1. Device and Package Configurations...........................2 Table 4-1. TPIC74100EVM Bill of Materials..........................9 Trademarks PowerPAD ™ is a trademark of Texas Instruments. All trademarks are the property of their respective owners.
  • Page 2: Introduction

    Introduction www.ti.com 1 Introduction The Texas Instruments TPIC74100EVM evaluation module (EVM) helps designers evaluate the operation and performance of the TPIC74100 Switch Mode Power Supply – Buck Regulator. The EVM contains one DC/DC converter (See Table 1). Table 1-1. Device and Package Configurations...
  • Page 3: Setup

    Jumpers allow the slew rate to be set to four set points. SCR1 SCR0 SCR1 SCR0 SCR1 SCR0 SCR1 SCR0 slow medium -slow medium-fast fast Figure 2-1. Slew Rate Jumper Settings SLIU002A – SEPTEMBER 2008 – REVISED OCTOBER 2022 TPIC74100EVM User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
  • Page 4: Setup

    For proper operation of the TPIC74100, JP1, JP2, JP3, JP4, JP5, and JP6 should be properly configured. The recommended setting, using shorting blocks: JP1 and JP2 to Fast JP3 to Enabled TPIC74100EVM User's Guide SLIU002A – SEPTEMBER 2008 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
  • Page 5 Disabled. JP4 EN turns the device on or off. JP5 5Vg turns the regulated 5-V output on or off. JP6 Bypass disables the low-pass filter located on the input supply to the device. SLIU002A – SEPTEMBER 2008 – REVISED OCTOBER 2022 TPIC74100EVM User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
  • Page 6: Board Layout

    3 Board Layout Figure 6, Figure 7, Figure 8, and Figure 9 show the board layout for the TPIC74100EVM PWB. The EVM offers resistors, capacitors, and jumpers to program the switch pin slew rate and regulator turn-on Delay. Jumpers are also provided to enable the device and to enable the low-power mode option.
  • Page 7: Figure 3-3. Top Layer Routing

    Board Layout Figure 3-3. Top Layer Routing Figure 3-4. Bottom Layer Routing (viewed from bottom) SLIU002A – SEPTEMBER 2008 – REVISED OCTOBER 2022 TPIC74100EVM User's Guide Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
  • Page 8: Schematic

    Schematic www.ti.com 4 Schematic Figure 4-1. TPIC74100EVM Schematic TPIC74100EVM User's Guide SLIU002A – SEPTEMBER 2008 – REVISED OCTOBER 2022 Submit Document Feedback Copyright © 2022 Texas Instruments Incorporated...
  • Page 9: Revision History

    Revision History Table 4-1. TPIC74100EVM Bill of Materials COUNT DESCRIPTION SIZE PART NO. Capacitor, ceramic, 4.7nF, C1, C2 0603 muRata GRM188R71H472KA01B 50V, 10% Capacitor, ceramic, 470nF, 0603 muRata GRM188R71C474KA88B 16V, 10% Capacitor, ceramic, 100nF, C4, C7 0603 muRata GRM188R71C104KA01J...
