This user's guide describes the characteristics, operation, and use of the TPIC8101 Evaluation Module
(EVM). This EVM helps designers evaluate the operation and performance of the TPIC8101 dual-channel
knock sensor interface IC. A complete circuit description, schematic diagram, and bill of materials are also
included.
...................................................................................................................
1
..........................................................................................................................
2
3
4
...................................................................................................................
5
6
1
2
3
4
....................................................................................................................
5
6
7
8
9
1
2
3
4
5
TPIC8101EVM Bill of Materials
SLIU012 - December 2015
Submit Documentation Feedback
................................................................................
................................................................................................................
...........................................................................................
.....................................................................................................
.................................................................................................
..........................................................................................................
....................................................................................................
.........................................................................................................
.......................................................................................................
.............................................................................................................
......................................................................................
...................................................................................................
................................................................................................
..................................................................................................
...........................................................................................
Copyright © 2015, Texas Instruments Incorporated
TPIC8101 Evaluation Module
Contents
List of Figures
......................................................
List of Tables
User's Guide
SLIU012 - December 2015
TPIC8101 Evaluation Module
2
2
7
9
10
11
2
4
5
6
7
8
9
9
10
2
2
3
7
11
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Texas Instruments TPIC8101
Summary of Contents for Texas Instruments TPIC8101
-
Page 1: Table Of Contents
SLIU012 – December 2015 TPIC8101 Evaluation Module This user's guide describes the characteristics, operation, and use of the TPIC8101 Evaluation Module (EVM). This EVM helps designers evaluate the operation and performance of the TPIC8101 dual-channel knock sensor interface IC. A complete circuit description, schematic diagram, and bill of materials are also included. -
Page 2: Introduction
Figure 1. TIGER Communication Board (Left) and IC EVM Board (Right) Table 2 Table 3 show the various jumpers and test points on the TPIC8101 EVM. Note that not all of the test points are installed. Table 2. TPIC8101 EVM Jumpers... -
Page 3: Tpic8101 Evm Test Points
SPI chip select line TP13 Analog output of the TPIC8101 TP14 XCLK Clock input TP15 Connects to VDD pin of TPIC8101. Can be used to externally supply 5V if TI communication board is not used. GND1 GND1 Ground test point GND2 GND2... -
Page 4: Gui : Default Spi Mode
Setup www.ti.com GUI Operation 2.3.1 Software Package Download the TPIC8101 EVM GUI from the TPIC8101 EVM tool folder. After installing, run the executable file TPIC8101EVM.exe to start the GUI. Figure 2 illustrates the GUI. By default, the IC will be working on default SPI mode after power up, which happens after the USB cable is plugged into the PC. -
Page 5: Gui : Advanced Spi Mode
5 ms integration window. An approximate formula that can be used to calculate the hex value needed for a given time window is as follows: 25 s HEX = 22 s SLIU012 – December 2015 TPIC8101 Evaluation Module Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 6: Sample Waveforms
Sample waveforms of knock sensor output, integration window and IC analog output are shown in Figure Knock Sensor Output Integration Window IC Analog Output Figure 4. Sample Waveforms TPIC8101 Evaluation Module SLIU012 – December 2015 Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 7: Ranges And Typical Setup For Evaluation
106 µs (10th code, SPI 0xCA) • Integration window setting: 0x0110 Refer to Figure 5 to see how to input these settings into the GUI. Figure 5. GUI Inputs SLIU012 – December 2015 TPIC8101 Evaluation Module Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 8: Typical Evm Waveforms
Ranges and Typical Setup for Evaluation www.ti.com This set-up results in the following: 7270 kHz, 300 mVpp INT, 3 ms 4.48 V Output Figure 6. Typical EVM Waveforms TPIC8101 Evaluation Module SLIU012 – December 2015 Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 9: Board Layout
TPIC8101EVM PCB. The board layout and the PCB for TIGER communication board are not provided. Figure 7. Top Assembly Layer Figure 8. Bottom Layer Routing SLIU012 – December 2015 TPIC8101 Evaluation Module Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 10: Schematic
30.1k CH2FB 3300pF XCLK 30.1k 1.00k XOUT CH2FB 1.00M 470pF TCLK TPIC8101DWR CLK_SEL GND1 GND2 GND3 SCLK TCLK PPPC152LFBN-RC INT/H Figure 9. EVM Schematic TPIC8101 Evaluation Module SLIU012 – December 2015 Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... -
Page 11: Tpic8101Evm Bill Of Materials
Test Point, Miniature, Yellow, TH Keystone 5004 TP8, TP13, TP14 TP15 Test Point, Miniature, Red, TH Keystone 5000 Knock Sensor Interface, DW0020A Texas Instruments TPIC8101DWR SLIU012 – December 2015 TPIC8101 Evaluation Module Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated... - Page 12 STANDARD TERMS AND CONDITIONS FOR EVALUATION MODULES Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, or documentation (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms and conditions set forth herein. Acceptance of the EVM is expressly subject to the following terms and conditions.
- Page 13 FCC Interference Statement for Class B EVM devices NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 14 【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの 措置を取っていただく必要がありますのでご注意ください。 1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用 いただく。 2. 実験局の免許を取得後ご使用いただく。 3. 技術基準適合証明を取得後ご使用いただく。 なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。 上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ ンスツルメンツ株式会社 東京都新宿区西新宿６丁目２４番１号 西新宿三井ビル 3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page 電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧くださ い。http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page SPACER EVM Use Restrictions and Warnings: 4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.
- Page 15 Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief in any United States or foreign court. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2015, Texas Instruments Incorporated...
- Page 16 IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest issue.
- Page 17 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Texas Instruments TPIC8101EVM...
