  • Page 1 Keysight Wireless Test Set E6640A Wireless Test Set Getting Started Guide...
  • Page 2 PERFORMANCE OF THIS to the public to use, modify, DOCUMENT OR ANY INFORMATION reproduce, release, perform, CONTAINED HEREIN. SHOULD display, or disclose commercial KEYSIGHT AND THE USER HAVE A computer software or SEPARATE WRITTEN AGREEMENT commercial computer software WITH WARRANTY TERMS...
  • Page 3 URLs, look for the name of your product: http://www.keysight.com/find/exm To receive the latest updates by email, subscribe to Keysight Email Updates at the following URL: http://www.keysight.com/find/MyKeysight Information on preventing instrument damage can be found at: www.keysight.com/find/PreventingInstrumentRepair...

  • Page 5: Table Of Contents

    Contents Table of Contents Quick-Start 11 About the Test Set 12 Elements of the TRX 13 Input/Output Matrix (M9432A, Option 2FD) 14 Input/Output Matrix (M9433A, Option 4FD) 15 Initial Inspection 16 Shipping problems? 17 Test Set Location and Mounting Requirements 18 Locating the test set 18 Cooling and rack mounting 18 Separate Application Interfaces 19...
  • Page 6 Test Set Operating System 61 Keysight Software Installed 62 Measurement Software Applications 62 Customer Installation of Software 63 3rd party software verified by Keysight 63 Installation of other 3rd party software 63 User Accounts 64 Administrator login 64 User login 64...
  • Page 7 Contents Spyware protection 80 System Maintenance 81 Backup 81 System restore 81 Disk defragmenting 81 USB Connections 82 Hard Drive Partitioning and Use 84 Hard Drive Recovery Process 85 Updating the software 87 Configuring recovery prompt timing 94 OperatingTasks: System-Level Tasks 95 TRX Selection 96 Using HiSLIP 97 Using Socket Ports 97...
  • Page 8 MIMO Modulation Analysis Results 132 Tx Beam Forming 135 Tx Beam Forming Commands 135 Tx Beam Forming Results 136 E6640A Calibration Status 137 Certificates of Calibration 138 Alignments (MultiTouch Interface) 139 “All” Alignment (daily use) 139 Weekly alignment procedure 140...
  • Page 9 Check the Basics 210 Problems with Microsoft Windows Operating System 212 Returning a test set for Service 213 Read the Warranty 213 Service Options 213 Calling Keysight Technologies 213 Locations for Keysight Technologies 213 Packaging the Test Set 214 Getting Started Guide...
  • Page 10 Contents Getting Started Guide...

  • Page 11: Quick-Start

    Keysight Wireless Test Set E6640A EXM Wireless Test Set Getting Started Guide Quick-Start This section explains how to initialize the test set and generate and view a signal. “About the Test Set” on page 12 “Initial Inspection” on page 16 “Test Set Location and Mounting Requirements”...

  • Page 12: About The Test Set

    Quick-Start About the Test Set About the Test Set The E6640A EXM Wireless Test set contains one to four Keysight M943xA TRXs. The specific TRX model number is dependent on the options and applications ordered with the test set: — M9432A (Option 2FD) has 2 half-duplex and 2 full-duplex ports.

  • Page 13: Elements Of The Trx

    Quick-Start About the Test Set Elements of the TRX Each TRX contains the full set of hardware elements illustrated below. Two separate examples are shown, for models M9432A (Option 2FD) and M9433A (Option 4FD). Figure 1-1 TRX elements Each TRX is run by its own instance of the XSA firmware application. A fully loaded test set shows four independent XSA windows on its monitor display.

  • Page 14: Input/Output Matrix (M9432A, Option 2Fd)

    Quick-Start About the Test Set Input/Output Matrix (M9432A, Option 2FD) The input/output matrix is illustrated below, for the M9432A TRX. Ports RFIO 1 and RFIO2 are full-duplex ports (simultaneously inputs and outputs). Ports RF3 I|O and RF4 I|O can be inputs or outputs, but not simultaneously. Figure 1-2 M9432A input/output matrix “Port Configuration”...

  • Page 15: Input/Output Matrix (M9433A, Option 4Fd)

    Quick-Start About the Test Set Input/Output Matrix (M9433A, Option 4FD) The input/output matrix is illustrated below, for the M9433A TRX. Ports RFIO 1 through RFIO4 are full-duplex ports (simultaneously inputs and outputs). . Figure 1-3 M9433A input/output matrix “Port Configuration” on page 98 for more information.

  • Page 16: Initial Inspection

    Initial Inspection Inspect the shipping container and the cushioning material for signs of stress. Retain the shipping materials for future use, as you may wish to ship the test set to another location or to Keysight Technologies for service. Item Deliverable...

  • Page 17: Shipping Problems

    — Contact the nearest Keysight Technologies office. — Keep the shipping materials for the carrier’s inspection. — If you must return an test set to Keysight Technologies, use the original (or comparable) shipping materials. See “Returning a test set for Service” on page 183.

  • Page 18: Test Set Location And Mounting Requirements

    Quick-Start Test Set Location and Mounting Requirements Test Set Location and Mounting Requirements Locating the test set Make sure that the fan inlet and exhaust vent areas on the sides, bottom, and back of the test set chassis are not obstructed. The minimal required clearance is 1 inch (25 cm).

  • Page 19: Separate Application Interfaces

    Quick-Start Separate Application Interfaces Separate Application Interfaces There are two different interfaces available for test applications which run on the EXM (the newer MultiTouch interface and the older Traditional interface). Any TRX can be set up to use either interface. Figure 1-5 Traditional interface and MultiTouch interface Because there are some differences in menu structure between the two interfaces, many EXM procedures are performed in a slightly different way,...

  • Page 20: Multitouch Interface

    Quick-Start Separate Application Interfaces MultiTouch Interface The MultiTouch interface features a set of menus accessible from the right pane of the display. Many of the menu selections open a temporary configuration window (for example, the window for setting the RF power level shown in the illustration below).

  • Page 21: Traditional Interface

    Quick-Start Separate Application Interfaces Traditional Interface The Traditional interface also displays menus in the right pane, but in this case the menu must be selected from a Virtual Front Panel popup window. This window is accessed by right-clicking on the display and selecting Utility > Virtual Front Panel in the temporary menu which appears.

  • Page 22: Desktop Icons

    (This is for the MultiTouch interface.) Separate versions of the Configure Applications window are needed because a few of the E6640A measurement applications are supported in one interface but not in the other.

  • Page 23: Trx Configurator

    TRX, and each TRX window has the type of interface you selected for it. The UpdateFPGA button is used when installing a new TRX into an E6640A which was purchased without it, to ensure software compatibility.

  • Page 24: Launch Xsa

    Quick-Start Desktop Icons Launch XSA Use the Launch XSA icon to open an application window for each TRX which is (1) installed and (2) enabled in the TRX Configurator. The application window will have whichever interface was selected for that TRX in the configurator. (In the example below, TRX3 is running the Traditional interface, and TRX1 is running the MultiTouch interface.) Figure 1-11...

  • Page 25: Configure Applications

    Configure Applications Click the Configure Applications icon to launch this utility, which allows you to specify which of the E6640A’s X-series measurement applications will be preloaded into memory at startup. Preloading the most frequently-used applications is a convenience (however, selecting fewer of them for preload shortens the startup time and uses less memory).
  • Page 26 Figure 1-14 Configure Applications Use the selection table to specify which application will be running when the E6640A starts up. Applications which are not pre-loaded at startup can be loaded later if needed, simply by making the necessary mode/measurement selections.

  • Page 27: Turning On The Test Set The First Time

    2 Connect a monitor Connect the monitor to the Model E6640A has no display; an external monitor is monitor port on the front panel required. of the test set. “Virtual Front Panel” on page 28 “Test Set Location and Mounting...
  • Page 28 Windows message window, “Please wait while windows prepares to setup” • Keysight window At this time, it is safe to turn off the instrument before initializing the software. After launching the setup, do not turn off the instrument or remove power before the Setup Wizard completes and the system restarts.
  • Page 29 Quick-Start Turning on the test set the first time Item Deliverable Notes 7 Verify the installation From the mouse right-click If you require further assistance, contact the Keysight Utility > (Traditional Interface support team. menu, select Online assistance: http://www.keysight.com/find/assist Virtual Front Panel .
  • Page 30 Quick-Start Turning on the test set the first time Item Deliverable Notes Input/Output > RF 10 Generate and view a Select RFIO 1 as the input port Press signal (Traditional Input > RF Input Port > interface) RFIO 1 Select RFIO 2 as the output port. Input/Output >...
  • Page 31 Quick-Start Turning on the test set the first time Item Deliverable Notes Input/Output > 11 Generate and view a Select RFIO 1 as the input port Press signal (MultiTouch Input > RF Input Port, interface) RFIO 1 Select RFIO 2 as the output port. Input/Output >...

  • Page 32: Options And Licenses

    Quick-Start Options and Licenses Options and Licenses Checking Options (MultiTouch Interface) The options and licenses installed on the test set are listed on the System > Show System display, as illustrated below. Certain features of the test set (such as its frequency range, its analysis bandwidth, the measurement applications it runs, and in some cases individual measurements within an application) are licensed features, and are unavailable if the appropriate license is not installed.

  • Page 33: Checking Options (Traditional Interface)

    Quick-Start Options and Licenses Checking Options (Traditional Interface) The options and licenses installed on the test set are listed on the System > Show > System display, as illustrated below. Certain features of the test set (such as its frequency range, its analysis bandwidth, the measurement applications it runs, and in some cases individual measurements within an application) are licensed features, and are unavailable if the appropriate license is not installed.

  • Page 34: Option 2Fd

    — Performance characteristics for all four ports are same as those described for ports RFIO 1 and RFIO 2 in the E6640A EXM Wireless Test Set Data Sheet. — Port settings found under the Input/Output menu (and equivalent SCPI commands) reflect the options installed.

  • Page 35: Frequency Range Options

    1.1 to 1.8, 2.3 to 2.6, and 4.8 to 6 GHz (wireless connectivity) Option E6640A-506 380 MHz to 6 GHz (cellular communications and wireless connectivity) Option E6640A-5B0 (required for 5G NR testing) 380 MHz to 6 GHz with 5G NR bands (cellular communications and wireless connectivity)

  • Page 36: Anti-Virus Software And Firewalls

    The test set is shipped with the Windows firewall enabled. Do not modify the default network settings as this may cause problems with the operating system of the test set. Keysight recommends installing Windows updates. This should be enabled in Windows security settings. Shortening the Test Set Power-On Time You can set the configuration to pre-load only the applications that you typically run.

  • Page 37: Instrument Safety & Environmental Information

    Instrument Safety & Environmental Information Power requirements The only physical installation of your Keysight test set is a connection to a power source. Line voltage does not need to be selected. This test set does not contain customer serviceable fuses.

  • Page 38: Environmental Conditions (Operating)

    The cable appropriate to the original shipping location is included with the test set. See: http://www.keysight.com/find/powercords Always use the three-prong AC power cord supplied with this product. Failure to ensure adequate earth grounding by not using this cord can cause product damage.

  • Page 39: Emc (Electromagnetic Compatibility)

    This equipment is Class A suitable for professional use and is for use in electromagnetic environments outside of the home. Declaration of Conformity The Declaration of Conformity for any Keysight product can be found on the website: http://www.keysight.com/go/conformity Getting Started Guide...

  • Page 40: Ventilation

    Quick-Start Instrument Safety & Environmental Information Ventilation VENTILATION REQUIREMENTS: When installing the product in a cabinet, the convection into and out of the product must not be restricted. The ambient temperature (outside the cabinet) must be less than the maximum operating temperature of the product by 4oC for every 100 watts dissipated in the cabinet.
  • Page 41 See “Returning a test set for Service” on page 183. Replaceable parts must be approved or supplied by Keysight Technologies. You can order the service documentation for the instrument through your Keysight Sales and Service office. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended.

  • Page 42: Protecting Against Electrostatic Discharge

    Quick-Start Instrument Safety & Environmental Information Protecting against electrostatic discharge Electrostatic discharge (ESD) can damage or destroy electronic components (the possibility of unseen damage caused by ESD is present whenever components are transported, stored, or used). Test equipment and ESD To help reduce ESD damage that can occur while using test equipment: Do not use these first three techniques when working on circuitry with a voltage potential greater than 500 volts.

  • Page 43: Front And Rear Panel Features

    Keysight Wireless Test Set E6640A EXM Wireless Test Set Getting Started Guide 2 Front and Rear Panel Features The following topics can be found in this section: “Front Panel Features” on page 44 “Rear Panel Features” on page 57 “Front and Rear Panel Symbols” on page 58...

  • Page 44: Front Panel Features

    Front and Rear Panel Features Front Panel Features Front Panel Features The test set consists of instruments loaded in a PXI rack, hidden behind a front panel. There is a controller (located on the far left), and one to four TRX (transmit/receive) sub-instruments, each of which includes an RF signal generator and an RF signal analyzer.

  • Page 45: Controller Hardware Interface

    — DRIVE: When the Solid State Drive is active, the LED will flash. — POWER: If the LED is on, the power supply to the controller is good and the system should boot. — USER: Not used. TRIG This trigger line is not used by the E6640A. Getting Started Guide...
  • Page 46 Front and Rear Panel Features Front Panel Features Number Item Name Description LAN Connectors Two TCP/IP Interface connectors that are used for remote test set operation. Choose the LAN 1 port to have an IP address assigned to the test set dynamically, using DHCP.

  • Page 47: Trx Module Hardware Interface

    There can be as many as four TRX modules in the PXI rack; each has the same hardware interface, as illustrated below. If the E6640A test set was purchased with Option 4FD, all four RF ports have full-duplex capability, therefore two of the ports are labeled and used differently than they are described below.
  • Page 48 Front and Rear Panel Features Front Panel Features Number Item Name Description TRIG OUT 2 A trigger output used to synchronize other test equipment with the test set. Configurable from the Input/Output keys. TRIG IN 1 A trigger input used to synchronize other test equipment with the test set. Configurable from the Input/Output keys.

  • Page 49: Reference Module Hardware Interface

    Front and Rear Panel Features Front Panel Features Reference Module Hardware Interface The connectors which are exposed when the impact cover is in place are illustrated below: Figure 2-4 Reference module front panel Number Item Name Description 10 MHz OUT This BNC input port provides a timebase reference output from the M9300A Reference module.

  • Page 50: Virtual Front Panel (Traditional Interface)

    2. Left-click Utility (1) in the menu, as shown below. 3. Left-click Virtual Front Panel (2) in the menu, as shown below. The PC mouse and monitor are required when using the E6640A. For ease in using the VFP, the PC keyboard is recommended.
  • Page 51 Front and Rear Panel Features Front Panel Features Figure 2-6 VFP keys The VFP window is not used in the interface, MultiTouch because that interface makes all menus and functions available from the main display screen. Getting Started Guide...

  • Page 52: When The Test Set Is Controlled Remotely

    Front and Rear Panel Features Front Panel Features When the Test Set is Controlled Remotely The test set can be controlled remotely, from another computer. (See “Remote Desktop: Using the Test Set Remotely” on page 187.) When the test set is being controlled remotely, a log-on screen is displayed on the monitor.

  • Page 53: Display Annotations (Multitouch Interface)

    Display annotations (XSA MultiTouch interface) Number Description Notes The TRX sub-instrument associated with the This is needed because the E6640A can include up to four application (identified as “TRX1” through independent TRX sub-instruments in one PXI rack. “TRX4”). Screen tab. Shows mode and measurement To change the selection, click on the tab to open the selected for that tab.
  • Page 54 Front and Rear Panel Features Front Panel Features Number Description Notes Preset icon. Access to presets and defaults. Left side of measurement bar; includes display The following graphics indicate single/continuous of pass/fail result, plus single/continuous measurement: measurement selection and indicator. Measurement results.

  • Page 55: Display Annotations (Traditional Interface)

    The TRX sub-instrument associated with the application (identified as “TRX1” through “TRX4”). This is needed because the E6640A can include up to four independent TRX sub-instruments in one PXI rack. Getting Started Guide...
  • Page 56 Front and Rear Panel Features Front Panel Features Number Description Function Key Banner; shows the name of the selected application Mode that is currently running. Measurement title; shows title information for the Meas current measurement, or a title that you created for View/Display, Display, Title the measurement.

  • Page 57: Rear Panel Features

    +3.3 VDC, (5) Inhibit [Low], (6) +12 VDC, (7) Rsrvd, (8) -12 VDC, (9) Logic Gnd. 10 MHz REF OUT This BNC connector is not used by the E6640A test set. The front panel 10 MHz OUT connector should be used instead. 10 MHz REF IN This BNC connector is not used by the E6640A test set.

  • Page 58: Front And Rear Panel Symbols

    Front and Rear Panel Features Front and Rear Panel Symbols Front and Rear Panel Symbols Labels and symbols which may be shown on the E6640A (mainly on the rear panel of the chassis) are described in the table below. Symbol Description This symbol marks the standby position of the power line switch.
  • Page 59 UK conformity mark is a UK government owned mark. Products showing this mark comply with all applicable UK regulations. The Keysight email address is required by EU directives applicable to our product. The CSA mark is a registered trademark of the CSA international.
  • Page 60 Front and Rear Panel Features Front and Rear Panel Symbols Getting Started Guide...

  • Page 61: Test Set Operating System

    Keysight Wireless Test Set E6640A EXM Wireless Test Set Getting Started Guide 3 Test Set Operating System The following topics can be found in this section: “Keysight Software Installed” on page 62 “Customer Installation of Software” on page 63 “User Accounts” on page 64 “Licensing”...

  • Page 62: Keysight Software Installed

    Keysight Software Installed Measurement Software Applications A set of Keysight measurement applications for different modes (GSM/EDTE, cdma2000, Sequence Analyzer mode, etc.) is installed by default in the test set, but these must be licensed in order to be used. Whichever licenses were purchased with the instrument are installed at the factory (see “Options and...

  • Page 63: Customer Installation Of Software

    Also, you must not remove any applications or programs that are installed on the test set when it is shipped from the factory. If you install programs other than those that Keysight has tested, it could cause problems with the test set's applications. If this happens, you should try uninstalling the program that has caused the problem, or try changing the program's configuration.

  • Page 64: User Accounts

    — Change the time and date — Run any application The E6640A was formerly a product of Agilent Technologies. If the front panel of the test set shows Agilent as the manufacturer, then “agilent4u” may have been set as the password for the Administrator account.

  • Page 65: Customer Creation Of Accounts

    Administrator or Power User privileges. Otherwise, the test set software will not operate correctly. It is Keysight’s expectation that each user’s My Documents folder is mapped to the D: drive. This is to avoid overwriting the user’s data in the event the Keysight Recovery must be performed.

  • Page 66: Licensing

    Test Set Operating System Licensing Licensing Licensed Applications The following application licenses are available for the EXM: Licenses Description V9060EM0E IQ Analyzer Measurement Application (always installed) V9065EM0E Sequence Analyzer Downlink Application V9065EM1E Sequence Analyzer Uplink Application (always installed) GSM/EDGE/Evo Application V9071EM0E and Y9071EM0E cdma2000®...

  • Page 67: Flexible Software Licensing

    Test Set Operating System Licensing Flexible Software Licensing Keysight offers a variety of flexible licensing options to fit your needs and budget. You have two or more options to choose from for the license term, license type, and KeysightCare software support subscription.

  • Page 68: Licensing New Measurement Application Software - After Initial Purchase

    Purchase Additional measurement application software can be ordered after your initial purchase of the E6640A test set. Software upgrades are provided in a kit that includes an option based Entitlement Certificate, a license agreement. The licenses are downloaded from the license Web site onto a storage device so they can be loaded into the instrument.
  • Page 69 System applications. Verify that the new application appears in If you require further assistance, please the list. contact the Keysight support team. Online assistance: http://www.keysight.com/find/assist If you do not have access to the Internet, contact your local Keysight Technologies Sales and Service Office, or if in the United States, call 1-800-829-4444.

  • Page 70: Transporting A License Between Test Sets

    Transporting a License Between Test Sets Transporting a License Between Test Sets To move a transportable license from one test set to another, Keysight recommends that both test sets be at the same instrument software release. This ensures that the user experience is identical between instruments.
  • Page 71 — On the source instrument, press on the Source Instrument System > More> Licensing… — It may take a minute for the Keysight License Manager screen to be fully populated with all the installed licenses. 5 Transport the — On the source instrument, locate...
  • Page 72 — Close the Save dialog and exit the KSM Transportation Web page. 8 Install License File in — With the target instrument The Keysight License Services running on Target Instrument running, insert the USB flash the target instrument looks for *.lic files...

  • Page 73: Windows Configuration

    To recover from problems caused by changing Windows systems settings, you may have to reinstall the Windows system and test set application using the Keysight Recovery process. Settings that can be changed You may change the following Windows settings or administrative tasks (available from the Windows Control Panel) to select your personal preferences.

  • Page 74: Settings That Must Not Be Changed

    Test Set Operating System Windows Configuration You may use this feature To do this... Under Advanced System Settings, System Properties, Advanced, Performance: choose either “Let Windows choose what’s best for my computer” or “Adjust for best performance”. Leave all other settings unchanged. Settings that must not be changed Avoid changing any settings in this section.
  • Page 75 — The .NET Framework or any Hotfixes or Service Packs for the .NET Framework — The “Microsoft Visual J# .NET Redistributable Package 1.1" — Programs that begin with “Agilent” or “Keysight” — The Adobe Acrobat Reader — Modify — The Agilent/Keysight I/O Library “GPIB27”, “GPIB28” interfaces shown as configured Instrument I/O in the Agilent/Keysight Connection Expert or I/O Config.

  • Page 76: Configuring Printers

    The Computer Name, or hostname, is pre-configured from the factory. It must be a unique name so that it does not conflict with other equipment on your LAN. The pre-configured Computer Name is K-E6640A-xxxxx, where xxxxx represents the last 5 digits of the test set serial number.

  • Page 77: Windows Security

    Test Set Operating System Windows Security Windows Security Microsoft recommends the following to ensure the test set Windows operating system is protected: — Use an internet firewall. — Get the latest critical Windows updates. — Use up-to-date antivirus software. To check the status or make changes in the security settings for your test set, click Start, Control Panel, and then System and Security.

  • Page 78: Windows Firewall

    Test Set Operating System Windows Security Windows Firewall Click Windows Firewall in the System and Security window to check the firewall status of your test set. The test set is shipped with the Windows Firewall enabled. Figure 3-2 Firewall settings The window may look slightly different on your test set.

  • Page 79: Automatic Updates

    Test Set Operating System Windows Security Automatic updates Keysight recommends installing Windows updates. This should be enabled in Windows security settings. The default test set setting is to automatically check for critical Windows Updates and notify you, if the test set has internet access.

  • Page 80: Virus Protection

    Antivirus application software has been tested to be compatible with the test set. See the section on “3rd party software verified by Keysight” on page 63 for anti-virus software that has been tested by Keysight. Having antivirus software installed may have a slight impact on the test set performance.

  • Page 81: System Maintenance

    Using the Keysight Recovery system in conjunction with a regular backup strategy should allow full recovery of the test set data.

  • Page 82: Usb Connections

    The test set USB device driver included in the test set software supports the test and measurement industry standard USBTMC-USB488 device class. In addition, the Agilent/Keysight IO Libraries that is installed on your test set contains USB Host drivers that allow control of other test sets connected to the USB bus.
  • Page 83 Test Set Operating System USB Connections Keysight Technologies does not support or warrant correct test set operation if additional USB drivers from third parties are installed in the test set. It is possible that additional drivers could break the normal USB operation. If USB operation is broken, recovery would require reinstalling the test set application using the hard drive recovery process.

  • Page 84: Hard Drive Partitioning And Use

    This allows you to restore the data if you ever need to replace the hard drive. — The E: partition is reserved for Keysight’s use. The primary use of the E: drive is for housing the Calibration and Alignment data. Do not change or overwrite the files on this drive.

  • Page 85: Hard Drive Recovery Process

    Hard Drive Recovery Process Hard Drive Recovery Process The Keysight Recovery System can be used to repair errors on the test set's C: drive partition, or to restore the original factory configuration of the system software. The Keysight Recovery System is stored in a separate hidden hard disk drive partition.
  • Page 86 Press 1, then press Enter to confirm. complete. After exiting the Keysight Recovery System, the test set reboots. If the original factory test set system “Turning on the test set the has been restored, the test set re-executes the following process: first time”...

  • Page 87: Updating The Software

    — You must have a USB keyboard and mouse. — You must be able to log in to the instrument as the administrator. — You must be able to transfer a large file (~1 GByte) to the E6640A being updated.
  • Page 88 1. Connect a USB keyboard and mouse to the E6640A. 2. If the E6640A is not already running, power it up and allow it to boot up completely. 3. Shut down the E6640A measurement application if it is running (close all TRX windows).
  • Page 89 Test Set Operating System Hard Drive Recovery Process Instrument software installation If you downloaded the instrument software update file to the instrument via LAN, access that file from the location that it was stored and proceed to step 1. If you downloaded the instrument software update file to a USB storage device, plug that into one of the USB ports on the front of the instrument.
  • Page 90 Test Set Operating System Hard Drive Recovery Process Table 3-2 Preparing the installation Step Notes Extraction window: Software updater window, showing uninstallation progress: While the old instrument software is being uninstalled, the text “Uninstall in Progress” text rolls across the screen, to be replaced finally by “Completed Successfully”. No interaction is required at this point. Getting Started Guide...
  • Page 91 Test Set Operating System Hard Drive Recovery Process Table 3-2 Preparing the installation Step Notes Software updater window, showing installation progress: During installation, various popup windows may appear temporarily, while required software components are downloaded from external sites. While the new instrument software is being installed, the text “Installation in Progress” text rolls across the screen.
  • Page 92 During FPGA programming, DO NOT power off the E6640A for ANY reason! Interrupting the FPGA update process can place the instrument in an unusable state, requiring it to be returned to Keysight for repair. After the installation has completed successfully, a confirmation message is displayed:...
  • Page 93 Step Notes 4 Clicking the “Finish” button results in a Windows shutdown. 5 After you power the E6640A back on, it will If the instrument does not reboot, remove the boot up in the default “Instrument” account, USB storage device and cycle power. The boot...

  • Page 94: Configuring Recovery Prompt Timing

    Test Set Operating System Hard Drive Recovery Process Configuring recovery prompt timing You can configure the time at which the test set power-up process waits for the selection of the recovery process by performing the following steps: Table 3-3 Recovery prompt timing Step Notes 1 From the Windows Start menu, right-click...

  • Page 95: Operatingtasks: System-Level Tasks

    “Switched MIMO” on page 114 “True MIMO” on page 121 “Tx Beam Forming” on page 135 “E6640A Calibration Status” on page 137 “Alignments (MultiTouch Interface)” on page 139 “Alignments (Traditional Interface)” on page 142 “LAN Address Configuration” on page 145...

  • Page 96: Trx Selection

    OperatingTasks: System-Level Tasks TRX Selection TRX Selection On the monitor or remote desktop view of the test set, each TRX is represented by a separate XSA window. You can identify which TRX a window controls by looking for the identifier (TRX1 through TRX4 for a fully loaded system) at the top left corner of the window.

  • Page 97: Using Hislip

    OperatingTasks: System-Level Tasks TRX Selection Using HiSLIP HiSLIP (High-Speed LAN Instrument Protocol) is the recommended interface for connection to the E6640A, because of its superior performance characteristics. Use hislip0 through hislip3: — TRX1: TCPIP0::<IP Address>::hislip0::INSTR — TRX2: TCPIP0::<IP Address>::hislip1::INSTR — TRX3: TCPIP0::<IP Address>::hislip2::INSTR...

  • Page 98: Port Configuration

    OperatingTasks: System-Level Tasks Port Configuration Port Configuration Any of the TRXs four RF ports can be configured as an input port (accepting a signal to be analyzed) or as an output port (providing an RF stimulus). If the test set was purchased with Option 4FD, the TRX model used is M9433A, and ports RFIO 1 through RFIO 4 connect to the source and analyzer through a splitter/combiner rather than a switch;...

  • Page 99: Full Duplex Port Setup (Rfio 1 And Rfio 2)

    OperatingTasks: System-Level Tasks Port Configuration Full Duplex Port Setup (RFIO 1 and RFIO 2) Ports RFIO 1 and RFIO 2 on the M9432A TRX (Option 2FD) connect to a splitter/combiner, and can therefore be used in full duplex mode. Figure 4-3 RFIO 1 on M9432A used in full duplex mode The menu path for the MultiTouch interface is listed first, followed by the path for the Traditional interface in italics.
  • Page 100 OperatingTasks: System-Level Tasks Port Configuration Figure 4-4 RFIO 2 on M9432A used in full duplex mode The menu path for the MultiTouch interface is listed first, followed by the path for the Traditional interface in italics. To use the RFIO 2 port as the input and output, set up the RF Input using this menu setting or its equivalent command: Input/Output >...

  • Page 101: Separate Input And Output Port Setup (Rf3 I|O And Rf4 I|O)

    OperatingTasks: System-Level Tasks Port Configuration Separate Input and Output Port Setup (RF3 I|O and RF4 I|O) Ports RF3 I|O and RF4 I|O on the M9432A TRX (Option 2FD) connect to a switch rather than a splitter/combiner, which means that one of these ports must be used as either an input or an output, not both, at any given time.
  • Page 102 OperatingTasks: System-Level Tasks Port Configuration (2) Define RF4 I|O as an output, using this menu setting or its equivalent command: Input/Output > RF Source > Half Duplex Output Port > RF4 I|O Input/Output > More > RF Output & Test Set Config > Half Duplex Config > RF Output Port >...
  • Page 103 OperatingTasks: System-Level Tasks Port Configuration Figure 4-6 RF3 I|O on M9432A used as output, RF4 I|O as input The menu path for the MultiTouch interface is listed first, followed by the path for the Traditional interface in italics. To define RF4 I|O as an input and RF3 I|O as an output, follow this four-step process.
  • Page 104 OperatingTasks: System-Level Tasks Port Configuration (3) Set up the RF Input using this menu setting or its equivalent command: Input/Output > Input > RF Input Port > RF Input Input/Output > RF Input > RF Input Port > RF Input Command: :FEED:RF:PORT RFIN (4) Set up the RF Output using this menu setting or its equivalent command:...

  • Page 105: Separate Input And Output Port Setup (Rfio 1 And Rfio 2)

    OperatingTasks: System-Level Tasks Port Configuration Separate Input and Output Port Setup (RFIO 1 and RFIO 2) Although Ports RFIO 1 and RFIO 2 on the M9432A TRX (Option 2FD) are designed to operate as full-duplex ports, they can function as separate inputs and outputs.
  • Page 106 OperatingTasks: System-Level Tasks Port Configuration Figure 4-8 RFIO 2 on M9432A used as input, RFIO 1 as output The menu path for the MultiTouch interface is listed first, followed by the path for the Traditional interface in italics. To use the RFIO 1 port as the input and the RFIO 2 port as the output, set up the RF Input using this menu setting or its equivalent command: Input/Output >...

  • Page 107: Option 4Fd: Full Duplex Port Setup

    OperatingTasks: System-Level Tasks Port Configuration Option 4FD: Full Duplex Port Setup If the test set was purchased with Option 4FD, the M9433A TRX is used. Each of the IO ports connects to a splitter/combiner rather than a switch, and it can be used in full duplex mode, as a simultaneous input and output.

  • Page 108: Option 4Fd: Separate Input And Output Port Setup

    OperatingTasks: System-Level Tasks Port Configuration Option 4FD: Separate Input and Output Port Setup Although, with Option 4FD, all of the RFIO ports are designed to operate as full-duplex ports, they can function as separate inputs and outputs. In this example, the RFIO 2 port is used as an input, and the RFIO 3 port as an output. (Other port combinations could be selected simply by substituting different port names in the instructions provided below.) Figure 4-10...

  • Page 109: Millimeter-Wave Accessory Instruments

    OperatingTasks: System-Level Tasks Port Configuration Millimeter-Wave Accessory Instruments For testing at higher frequencies than the EXM itself can generate, two other instruments are commonly used with the EXM: the M1740A mmWave Transceiver (usually called the Remote Radio Head or RRH) and the E7770A Common Interface Unit (usually called the CIU).
  • Page 110 OperatingTasks: System-Level Tasks Port Configuration As illustrated below, the CIU is able to upconvert the RF output of the EXM to the 6-12 GHz range (the lower portion of the picture), and apply this signal to the DUT. On the same path, it also can accept a return signal from the DUT, downconvert it to the range of the EXM, and return it to an input port on the EXM.
  • Page 111 OperatingTasks: System-Level Tasks Port Configuration In the test setup illustrated below, the EXM is used to drive mmWave testing of the DUT over a wireless interface (typically using horn antennas within a test chamber). The CIU provides the combined LO, Power, and Control inputs needed by the M1740As.
  • Page 112 OperatingTasks: System-Level Tasks Port Configuration The test setup illustrated below expands on the previous example, by adding 6-12 GHz testing of the DUTs over a wired interface. A second CIU is used for upconversion of the EXM output to the 6-12 GHz range (and downconversion of the signal returned by the DUT).
  • Page 113 OperatingTasks: System-Level Tasks Port Configuration The test setup illustrated is used for WLAN testing, which requires an input to the DUT in the 7 GHz range, which is slightly above the frequency range of the EXM. An output signal from the EXM is upconverted by the CIU and furnished to the DUT.

  • Page 114: Switched Mimo

    OperatingTasks: System-Level Tasks Switched MIMO Switched MIMO For WLAN modulation accuracy measurements, a form of MIMO measurement can be made with a single TRX, using a time-division multiplexing process. The same source/analyzer pair within the TRX switches between the antenna ports of the Device Under Test.

  • Page 115: Source Sync Control

    OperatingTasks: System-Level Tasks Switched MIMO For 3x3 MIMO, the RFIO 1 port (a full-duplex port) captures the data stream from the first antenna port of the DUT. The other full-duplex port, RFIO 2, captures the data stream from the second antenna port of the DUT. One of the half-duplex ports, RF3 I|O or RF4 I|O, captures the data stream from the third antenna port of the DUT.

  • Page 116: Half Duplex Rf Input

    OperatingTasks: System-Level Tasks Switched MIMO Half Duplex RF Input In the case of 3x3 switched MIMO, one of the half-duplex ports (RF3 I|O or RF4 I|O) must be designated as an RF input port for the third input. In the Input/Output >...

  • Page 117: Acquisition Rf Input Port

    OperatingTasks: System-Level Tasks Switched MIMO Acquisition RF Input Port An RF input path must be selected for each acquisition. In the Meas Setup > Settings > RF Input Port menu, select RFIO1, RFIO2, or RF Input, as needed for each acquisition. The equivalent menu path for the Traditional interface is: Meas Setup >...

  • Page 118: Switched Mimo Modulation Accuracy Measurement Scpi Commands

    OperatingTasks: System-Level Tasks Switched MIMO Switched MIMO Modulation Accuracy measurement SCPI commands The following commands are used to set up the MIMO Modulation Accuracy (“EVM MIMO”) measurement. Command Description Notes Freq Error Sets a frequency :CALCulate:LSEQuencer:WLAN:EVMMimo:LIMit: error limit FERRor <real> Clock Error Sets a clock error :CALCulate:LSEQuencer:WLAN:EVMMimo:LIMit:...
  • Page 119 OperatingTasks: System-Level Tasks Switched MIMO Command Description Notes Equalizer Training Specifies how the :CALCulate:LSEQuencer:WLAN:EVMMimo:EQUalizer: equalizer is TMODe SEQuence|SDATa initialized or trained. Track Amplitude Sspecifies whether :CALCulate:LSEQuencer:WLAN:EVMMimo:PILot:TRACk:AMPLi analyzer tracks tude OFF|ON|0|1 amplitude changes in the pilot subcarriers. Track Phase Specifies whether :CALCulate:LSEQuencer:WLAN:EVMMimo:PILot:TRACk: analyzer tracks PHASe OFF|ON|0|1...

  • Page 120: Switched Mimo Results

    OperatingTasks: System-Level Tasks Switched MIMO Switched MIMO Results The results available for a WLAN MIMO Modulation Accuracy measurement are as follows (the results for Stream 3 are returned as -1.0 (not tested) in the case of 2x2 MIMO): Index Result Parameter Overall Pass/Fail Result (0 = Pass, 1 = Fail, -1 = Not tested) Stream 1 RMS EVM pass/fail result (1.0 = fail, 0.0 = pass, -1.0 = Not tested) Stream 1 RMS EVM (dB)

  • Page 121: True Mimo

    OperatingTasks: System-Level Tasks True MIMO True MIMO In WLAN mode, True MIMO (simultaneous rather than switched MIMO) is supported for the MIMO Modulation Analysis measurement. (This functionality is not available in Sequence Analyzer mode.) Setting up this type of measurement requires configuration of two separate TRXs. For MIMO Modulation Analysis, two or more measurement data streams are captured simultaneously, by two or more separate TRXs in the EXM test set.
  • Page 122 OperatingTasks: System-Level Tasks True MIMO Here is an example of 3x3 MIMO: Figure 4-19 3X3 true MIMO connections In the example setup shown here, TRX 1 runs the MIMO Modulation Analysis measurement, and is also configured to control TRX 2 and 3, which collect the second and third data streams.
  • Page 123 OperatingTasks: System-Level Tasks True MIMO Here is an example of 4x4 MIMO: Figure 4-20 4X4 true MIMO connections In the example setup shown here, TRX 1 runs the MIMO Modulation Analysis measurement, and is also configured to control TRX 2 to 4, which collect the second, third, and fourth data streams.

  • Page 124: Source Settings For Mimo

    OperatingTasks: System-Level Tasks True MIMO Source Settings for MIMO Unlike measurement settings, which are made only to the primary TRX and applied to the others, source settings can be made separately for each TRX. However, it is possible to make certain source settings to other TRXs by making those settings on the primary TRX.
  • Page 125 OperatingTasks: System-Level Tasks True MIMO settings for the primary TRX source (amplitude, waveform, trigger source, trigger type, and RF output) are also applied to the second of two “2x2 + 2x2” or “1x1 + 1x1” pairs of TRXs. The equivalent SCPI command is: :SOUR:SYNC:SETT:SEGM2:ENAB ON 5.

  • Page 126: Constraints On Waveform File Names

    OperatingTasks: System-Level Tasks True MIMO Constraints on Waveform File Names When Sync Settings is enabled, as described in the previous procedure, it is necessary to follow a convention for naming the waveform files used by the TRXs, so that the file associated with each TRX is distinguished by a TRX-specific suffix.

  • Page 127: Constraints On Radio Standards

    OperatingTasks: System-Level Tasks True MIMO Constraints on Radio Standards Only certain radio standards support MIMO. Under Mode Setup > Radio Std, select 802.11n or 802.11ac. MIMO Type For the MIMO Modulation Analysis measurement, go to the Meas Setup > MIMO Type menu and select 2x2, 3x3, or 4x4.This setting determines whether the display shows two, three, or four constellation diagrams for the measurement.) The equivalent SCPI command is: [:SENSe]:EVMMimo:TYPe M2M2|M3M3|M4M4...
  • Page 128 OperatingTasks: System-Level Tasks True MIMO Highlighted Analyzer from the Remote Analyzer Config window, or send to the primary the equivalent SCPI command: :SYST:COMM:ANAL:REL 8. The equivalent SCPI command for the steps described above is as follows (modify the address string "127.0.0.1:5125" as needed): :SYST:COMM:ANAL:SEL "127.0.0.1:5125"...

  • Page 129: Remote Analyzer Configuration (Traditional Interface)

    OperatingTasks: System-Level Tasks True MIMO Remote Analyzer Configuration (Traditional Interface) 1. From the primary TRX window (TRX 1 in this example), select Mode Setup > Global Settings > Remote Analyzer Config. 2. A list is displayed which includes any TRX which you have previously used (unless you have deleted it) and any added while in the Add Analyzer to List menu.
  • Page 130 OperatingTasks: System-Level Tasks True MIMO Figure 4-22 IP and socket port addresses (traditional interface) The procedure given above is for 2x2 MIMO; the process is the same for 3x3 or 4x4 MIMO, except that more TRXs are added. The command equivalent for 3x3 MIMO would be: :SYST:COMM:ANAL:SEL "127.0.0.1:5125"...

  • Page 131: Mimo Modulation Analysis Measurement Scpi Commands

    OperatingTasks: System-Level Tasks MIMO Modulation Analysis measurement SCPI commands MIMO Modulation Analysis measurement SCPI commands The following commands are used to set up the MIMO Modulation Analysis measurement. Command Description Notes Matrix Type Sets the type as [:SENSe]:EVMMimo:MTYPe DMAP|FOURier DMAP or Fourier MIMO Type Sets the type as [:SENSe]:EVMMimo:TYPe M2M2|M3M3|M4M4...

  • Page 132: Mimo Modulation Analysis Results

    OperatingTasks: System-Level Tasks MIMO Modulation Analysis Results MIMO Modulation Analysis Results The results available for a WLAN MIMO Modulation Analysis measurement are as follows (the results for Stream 3 are returned as -1.0 (not tested) in the case of 2x2 MIMO): Index Result Parameter Returns unprocessed I/Q trace data of Capture Interval, as a series of trace point values for Channel m.
  • Page 133 OperatingTasks: System-Level Tasks MIMO Modulation Analysis Results Index Result Parameter Returns series of floating point numbers that represent each sample in the Channel Response for STRM m CH k. Stream index m can be set and queried through EVMM:RESult:STReam command. Channel index k can be set and queried through EVMM:RESult:CHAN command.
  • Page 134 OperatingTasks: System-Level Tasks MIMO Modulation Analysis Results Index Result Parameter Returns comma-separated floating point numbers of spectral flatness trace for STRM m CH k. Stream index m can be set and queried through EVMM:RESult:STReam command. Channel index k can be set and queried through EVMM:RESult:CHAN command.

  • Page 135: Tx Beam Forming

    OperatingTasks: System-Level Tasks Tx Beam Forming Tx Beam Forming If license V9077B-KFP is installed, Tx Beam-Forming results are available from the Modulation Analysis measurement in WLAN mode. Tx Beam Forming Commands Two commands are added for Tx Beam Forming, as described in the table below.

  • Page 136: Tx Beam Forming Results

    OperatingTasks: System-Level Tasks Tx Beam Forming Tx Beam Forming Results The Tx Beam Forming results are added to the Modulation Analysis measurement results as Index 21 and Index 22, as described in the table below. Index Result Parameter Tx Beam Forming Calibrated Angle Error returns a series of floating point numbers (in rad) that represent the calibrated angle error vectors on channels, when - Radio Std is 802.11n (20 MHz), or 802.11n (40 MHz), and MIMO Tx Channel Count <= 4...

  • Page 137: E6640A Calibration Status

    E6640A. There isn’t a single instrument-level calibration (or calibration due-date) that covers the E6640A as a whole and all of the TRX modules (and the Reference module) within it. Each module is calibrated independently, and not necessarily at the same time that the others in the test set are calibrated.

  • Page 138: Certificates Of Calibration

    E6640A), are the only items that require calibration, and therefore they are the only items supplied with a CoC and calibration sticker at shipment. Each E6640A test set is shipped with a yellow envelope which contains your calibration certificates; this envelope is labeled (lower right corner) with a sticker identifying the unit model number (E6640A) and serial number.

  • Page 139: Alignments (Multitouch Interface)

    OperatingTasks: System-Level Tasks Alignments (MultiTouch Interface) Alignments (MultiTouch Interface) Alignments are internal calibration adjustments which each TRX module must make to ensure that internal signal levels are properly maintained. To avoid interruptions, the alignments are not run automatically, either at startup or afterward;...

  • Page 140: Weekly Alignment Procedure

    OperatingTasks: System-Level Tasks Alignments (MultiTouch Interface) Weekly alignment procedure A more thorough alignment of the source and analyzer in the TRX is required on a weekly basis. This procedure is similar to the “All” alignment described above, but it also performs additional alignment functions related to slow-drifting parameters which do not change significantly over time periods shorter than a week.

  • Page 141: Alignment Statistics

    OperatingTasks: System-Level Tasks Alignments (MultiTouch Interface) Alignment statistics The TRX’s internal temperature and the time since the most recent alignment can be checked by selecting System Settings> Alignments > Show Alignment Statistics, as illustrated below. Figure 4-26 Show Alignment Statistics Getting Started Guide...

  • Page 142: Alignments (Traditional Interface)

    OperatingTasks: System-Level Tasks Alignments (Traditional Interface) Alignments (Traditional Interface) Alignments are internal calibration adjustments which each TRX module must make to ensure that internal signal levels are properly maintained. To avoid interruptions, the alignments are not run automatically, either at startup or afterward;...

  • Page 143: Weekly Alignment Procedure

    OperatingTasks: System-Level Tasks Alignments (Traditional Interface) Weekly alignment procedure A more thorough alignment of the source and analyzer in the TRX is required on a weekly basis. This procedure is similar to the “All” alignment described above, but it also performs additional alignment functions related to slow-drifting parameters which do not change significantly over time periods shorter than a week.
  • Page 144 OperatingTasks: System-Level Tasks Alignments (Traditional Interface) Alignment statistics The TRX’s internal temperature and the time since the most recent alignment can be checked by selecting System > Alignments > Show Alignment Statistics, as illustrated below. Figure 4-28 Show Alignment Statistics Getting Started Guide...

  • Page 145: Lan Address Configuration

    LAN Address Configuration LAN Address Configuration The E6640A supports both dynamic and static assignment of its IP address, using ports LAN 1 and LAN 2 respectively. The LAN 1 port is designed for dynamic IP addressing, using the Dynamic Host Configuration Protocol.
  • Page 146 If you cannot easily obtain a monitor view of System > Show > System, you can determine the computer name using the instrument serial number. The computer name is in the format K-E6640A-nnnnn, ending in the last five digits of the serial number.

  • Page 147: Managing Licenses

    Licenses can be either time-based or perpetual (the latter have no expiration date). To verify which licenses are installed, open the Keysight License Manager from the Windows Start menu. (In the MultiTouch interface, it can also be opened by clicking the "gear" icon at the upper left to open the System Settings screen, and clicking Licensing >...

  • Page 148: Flexible Software Licensing

    OperatingTasks: System-Level Tasks Managing Licenses Flexible Software Licensing Keysight offers a variety of flexible licensing options to fit your needs and budget. You have two or more options to choose from for the license term, license type, and KeysightCare software support subscription.

  • Page 149: Operating Tasks: Receiver Setup

    Keysight Wireless Test Set E6640A EXM Wireless Test Set Getting Started Guide 5 Operating Tasks: Receiver Setup The following topics can be found in this section: “Measurement Setup (MultiTouch Interface)” on page 150 “Measurement Setup (Traditional Interface” on page 154 “Marker Setup (MultiTouch Interface)”...

  • Page 150: Measurement Setup (Multitouch Interface)

    Operating Tasks: Receiver Setup Measurement Setup (MultiTouch Interface) Measurement Setup (MultiTouch Interface) The analyzer/receiver function of the E6640A relates to measurement of signals received from the DUT. Clicking on the measurement tab at the upper left corner of the display opens the Mode/Measurement/View Selector, which you can use to select a particular kind of measurement.
  • Page 151 Operating Tasks: Receiver Setup Measurement Setup (MultiTouch Interface) Most measurement settings are made from the menus, which can be accessed by selecting the dropdown button near the upper right of the display. Figure 5-2 Accessing Menus Selecting a menu from the dropdown list displays the menu selections (usually the selections are indented under multiple tabs shown at the right).
  • Page 152 Operating Tasks: Receiver Setup Measurement Setup (MultiTouch Interface) Figure 5-3 Measurement Menus Although some menu choices involve only a simple selection (Top | Center | Bottom) or a value to be entered (O dBm), some choices cause a more elaborate selection screen to appear in the display. In the example illustrated below, Trigger >...
  • Page 153 Operating Tasks: Receiver Setup Measurement Setup (MultiTouch Interface) Another type of complex screen which some menu selections open is a configuration window such as the Meas Setup Summary Table, which gathers together multiple settings on one screen to make it easier to review them. Figure 5-5 Meas Setup Summary Table The menu choices are different for each measurement.

  • Page 154: Measurement Setup

    Operating Tasks: Receiver Setup Measurement Setup (Traditional Interface Measurement Setup (Traditional Interface The analyzer/receiver function of the E6640A relates to measurement of signals received from the DUT. Menus are accessed from the the Virtual Front Panel popup window. To open the VFP, right-click on the display and select Utility >...
  • Page 155 Operating Tasks: Receiver Setup Measurement Setup (Traditional Interface Click the Meas button on the VFP and select the desired measurement (using the More function as necessary to see all the available choices). In this example, the Channel Power measurement is selected. Figure 5-7 Selecting a measurement Settings for the selected measurement are made by selecting other menus.
  • Page 156 Operating Tasks: Receiver Setup Measurement Setup (Traditional Interface Where a menu setting requires a numerical value, use the numeric keypad at the lower right corner of the VFP to enter the number required. Figure 5-9 Selecting menu settings Getting Started Guide...

  • Page 157: Marker Setup (Multitouch Interface)

    Operating Tasks: Receiver Setup Marker Setup (MultiTouch Interface) Marker Setup (MultiTouch Interface) Multiple markers can be set up on the measurement display. Under Marker > Select Marker, choose the marker of interest and select Settings for it such as Marker Frequency and Marker Mode. Figure 5-10 The Marker/Settings menu The currently selected marker can be moved simply by dragging it, but it can...
  • Page 158 Operating Tasks: Receiver Setup Marker Setup (MultiTouch Interface) (If Delta is selected, the marker is used with reference to another marker at a different frequency, to show the difference between trace amplitudes at those two points on the spectrum.) To define Marker 2 as a delta marker referenced to Marker 1, first click on the Marker 1 icon and drag it to the space occupied by the Reference Marker icon directly under the Marker 2 icon;...

  • Page 159: Marker Setup (Traditional Interface)

    Operating Tasks: Receiver Setup Marker Setup (Traditional Interface) Marker Setup (Traditional Interface) Multiple markers can be set up on the measurement display. Click Marker on the VFP to open the Marker menu, and click Select Marker to choose the particular marker for which you want to make settings. Figure 5-14 The Marker >...
  • Page 160 Operating Tasks: Receiver Setup Marker Setup (Traditional Interface) In the example setup below, Marker 1 is configured as Normal, and Marker 2 is configured as Delta. Under Properties, set Marker 2 as Relative To 1. When Marker 1 is selected, its frequency is displayed, as well as the measured power at that frequency.

  • Page 161: Operating Tasks: Source Setup

    Keysight Wireless Test Set E6640A EXM Wireless Test Set Getting Started Guide 6 Operating Tasks: Source Setup The following topics can be found in this section: “General RF Source Setup” on page 162 “Loading and Running Waveform Files (Traditional Interface)” on page 166 “Creating Waveform Sequences (Traditional Interface)”...

  • Page 162: General Rf Source Setup

    Operating Tasks: Source Setup General RF Source Setup General RF Source Setup The source function of the E6640A relates to generation of test signals to be transmitted to the DUT. (Not all measurement scenarios require these signals, but many do.) In the MultiTouch interface, most source settings are made from the Input/Output >...

  • Page 163: Loading And Running Waveform Files (Multitouch Interface)

    Operating Tasks: Source Setup Loading and Running Waveform Files (MultiTouch Interface) Loading and Running Waveform Files (MultiTouch Interface) The Modulation Setup > ARB Setup window can be used to configure various functions of the arbitrary waveform generator, and to select which waveform files it plays.
  • Page 164 Operating Tasks: Source Setup Loading and Running Waveform Files (MultiTouch Interface) Basic Control is used to set markers and triggers, and to select waveform files as illustrated below. Click Select Waveform to choose a waveform file that is currently in ARB memory. If a desired waveform file is not currently shown in the Segments in ARB Memory list, use Recall Waveform to load it.
  • Page 165 Operating Tasks: Source Setup Loading and Running Waveform Files (MultiTouch Interface) Figure 6-4 Recalling an ARB file (Recall function) Getting Started Guide...

  • Page 166: Loading And Running Waveform Files (Traditional Interface)

    Operating Tasks: Source Setup Loading and Running Waveform Files (Traditional Interface) Loading and Running Waveform Files (Traditional Interface) The Source > Modulation Setup > ARB menu can be used to configure various functions of the arbitrary waveform generator, and to select which waveform files it plays.
  • Page 167 Operating Tasks: Source Setup Loading and Running Waveform Files (Traditional Interface) The ARB Waveform menu and its submenus are used to control which waveforms are in ARB memory. Click Segments on Hard Disk to see a list of available waveform files on the hard disk drive (use the Current Directory or Default Directory selections to navigate to a different directory on the hard drive if necessary).

  • Page 168: Creating Waveform Sequences (Multitouch Interface)

    Operating Tasks: Source Setup Creating Waveform Sequences (MultiTouch Interface) Creating Waveform Sequences (MultiTouch Interface) Waveform Sequences (under ARB Setup) is used to create a sequence of waveform files to be played in order: 1. Click Build New Sequence. 2. In the window which opens, click Insert Waveform (this opens a window showing the waveforms that are in ARB memory.

  • Page 169: Using The Waveform Sequence (Multitouch Interface)

    Operating Tasks: Source Setup Creating Waveform Sequences (MultiTouch Interface) Using the waveform sequence (MultiTouch interface) Once a waveform sequence file (.seq) has been saved, it can be used as if it were a regular waveform file (.wfm). In the Recall Waveform window, change the displayed File Type to Waveform Sequence Files and select the desired file, which is then loaded into ARB memory, and can be used in place of a waveform file.

  • Page 170: Creating Waveform Sequences (Traditional Interface)

    Operating Tasks: Source Setup Creating Waveform Sequences (Traditional Interface) Creating Waveform Sequences (Traditional Interface) To create a sequence of waveform files to be played in order, go to the Source menu and select Modulation Setup > ARB >Waveform Sequences > Build New Sequence >...
  • Page 171 Operating Tasks: Source Setup Creating Waveform Sequences (Traditional Interface) Select any waveform segments you need from the hard drive and click Load Segment to Arb Memory. Figure 6-11 Loading waveform segments into ARB memory When the desired segments are in ARB memory, click Insert Waveform to add them to the waveform sequence.

  • Page 172: Using The Waveform Sequence (Traditional Interface)

    Operating Tasks: Source Setup Creating Waveform Sequences (Traditional Interface) Using the waveform sequence (Traditional interface) Once a waveform sequence file (.seq) has been saved, it can be used as if it were a regular waveform file (.wfm). On the Source menu, select Modulation Setup >...

  • Page 173: Using Waveform Markers

    Using Waveform Markers Using Waveform Markers ARB waveform files played by the source in the E6640A include markers within the waveform data, together with settings for these markers included in the header of the waveform file. One of these markers can designated for RF blanking of the source output (that is, RF power is on only during the marker event).

  • Page 174: Waveform Marker Settings (Multitouch Interface)

    Marker Polarity settings determine whether the trigger is rising (Positive) or falling (Negative). ALC Hold settings have no effect in model E6640A. RF blanking is set up by Marker Routing (under Basic Control) or by RF Blanking Routing under Header Utilities. The possible settings include: —...

  • Page 175: Waveform Marker Settings (Traditional Interface)

    Operating Tasks: Source Setup Using Waveform Markers Waveform Marker Settings (Traditional Interface) To view or alter marker settings included in the ARB file header, go to the Source menu and select Modulation Setup > ARB > Marker Utilities. Use the Marker Polarity menu to set the polarity of the four waveform markers as positive or negative.
  • Page 176 Operating Tasks: Source Setup Using Waveform Markers Select Utilities to see marker settings in the header file. Figure 6-18 Marker settings in ARB file header Getting Started Guide...

  • Page 177: Generating Trigger Outputs (Multitouch Interface)

    In selecting a marker under Trig 1 Out or Trig 2 Out, the options include Off (no output trigger), Marker N (choose a numbered marker), or Source Per Arb. (The latter option does not apply to the E6640A model.) Getting Started Guide...

  • Page 178: Generating Trigger Outputs (Traditional Interface)

    Operating Tasks: Source Setup Using Waveform Markers Generating Trigger Outputs (Traditional Interface) The waveform markers can be used to generate triggers at the Trig 1 and Trig 2 outputs on the front panel. In the Input/Output > Trigger Output menu, separate settings are available for Trig 1 Out and Trig 2 Out.

  • Page 179: Locking Waveform Files (Multitouch Interface)

    Locking Waveform Files (MultiTouch Interface) Locking Waveform Files (MultiTouch Interface) The measurement applications which run on the E6640A can have a "Y" license (which supports unrestricted use of waveform files by the internal source) or a "V" license (a measurement-oriented license which limits the source to a fixed number of slots into which waveforms can be locked).
  • Page 180 Operating Tasks: Source Setup Locking Waveform Files (MultiTouch Interface) To lock a waveform into a slot, highlight the name of the waveform in the list and click Lock Waveform In Slot. A confirmation window appears, giving you an opportunity to cancel if you don’t want the slot permanently assigned. Figure 6-22 Waveform Utilities: adding a waveform Getting Started Guide...

  • Page 181: Locking Waveform Files (Traditional Interface)

    Locking Waveform Files (Traditional Interface) Locking Waveform Files (Traditional Interface) The measurement applications which run on the E6640A can have a "Y" license (which supports unrestricted use of waveform files by the internal source) or a "V" license (a measurement-oriented license which limits the source to a fixed number of slots into which waveforms can be locked).
  • Page 182 Operating Tasks: Source Setup Locking Waveform Files (Traditional Interface) Click Segments on Hard Disk and move the desired waveform into ARB memory. Click Add Waveform to add the selected waveform into a license slot. A confirmation window appears, giving you an opportunity to cancel if you don’t want the slot permanently assigned.

  • Page 183: Header Utilities (Multitouch Interface)

    (such as Sample Rate and Marker Polarity) are editable; to save your changes to these settings, click Save Header. ALC Hold settings have no effect in model E6640A. However, the setting for RF Blanking is functional and can be selected here.

  • Page 184: Header Utilities (Traditional Interface)

    (To save those modified settings to the header file, click Save Setup To Header. ALC Hold settings have no effect in model E6640A. However, the setting for RF Blanking is functional and can be selected here.

  • Page 185: Windows Operating System

    Keysight Wireless Test Set E6640A EXM Wireless Test Set Getting Started Guide 7 Windows Operating System The following topics can be found in this section: “Navigating Windows Without a Mouse” on page 186 “Remote Desktop: Using the Test Set Remotely” on page 187 “Programmatic Control of the Test Set”...

  • Page 186: Navigating Windows Without A Mouse

    Windows Operating System Navigating Windows Without a Mouse Navigating Windows Without a Mouse Table 7-1 Key functions Key Presses Actions Exits/closes a Windows dialog box (does not exit an Application window) Enter Does the current "default action". If a menu item or a button is currently highlighted, then the Enter key activates that menu item or button.

  • Page 187: Remote Desktop: Using The Test Set Remotely

    Windows Operating System Remote Desktop: Using the Test Set Remotely Remote Desktop: Using the Test Set Remotely Windows Remote Desktop is recommended for remote control of the test set. The Remote Desktop functionality is a Microsoft Windows capability. The following discussion provides some guidelines for using this capability with the test set.

  • Page 188: Setting Up Remote Desktop Operation

    Windows Operating System Remote Desktop: Using the Test Set Remotely Setting up Remote Desktop operation Setting up the test set Before the test set can be controlled through a Remote Desktop Connection, it must be set up to allow connection from a remote computer. Table 7-2 Setting up a remote desktop connection Step...

  • Page 189: How To Locate The Computer Name Of The Test Set

    Remote Desktop: Using the Test Set Remotely The following instructions relate to software provided by Microsoft Corporation. Keysight offers no warranty regarding the operation of such software. The procedure described here may be changed by Microsoft at some future time.
  • Page 190 Windows Operating System Remote Desktop: Using the Test Set Remotely Table 7-6 Locating the name from the Windows desktop (without a mouse) Step Notes 1 Press Ctrl+Esc to display the Windows Start menu. 2 Use the Up Arrow or Down Arrow keys to select the Control Panel item.

  • Page 191: Running A Remote Desktop Session

    Windows Operating System Remote Desktop: Using the Test Set Remotely Running a Remote Desktop session Initializing a Remote Desktop session To initialize a Remote Desktop Session, you need to know the Computer Name of the test set. This information can be shown on the test set display by “How to locate the computer following the procedure in the section name of the test set”...
  • Page 192 Windows Operating System Remote Desktop: Using the Test Set Remotely Setting Remote Desktop options Table 7-8 Setting options Step Notes 1 On the Remote Desktop Connection window, click Options. The window expands vertically to show several configuration tabs. The Options dialog has several tabs. Generally, the default settings are correct.
  • Page 193 Windows Operating System Remote Desktop: Using the Test Set Remotely Table 7-8 Setting options Step Notes 3 Click the Display tab. Under Remote desktop size, you may select the size of the window in which the test set display appears. Do not select any size smaller than 1024 x 768 pixels.
  • Page 194 Windows Operating System Remote Desktop: Using the Test Set Remotely Table 7-8 Setting options Step Notes 5 Click the Experience tab. To Optimize the performance of the Remote Desktop session, choose the appropriate connection format from the drop-down list. Getting Started Guide...
  • Page 195 Windows Operating System Remote Desktop: Using the Test Set Remotely Accessing menus for Remote Desktop operation Using the mouse, right-click the application display window to access the following remote desktop menus: The function of each selection in the menu is generally identical to that of the corresponding Virtual Front Panel key.
  • Page 196 Windows Operating System Remote Desktop: Using the Test Set Remotely Keycode commands for Remote Desktop operation When using the test set in remote desktop mode, the following combinations of remote keyboard keys can be used to perform the operation of the virtual front-panel keys.
  • Page 197 Windows Operating System Remote Desktop: Using the Test Set Remotely Table 7-9 Keycode commands To initiate the following virtual key: Press these keys on the remote computer keyboard: Ctrl Shift AMPTD Y Scale Ctrl Shift Auto Couple Backspace Bk Sp Ctrl Cancel (Esc) Ctrl...
  • Page 198 Windows Operating System Remote Desktop: Using the Test Set Remotely Table 7-9 Keycode commands To initiate the following virtual key: Press these keys on the remote computer keyboard: Mute checkbox under the Volume Mute Control Next Window Ctrl Shift Peak Search Ctrl Ctrl Print...
  • Page 199 Windows Operating System Remote Desktop: Using the Test Set Remotely Table 7-9 Keycode commands To initiate the following virtual key: Press these keys on the remote computer keyboard: Up Arrow Up Arrow Ctrl User Preset Ctrl Shift View/Display Zoom Ctrl Shift Use the –...
  • Page 200 Windows Operating System Remote Desktop: Using the Test Set Remotely Ending a Remote Desktop session There are two ways to disconnect the remote computer from the test set to end the session: Table 7-10 Ending the session Step Notes 1 Click the X, then click OK. For full-screen, the X appears at the top center of the window.

  • Page 201: The Virtual Front Panel

    Windows Operating System Remote Desktop: Using the Test Set Remotely The Virtual Front Panel The Virtual Front Panel is a software equivalent of the front-panel key set, which provides another alternate method for test set control. It may be displayed in a separate window on the test set (or remote desktop) display. The Virtual Front Panel is also available when using the test set directly, provided that a mouse or other pointing device is attached to it.

  • Page 202: Programmatic Control Of The Test Set

    For information on how to send commands to the test set, using a VISA connection, see the X-Series Signal Analyzer Programmer’s Guide, which is available online at: http://www.keysight.com/find/mxa_manuals The individual TRX instruments within the test set chassis are controlled using “TRX Selection” on page 38 separate VISA connections;...

  • Page 203: Capturing/Printing Displays And Windows

    Windows Operating System Capturing/Printing Displays and Windows Capturing/Printing Displays and Windows You need an external keyboard and mouse to use this feature. Table 7-11 Saving the desktop Step Notes 1 Press Print Screen on the external This captures the desktop and saves it on the keyboard.

  • Page 204: Windows Shortcuts And Miscellaneous Tasks

    Windows Operating System Windows Shortcuts and Miscellaneous Tasks Windows Shortcuts and Miscellaneous Tasks This section provides a list of Windows shortcuts (key combinations) that are useful when you operate the test set without an attached mouse and keyboard. (See also “Navigating Windows Without a Mouse”...
  • Page 205 Windows Operating System Windows Shortcuts and Miscellaneous Tasks Navigating an Application Menu without a Mouse or Keyboard This example uses Microsoft Excel, but you can use a similar sequence of operations to select and execute any menu item of any application. To select and execute the item Sheet >...

  • Page 206: Windows Taskbar Auto-Hide Feature

    Windows Operating System Windows Shortcuts and Miscellaneous Tasks Windows taskbar auto-hide feature The Windows taskbar should always be in the auto-hide mode when using the test set application. If the taskbar is not set to auto-hide, the lower part of the test set display is obscured by the taskbar.
  • Page 207 Windows Operating System Windows Shortcuts and Miscellaneous Tasks Table 7-15 Restoring taskbar auto-hide mode Step Notes 4 Select the Auto-hide the taskbar check If you are not using a mouse, press Tab box. repeatedly until the auto-hide option is selected, then press Select to toggle the check box state.

  • Page 208: Windows Startup Folder

    Windows itself, or by a third-party application, or by any user), that program automatically runs every time Windows is restarted. When your test set is first configured by Keysight, shortcuts to the appropriate application software and supporting programs are placed in the Startup folder.

  • Page 209: Troubleshooting

    Keysight Wireless Test Set E6640A EXM Wireless Test Set Getting Started Guide 8 Troubleshooting The following topics can be found in this section: “Check the Basics” on page 210 “Problems with Microsoft Windows Operating System” on page 212 “Returning a test set for Service” on page 213 No operator serviceable parts inside.

  • Page 210: Check The Basics

    If the test set gets far enough along in the boot process to run the "Keysight Recovery System", perform the “Hard Drive Recovery Process” on page 85.
  • Page 211 Troubleshooting Check the Basics — If the previously performed alignments did not resolve the problem, press System >Alignments > Restore Align Defaults. Then press System > Alignments > Align Now >All. The test set must be powered on for 45 minutes prior to performing alignments. —...

  • Page 212: Problems With Microsoft Windows Operating System

    “Settings that can be changed” on page The E6640A EXM Wireless Test Set operates in an open Windows environment, so you can install software on the test set. However, installation of non-approved software may affect test set performance. Keysight does not warrant the performance with non-approved software installed.

  • Page 213: Returning A Test Set For Service

    Service Options Keysight Technologies offers several optional maintenance plans to service your test set after the warranty has expired. Call your Keysight Technologies office for full details. Calling Keysight Technologies Keysight Technologies has offices around the world to provide you with complete support for your test set.

  • Page 214: Packaging The Test Set

    Troubleshooting Returning a test set for Service Packaging the Test Set Use original packaging or comparable. It is best to pack the unit in the original factory packaging materials if they are available. Test set damage can result from using packaging materials other than those specified.
  • Page 215 This information is subject to change without notice. © Keysight Technologies 2014-2021 Edition 1, November 2021 E6640-90001 www.keysight.com...

Table of Contents
