- Page 1 ZH 用户手册 / 组装说明 EN Instructions for use / assembly instructions Focus E² 31936007...
- Page 2 中文 安全技巧 装配时为避免挤压和切割受伤，必须戴上 手套。 本产品只允许作为洗浴、卫生和洁身之 用。 冷热水管间过大的压力差必须予以平衡。 必须避免让身体敏感部位（如眼睛）接触 到莲蓬头喷水。必须保持莲蓬头与人头之 间有足够的距离。 该产品不得作扶柄使用。必须安装单独的 扶柄。 安装提示 • 安装前必须检查产品是否受到运输损害。 安装后将不认可运输损害或表面损伤。 • 管道和阀门必须根据通用标准进行安装、冲 洗和检查。 • 请遵守当地国家现行的安装规定。 技术参数 ® 本龙头配有 EcoSmart （流量限制器） 1 MPa 工作压强： 最大 0,1 - 0,5 MPa 推荐工作压强： 1,6 MPa 测试压强： (1 MPa = 10 bar = 147 PSI) 70°C 热水温度： 最大 65°C 推荐热水温度： 70°C ⁄ 4 分钟 热力消毒: 最大 • 自动防止回流 • 该产品专为饮用水设计！ 符号说明...
-
Page 3: Safety Notes
English Operation (see page 7) Safety Notes Maintenance check valve Gloves should be worn during installation to prevent crushing and cutting injuries. (see page 6) The product may only be used for bathing, The check valves must be checked regularly hygienic and body cleaning purposes. according to DIN EN 1717 in accordance The hot and cold supplies must be of equal with national or regional regulations (at pressures. least once a year). Do not allow the streams of the shower touch sensitive body parts (such as your eyes). An adequate distance must be kept between the shower and you. The product may not be used as a holding handle. A separate handle must be installed. Installation Instructions • Prior to installation, inspect the product for transport damages. After it has been installed, no transport or surface damage will be honoured. • The pipes and the fixture must be installed, flushed and tested as per the applicable standards. • The plumbing codes applicable in the respective countries must be observed. Technical Data This mixer series-produced with EcoSmart®... - Page 4 13244187 (1,8 Nm) SW 27 mm...
- Page 5 SW 3 mm (2 Nm)
- Page 7 开 / open 关 / close 热 / hot 冷 / cold 开 / open...
- Page 8 中文 汉斯格雅产品的清洁建议 重要说明 肥皂，洗发水、沐浴液、染发剂、香水、刮胡 现代的卫浴龙头、厨房龙头、花洒、配件、盥 水、指甲油的残留也会对产品造成损伤。 洗台、浴盆和加热器采用的制造材料非常迥 此处：使用后要小心地用清水将剩余物冲洗干 异，以适应产品外形设计和使用功能的市场需 净。 求。 同样在产品下方不得存放洗涤剂和化学药品， 为了避免产品损坏和由此引发的投诉及争议， 例如不可放在用于洗脸盆的梳洗柜中否则挥发 必须在使用和清洁产品时遵循有关规程。 气体将损坏产品。 在已经损伤的表面继续使用清洁剂会给表面造 在保养汉斯格雅产品时，原则上必须注意： 成更大的损伤。 表面损坏的部件必须更换，否则会有 • 只能使用那些有明确注明是适用于本产品的 受伤的危险。 清洁剂。 • 不允许使用含有盐酸、蚁酸、氯漂或醋酸的 清洁剂，因为这些清洁剂会给产品表面造成 严重的损伤。 不按规定进行清洁而造成的任何损坏不在本公 • 含磷酸的清洁剂必须在特定条件下使用。 司产品保修范围之内。 • 不允许将两种以上清洁剂混合使用。 QuickClean • 不允许使用具有研磨作用的清洁工具和设 有了QuickClean，手工清洁功能，要去掉喷头上 备，如不适合的清洁粉末、海绵垫或超细麦 的水垢，只需简单地搓除即可。 克布。 • 必须严格遵守清洁剂生产厂商的使用说明。 担保 • 严格遵守清洁剂的用量和作用时间，决不允 许清洁剂的作用时间长于规定值。 Hansgrohe 向用户保证，该产品无制造 缺陷。...
-
Page 9: Warranty
English Cleaning Recommendation for Hans- remove any cleaner residue. • The use of steam cleaners is not permitted. The grohe Products high temperatures can damage the products. Today, modern sanitary and kitchen tapware, Important showers, accessories, washstands, tubs and radiators Residues of toiletries such as liquid soaps, shampoos consist of very different materials to comply with the and shower gels, hair dyes, perfumes, aftershave and needs of the market with regard to design and nail varnish can also cause damage. functionality. Here too: Carefully rinse with water after use to To avoid damage and reclamations, it is necessary to remove residues. consider certain criteria when cleaning. Likewise, do not store any cleaning agents or With regard to caring for the Hans- chemicals under the products, for example in a vanity grohe products, the following must in unit, as the vapours may damage the products. principle be heeded: The damage of already damaged surfaces will deteriorate under the effect of the cleansers. - Page 10 94246000 93339000 > 1 min...
- Page 11 0,60 0,55 0,50 0,45 0,40 0,35 0,30 0,25 0,20 0,15 0,10 0,05 0,00 9 12 15 18 21 24 27 30 Q = l/min Q = l/sec...
- Page 12 98607000 13914000 28562007 95941000 97660000 93339000 98400000 94246000 (39x1,5) 28071000 97779000 94074000 97159000 95929000 31098000 94184000 98749000 95819000 98189000 (14x2,5) 98183000 (23x2,5) 96775000 98185000 98217000 (22x2) (9x2,5) Hansgrohe · Auestraße 5 - 9 · D-77761 Schiltach · Telefon +49 (0) 78 36/51-1282 · Telefax +49 (0) 7836/511440 E-Mail: info@hansgrohe.com ·...
