Hans Grohe Talis Classic 14165 Series Instructions For Use/Assembly Instructions
Hans Grohe Talis Classic 14165 Series Instructions For Use/Assembly Instructions

Hans Grohe Talis Classic 14165 Series Instructions For Use/Assembly Instructions

Hide thumbs Also See for Talis Classic 14165 Series:

Advertisement

Quick Links

DE
Gebrauchsanleitung / Montageanleitung
FR
Mode d'emploi / Instructions de montage
EN
Instructions for use / assembly instructions
IT
Istruzioni per l'uso / Istruzioni per Installazione
ES
Modo de empleo / Instrucciones de montaje
NL
Gebruiksaanwijzing / Handleiding
DK
Brugsanvisning / Monteringsvejledning
PT
Instruções para uso / Manual de Instalación
PL
Instrukcja obsługi / Instrukcja montażu
CS
Návod k použití / Montážní návod
SK
Návod na použitie / Montážny návod
ZH
RU
Руководство пользователя / Инструкция по
монтажу
HU
Használati útmutató / Szerelési útmutató
FI
Käyttöohje / Asennusohje
SV
Bruksanvisning / Monteringsanvisning
LT
Vartotojo instrukcija / Montavimo instrukcijos
HR
Upute za uporabu / Uputstva za instalaciju
TR
Kullanım kılavuzu / Montaj kılavuzu
RO
Manual de utilizare / Instrucţiuni de montare
EL
Οδηγίες χρήσης / Οδηγία συναρμολόγησης
SL
Navodilo za uporabo / Navodila za montažo
ET
Kasutusjuhend / Paigaldusjuhend
LV
Lietošanas pamācība / Montāžas instrukcija
SR
Uputstvo za upotrebu / Uputstvo za montažu
NO
Bruksanvisning / Montasjeveiledning
BG
Инструкция за употреба / Ръководство за
монтаж
SQ
Udhëzuesi i përdorimit / Udhëzime rreth montimit 29
/
AR
2
3
4
5
6
7
8
9
Talis Classic
Metropol S
10
14165XXX
14665000
11
12
13
14
PuraVida
Metris S
15
15665XXX
31665000
16
17
18
19
20
Metris
Metris Classic
21
31675000
31676XXX
22
23
24
25
Focus S
Focus
26
31763000
31965000
27
28
30
Metris
31685000
Metropol E
14675000
Talis E²
31666000
Focus E
31761000
Talis S / Talis
32675000

Advertisement

loading
Need help?

Need help?

Do you have a question about the Talis Classic 14165 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hans Grohe Talis Classic 14165 Series

  • Page 1 Gebrauchsanleitung / Montageanleitung Mode d‘emploi / Instructions de montage Instructions for use / assembly instructions Istruzioni per l‘uso / Istruzioni per Installazione Modo de empleo / Instrucciones de montaje Gebruiksaanwijzing / Handleiding Brugsanvisning / Monteringsvejledning Instruções para uso / Manual de Instalación Talis Classic Metropol S Metropol E...
  • Page 2: Installation Instructions

    English Safety Notes Symbol description Gloves should be worn during installation to prevent Do not use silicone containing acetic acid! crushing and cutting injuries. The shower system may only be used for bathing, Adjustment hygienic and body cleansing purposes. To adjust the hot water limiter on single lever The hot and cold supplies must be of equal mixers, please see page 33.
  • Page 4 PuraVida 15665XXX SW 4 mm 5 Nm...
  • Page 5 0,3 MPa 0,3 МПа 60 °C 10 °C...
  • Page 6 Metropol S Talis Classic PuraVida Metris S 14665000 14165XXX 15665XXX 31665000 Talis E² Metris Classic Focus S Focus 31666000 31676XXX 31763000 31965000 Talis S / Talis Metris Metropol E Metris 32675000 31685000 14675000 31675000...
  • Page 7 Focus E 31761000...
  • Page 8 98133000 16x2 92730000 94073000 98400000 (39x1,5) 96525000 98793000 M5x20 95008000 95140000 98796000 98790XXX 98418000 (43x3) 96454000 13595000 96338000 (25 mm) 98792XXX (Ø 150 mm) 95519000 96338000 96338000 98418000 (43x3) 98532000 31692000 96338000 31093000 96338000 32096000 96338000 31793000 96338000 95276XXX 14895000 96338000 96338000 14193XXX...
  • Page 9 98133000 96525000 (16x2) (M5x20) 92730000 98400000 94073000 (39x1,5) 95008000 96454000 95140000 98796000 95508000 (48x3) 96447000 98148000 (43x1,5) 95010000 96452000 96338000 (Ø 170 mm) 31094000 96338000 14094000 96338000 31791000 13595000 (25 mm) 13596000 (22 mm)
