Pittasoft BlackVue 7-1CH Quick Start Manual page 36

Speaker
(Voice Guidance)
LED Indicators
Button
Sensor
Backup Battery
Input Power
Power Consumption
Operation
Temperature
Storage
Temperature
High Temperature
Cut-Off
36 BLACKVUE
Built-in
Front: Recording LED, GPS LED, B/W/L (Bluetooth/Wi-Fi/LTE)
LED, Front security LED
Rear: 2 Rear Security LED (Front & Rear side)
Touch sensor:
Pressing the touch sensor triggers manual recording
depending on the firmware settings.
3-Axis Acceleration Sensor
Built-in super capacitor
DC 12V-24V (3 pole DC Plug (Ø3.5 x Ø1.1)) to Wires
(Black: GND / Yellow: B+ / Red: ACC)
y BlackVue 9-1CH
Normal Mode (GPS On/1CH): Avg. 300mA /12V
Parking Mode (GPS Off/1CH): Avg. 230mA /12V
y BlackVue 9-2CH
Normal Mode (GPS On/2CH): Avg. 400mA /12V
Parking Mode (GPS Off/2CH): Avg. 340mA /12V
* Actual power consumption may vary depending on use
conditions and environment.
-20 °C − 70 °C (-4 °F − 158 °F)
-20 °C − 80 °C (-4 °F − 176 °F )
Approx. 75 °C (167 °F)
