Plug the right angle connector of the rear camera connection cable to the front
camera ('Rear' port).
Use the pry tool to lift the edges of the rubber window sealing and molding and
tuck in the rear camera connectoin cable.
Rear camera connection cable
Connectivity Module (Optional-Sold Separately): Connect the connectivity
module to the front camera and attach it to the edge of the window. Use the pry
tool to tuck in the cable
Plug the cigarette lighter power cable into the cigarette lighter socket and the
O
front camera. Skip to
for Hardwiring Power Cable setup.
Use the pry tool to lift the edges of the windshield trim/molding and tuck in the
power cord.
Power cord
Rear camera connection cable
