- Page 1 Quick Start Guide BlackVue 7-1CH, 2CH BlackVue 9-1CH, 2CH * 1CH Model * 2CH Model ENGLISH www.blackvue.com Detailed Manual...
- Page 2 BLACKVUE BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH For manuals, customer support and FAQs go to www.blackvue.com...
-
Page 3: Important Safety Information
If the product is damaged or the power supply is cut due to an accident, video may not be recorded. y Do not remove the microSD card while the microSD card is saving or reading data. The data can be damaged or malfunctions may occur. BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH... -
Page 4: Fcc Compliance Information
FCC Compliance Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protections against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 5 3. For more detailed information about disposal of your BlackVue dashcam, please contact your city office, waste disposal service or the shop where you purchased the product. BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH...
- Page 6 IC Compliance This Class [B] digital apparatus complies with Canadian ICES-003. This radio transmitter has been approved by Industry Canada to operate with the antenna types listed below with the maximum permissible gain and required antenna impedance for each antenna type indicated. Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited for use with this device.
-
Page 7: Need Help
1CH: Cable clips (5 EA) Quick start guide 2CH: Cable clips (8 EA) Need help? Download the manual (including FAQs) and the latest firmware from www.blackvue.com Or contact a Customer Support expert at cs@pittasoft.com BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH... -
Page 8: Front Camera
At a glance The following diagrams explain each part of the BlackVue dashcam. Front camera 134 mm Camera lens Mounting bracket Front security LED : Lights on during (i) normal mode, (ii) an event is being recorded (impact detected), (iii) manual recording has started, or (iv) motion is detected in parking mode. - Page 9 Tamperproof case screw hole DC in (power connector) microSD card slot microSD card cover Touch Sensor: Press the sensor to trigger a customizable function. Available options: - Manual recording trigger (default) - Off BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH...
- Page 10 Rear camera Mounting bracket 69.4 mm Tamperproof case Camera lens Rear security LED : Stays on in all recording modes but can be turned off from firmware settings. Tamperproof case screw hole Front camera connection port 10 BLACKVUE...
- Page 11 Do not install the product in a location where it can obstruct the driver's field of vision. Turn off the engine. Open the cover of the microSD card slot, gently push the card into the slot until it locks into place and close the cover. BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 11...
- Page 12 Peel off the protective film from the double-sided tape and attach the front camera to the windshield behind the rear-view mirror. Adjust the angle of the lens by pressing the release button and rotating the body of the front camera simultaneously. We recommend pointing the lens slightly downwards (≈10°...
- Page 13 Adjust the angle of the lens by rotating the body of the camera. Fully tighten the screw to ensure angle of the lens is fixed in place. BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 13...
- Page 14 Plug the right angle connector of the rear camera connection cable to the front camera (‘Rear’ port). Use the pry tool to lift the edges of the rubber window sealing and molding and tuck in the rear camera connectoin cable. Rear camera connection cable Connectivity Module (Optional-Sold Separately): Connect the connectivity module to the front camera and attach it to the edge of the window.
- Page 15 Note y To use battery saver feature, connect the BATT+ cable to the hazard light fuse. Functions of fuse differ by manufacturer or model. For details refer to the vehicle owner's manual. BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 15...
- Page 16 Connect the GND cable to metal ground bolt. Connect the power cable to the DC in terminal of the front camera. BlackVue will power up and start recording. Video files are stored on the microSD card. Tamperproof Case (Optional): Slide the tamperproof case on the side of the front camera.
- Page 17 (iv) Once sign-up process is done, you will be automatically logged into your account. If you want to connect to BlackVue Cloud with your account, skip to Connect to BlackVue Cloud. STEP 4 BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 17...
- Page 18 Add BlackVue dashcam to camera list via Seamless pairing. (i) Select Connect to camera in the main page. (ii) Make sure smartphone's Bluetooth is turned on and press +. (iii) Select Seamless pairing support model. (iv) Choose your BlackVue dashcam from the detected camera list. (v) Put your hand on the camera's touch sensor to complete Seamless pairing.
- Page 19 Dashcam SSID is printed in connectivity details label attached on your dashcam or inside the product box. (vi) Customize your camera name and press OK. (vii) BlackVue dashcam is now added to the camera list. BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 19...
- Page 20 Add BlackVue dashcam to camera list manually. (i) If you want to connect to camera manually, press connect to camera manually in the searching for camera page. (ii) Enter credentials (Printed in connectivity details label attached on your dashcam or inside the product box). 20 BLACKVUE...
- Page 21 Connect to BlackVue dashcam using Wi-Fi. (i) Click your camera name to connect your camera and smartphone using Wi-Fi. (ii) Select the video that you want to play from the video list. BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 21...
- Page 22 Playing video files on the web To experience the camera features in the Web Viewer, you must create an account and your dashcam must be connected to the Cloud. For this setup, it is recommended Connect to to download the BlackVue app and follow the instructions in STEP 4 BlackVue Cloud prior to accessing the Web Viewer.
- Page 23 To remove Insert the card into the microSD card reader and connect it to a computer. Download BlackVue Viewer program from www.blackvue.com > Support > Downloads and install it on your computer. BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 23...
- Page 24 Run BlackVue Viewer. To play, select a video and click on the play button or double click the selected video. Windows/macOS Viewer Note y The playback of 4K UHD resolution depends on your computer's hardware and software. Older computers may not support 4K UHD. If you encounter issues please check your computer's video playback capabilities.
- Page 25 Settings that can be changed include Wi-Fi SSID & password, image quality, sensitivity settings, voice recording on/off, speed unit (km/h, MPH, off), LEDs on/ off, voice guidance volume, Cloud settings etc. Once settings are configured, tap Save. BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 25...
- Page 26 Changing the dashcam's time zone and other firmware settings on your computer (Windows/macOS) Run BlackVue Viewer program after connecting dashcam's microSD card to your computer. Click on the button to open the BlackVue settings panel. Settings Settings that can be changed include Wi-Fi SSID & password, image quality, sensitivity settings, voice recording on/off, speed unit (km/h, MPH, off ), LEDs on/off, voice guidance volume, Cloud settings etc.
-
Page 27: Connect To Blackvue Cloud (Optional)
QR Code: Press Add camera manually and line up the QR Code on your smartphone's screen. Serial number QR code / Cloud code Input QR code manually: Enter your camera's Serial number and Cloud code and press Add camera. BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 27... - Page 28 Connect your BlackVue dashcam to a Wi-Fi hotspot for Cloud connectivity (i) Make sure your BlackVue dashcam and mobile Wi-Fi hotspot are on. (ii) After your camera is added, the app will give you the option to choose a cloud connection method. (iii) Select Wi-Fi hotspot.
- Page 29 "SIM activation guide" in the packaging box or visit BlackVue Help Center: www.helpcenter.blackvue.com -> LTE connectivity guide. (v) Once your dashcam is connected to the internet, you can go to the Connect to Cloud menu to use BlackVue Cloud features. BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 29...
- Page 30 Note y For full details, refer to the "SIM activation guide" that is included in the CM100GLTE package. y To use the BlackVue Cloud Service, SIM card must be properly activated for Internet access via LTE network. y When the dashcam is connected to internet, you can use BlackVue Cloud features such as remote Live View and Video playback, Real-time location, push notification, Auto-upload, remote Firmware update etc.
-
Page 31: Tips For Optimal Performance
Firmware updates will be made available for download at www.blackvue.com > Support > Downloads. Customer Support For customer support, manuals and firmware updates please visit www.blackvue.com You can also email a Customer Support expert at cs@pittasoft.com BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 31... - Page 32 Product specifications (BlackVue 7-1CH, 2CH): Model Name BlackVue 7-1CH l BlackVue 7-2CH Front: Black / Width 134mm x Height 40mm / 125g Color/Size/Weight Rear: Black / Width 69.4mm x Height 32mm / 32g Memory microSD Card (32 GB / 64 GB / 128 GB / 256 GB)
- Page 33 -20 °C − 80 °C (-4 °F − 176 °F) Temperature Storage -20 °C − 80 °C (-4 °F − 176 °F ) Temperature High Temperature Approx. 80 °C (176 °F) Cut-Off BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 33...
- Page 34 Front: FCC, ISED, CE, UKCA, RCM, RoHS, Telec, WEEE, KC Certifications Rear: FCC, ISED, CE, UKCA, RCM, RoHS, WEEE, KC BlackVue Viewer Software * Windows 7 or higher and Mac OS X Sierra (10.12) or higher Application BlackVue Application (Android 5.0 or higher, iOS 11.0 or higher) Others Adaptive Format Free File Management System *STARVIS is a trademark of Sony Corporation.
- Page 35 * Frame rate may vary during Wi-Fi streaming. Image Quality Highest (Extreme), Highest, High, Normal Video Compression Mode Wi-Fi Built-in (802.11 a.b.g.n.ac) Built-in (Dual Band : GPS, GLONASS) Bluetooth Built-in (V2.1+EDR/4.2) Microphone Built-in BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 35...
- Page 36 Speaker Built-in (Voice Guidance) Front: Recording LED, GPS LED, B/W/L (Bluetooth/Wi-Fi/LTE) LED Indicators LED, Front security LED Rear: 2 Rear Security LED (Front & Rear side) Touch sensor: Button Pressing the touch sensor triggers manual recording depending on the firmware settings. Sensor 3-Axis Acceleration Sensor Backup Battery...
- Page 37 BlackVue Application (Android 5.0 or higher, iOS 11.0 or higher) Others Adaptive Format Free File Management System *STARVIS is a trademark of Sony Corporation. Note y For 1CH user, if rear camera is added, refer to 2CH specification. BlackVue 7-1CH, 2CH l BlackVue 9-1CH, 2CH 37...
- Page 38 Notes...
-
Page 39: Product Warranty
The term of this product warranty is 1 year from the purchase date. (Accessories such as an External Battery/microSD Card: 6 Months) We, PittaSoft Co., Ltd., provide the product warranty according to the Consumer Dispute Settlement Regulations (drawn up by the Fair Trade Commission). PittaSoft or designated partners will provide the warranty service upon request. Warranty Circumstances... -
Page 40: Manufacturer Address
BlackVue 7-1CH, BlackVue 7-2CH: R-C-PTA-BlackVue7 R-R-PTA-RC1-IR FCC ID : YCK-BV7 / HVIN: BlackVue 7-1CH, BlackVue 7-2CH / IC: 23402-BV7 BlackVue 9-1CH, BlackVue 9-2CH: R-C-PTA-BlackVue9 R-R-PTA-RC1-IR FCC ID : YCK-BV9 / HVIN: BlackVue 9-1CH, BlackVue 9-2CH / IC: 23402-BV9 Product | Car Dashcam...
