Technical specifications
transceiver
*operating frequency
output power (EIRP)
* Other frequencie ranges may apply in certain countries
electrical, physical, and general
operating temperature
dimensions
mass
power supply
battery
camera
data interfaces
24.08 - 24.16 GHz (nominal)
24dBm +/- 3dBm USA 17dBm +/-3dBm EU
0°C to 40°C / 32°F to 100°F
6.8" x 1.2" x 4.6" / 174 x 31 x 118mm (W x D x H)
1lb / 465g
5V DC +/- 5%; >2 A
Rechargeable Li-ion Battery, 3.6V, 3500mAh 12.6Wh
5MP
USB 2.0
31
