Summary of Contents for FlightScope X3B
- Page 1 BASEBALL X3B SETUP GUIDE Per formance data you can trust...
- Page 2 A coin can be used to help fasten the tripod plate screw to the X3B. When in Wi-Fi mode, keep the distance from the PC to X3B to 20 feet or closer. Connect the PC to AC Power to prevent the PC from dying.
- Page 4 Absolute Minimum and Maximum Setback Distances Minimum 14’ 10” Maximum 50’ Game and Scrimmage Minimum 8’ 3” Maximum 50’ Bullpen Minimum 14’ 10” Batting Practice Maximum 50’ Maximum 50’ Live BP Minimum 14’ 10” General Guideline for Tripod Height Setup Setback Distance Radar Height <...
- Page 5 BULLPEN LIVE BP BATTING PRACTICE GAME AND SCRIMMAGE 14' 10" 8' 3" 14' 10" 14' 10" minimum minimum minimum minimum maximum maximum maximum maximum...
- Page 6 X3B Tripod Setup Step 1: Tightly screw tripod plate to bottom of the X3B. Plug in the Wi-Fi adapter to the top left USB port on the back of the X3B. Step 2: Adjust the tripod height by extending the legs and tripod head. Ensure a stable base by firmly tightening the tripod legs and head.
- Page 7 X3B Tripod Setup Step 5: Once connected to the X3B, select Session Type: Scrimmage, Game, Batting Practice, Bullpen, or Live BP. Step 6 - Radar Setup: Select Full Flight or Limited Flight and enter Field Dimensions. Default is set to 60’ 6”. Click Next.
- Page 9 Using the Leica Turn Leica on by pressing the ON button. Click the FUNC button. Use the arrow buttons to navigate to “Smart Horizontal Mode.” (Middle row, far right column) Press ON again to enter Smart Horizontal Mode. Click the Camera button on Leica. Place the rear of the Leica device on the tip of home plate and point the laser towards the radar’s internal camera.
- Page 11 Using the Leica...
- Page 12 For more help contact support@flightscope.com www.baseball.flightscope.com...
