Summary of Contents for FlightScope Mevo+
- Page 1 Mevo+ User Manual...
- Page 2 Performance data you can trust “FlightScope technology is developed to offer you performance data you can trust in your pursuit of excellence.” Henri Johnson - Founder & CEO...
-
Page 3: Table Of Contents
Contents Battery Warning Tips Performance tracking Indoor ball spin In the box Tee the ball Mevo+ E6 Connect Switch off Charging Battery indicators Electronic noise System indicators Care Get the app Avoid FAQ’s and support Connect to Mevo+ Via QR Code Technical specifications Manually (via Wi-Fi) FCC Statement... -
Page 4: Battery Warning
Battery warning CAUTION: This device contains a Li-ion battery. Do not expose to temperatures below freezing point. Do not expose to excessive heat. Avoid physical impact, puncture, crushing or dropping. If the unit is struck by a club or ball, a short circuit or other heat reaction may occur, resulting in a fire. Do not tamper with the battery pack. -
Page 5: Performance Tracking
Performance tracking Visit myFlightScope.com to analyze and track your data performance over time. myFlightScope.com Join the myFlightScope.com community and connect with fellow golfers like yourself. Keep track of your stats over time, spot trends or tendencies and see how you have improved. Please share your results and tag us on social media. -
Page 6: In The Box
In the box Mevo+ Case (Not to scale) Quickstart guide Power adapter USB charging cable Aluminum stickers (Only needed for indoor use) -
Page 7: Mevo
Mevo+ Indicators USB charging port Alignment camera On / Off button Kickstand 5000 mAh Battery (under rubber band) Tripod mount (bottom of the unit) Serial Sticker (includes QR code for connection) -
Page 8: Charging
Power and charging 4hrs for a full charge using the supplied adapter. 5000mAh External FlightScope battery packs available in shop on flightscopemevo.com... -
Page 9: Battery Indicators
Battery and charging indicators Charging error (Battery too hot or cold to charge, or battery is not connected properly) Battery Powered Charging 0-25% above 75% 25-50% above 50% 50-75% above 25% 75-100% above 10% Full under 10%... - Page 10 Externally Powered External & battery power (Battery not charging) (External power is not sufficient to power system) 0-25% 0-25% 25-50% 25-50% 50-75% 50-75% 75-100% 75-100%...
-
Page 11: System Indicators
System indicators Radar Status Power on, switching on Processor start up 30-60 seconds Standby mode Connection Status Armed, ready to measure Ready Triggered Connected Sleep Communication Error Processor shut down 15-30 seconds Battery empty Firmware error... -
Page 12: Get The App
Get the app Download and install the FS Golf app. Scan the QR code on the bottom of the box This will direct you to the FlightScope applications page. Please choose the FS Golf app. -
Page 13: Connect To Mevo
Connect to Mevo+ (via QR Code) Press and hold until the unit beeps Wi-Fi on Switch on Launch FS Golf app The username and password you setup will be the same for myflightscope.com... - Page 14 Connected In app, scan QR code on back of unit...
-
Page 15: Manually (Via Wi-Fi)
Connect manually (via Wi-Fi) If you are unable to connect using the QR code, then you can connect manually in your device settings. Follow these easy steps: Make sure your phone’s Wi-Fi is turned on. Press the on/off button on the unit, the system and battery lights will come on. The connection light will be solid blue while the unit is ready for connection. -
Page 16: Kickstand
Kickstand Open the Kickstand before placing. Do not over extend the kickstand or force it past it’s open position, The kickstand will stop at open position. With the kickstand open, this can cause damage to your unit. the radar will be at the correct tilt angle on a flat surface. -
Page 17: Setup
Setup - Setback OUTDOOR LIMITED FLIGHT Aluminum stickers NOT required. Aluminum stickers required. Aluminum stickers not required if using Titleist RCT golf balls. Unrestricted ball flight 13’ (4m) min. 7’-9’ (2.1m-2.7m) 8’ (2.4m) sensor to tee sensor to tee... -
Page 18: Aiming
Aiming Place the Mevo+ behind the ball position so that the In the App, follow the instructions using the camera view to align. camera aims along the chosen target line. Adjust the position and aim so that the vertical line on the camera view passes through the ball and is aligned with the target. -
Page 19: Clearance
Clearance Keep area between Mevo+ and the ball position clear of any objects and people. KEEP CLEAR... -
Page 20: Tips
Tips Best practice is to keep the unit on the floor with a level surface between the unit and the mat. Hitting Surface Ground surface Maximum Height: 3’’ (76mm) - Page 21 For putting, keep the ball and unit on an even flat surface. For putting, chipping and hitting never raise the Mevo+ to match the ground level.
- Page 22 Extremely low and wide shots, and shots where the player is between the Mevo+ and the ball, might not register.
-
Page 23: Indoor Ball Spin
Indoor ball spin For the best spin accuracy indoors, place a reflective sticker on the ball. Reflective stickers are for indoor use only. To order additional stickers: go to flightscopemevo.com/collections/mevo-accessories... -
Page 24: Tee The Ball
Tee the ball Place the ball so that the sticker faces forward, directly away from the Mevo+. Sticker facing towards target... -
Page 25: E6 Connect
Mevo+ to another person in future.) you decide to sell your Mevo+ to another person in future.) Register a FlightScope Mevo+ account on the iOS/ Android FS Register a FlightScope Mevo+ account on the iOS/ Android FS Golf app or Windows FS Golf PC app. -
Page 26: Switch Off
Switch off Press and hold to turn off, unit will beep to confirm. When all indicators are off, the unit is off. -
Page 27: Electronic Noise
Electronic noise Mevo+ is designed to operate in most environments. However certain appliances and equipment can create noise that can interfere with resulting shots. Some common noisy objects are: aircon fluorescent fans tv’s, laptops & fridges signal lights towers desktop computers in front of the Mevo+... - Page 28 Keep area clear of possible noise interference. Make sure to move noisy electronic devices behind the unit.
- Page 29 Noisy electronic devices in front of the unit may cause poor tracking performance. Flourescent...
-
Page 30: Care
Care Clean with a damp cloth and light Store in the case household detergent... -
Page 31: Avoid
Avoid Flames and Moisture, including rain direct heat Excessive weight loading Physical impact Solvent Chemicals Water immersion... -
Page 32: Faq's And Support
FAQ’s and support Below are the top 5 frequently asked questions. For more FAQ’s please refer to flightscopemevo.com/faq 1. Can Mevo+ be used indoors and outdoors? Yes. Please check page 13 for indoor space requirements. 2. Does a reflective sticker need to be used? Yes, for indoor use only. -
Page 34: Technical Specifications
Technical specifications transceiver *operating frequency 24.08 - 24.16 GHz (nominal) output power (EIRP) 24dBm +/- 3dBm USA 17dBm +/-3dBm EU * Other frequencies ranges may apply in certain countries electrical, physical, and general operating temperature 0°C to 40°C / 32°F to 100°F dimensions 6.8"... - Page 35 172mm 33mm 118mm...
-
Page 36: Fcc Statement
— Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by FlightScope (PTY) could void the user’s authority to operate the equipment. ISED Statement: This device contains licence-exempt transmitters(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). - Page 37 Performance data you can trust www.flightscope.com...
