Hybe
A S S EM BLY INS TRU CT IO N 039220
For more information, please visit efg.se.
Assemble the armrests/side tables
Position the armrest(s) by sliding
them into the tubes underneath
the seat(s).
Secure them by screwing the M6x20
mm screws through the tubes into
the armrest(s), 4 screws/armrest.
Assemble the armrest top(s)
by screwing the M6x20 mm screws in the
T-nuts from underneath. NOTE! If you are
adding screens, don´t tighten the screws
until the screens are added.
The product contains one or more
of following materials: Metal, plastic,
039220 EFG Product development
wood, fabric, foam.
1(2)
