Summary of Contents for EFG Active
- Page 1 EFG Active Assembly Instruction 039115 The product contains one or more of following materials: Metal, plastic, wood, fabric, foam. For more information, 039115/ Produced by: EFG Marketing Support please visit www.efg.info...
- Page 2 EFG Active - Frame assembly EFG Active - Frame assembly Step 1 - Assembly beams, legs, hooks, spacer and decal. Step 2 - Assembly foot and sidebars. Recommended beam length for following table top length: 1600 = Beam length 1248 mm (Overhang on table according to page 7)
- Page 3 EFG Active - Frame assembly EFG Active - Frame assembly Step 3 - Assembly frame to table top. Step 4 - Assembly cables and handset. Loosen screws slightly in beams and adjust frame width symmetric to Structure excess cabling under the table top, use the cable clips to wished position (Do not loosen the screws entirely) strap the cables.
- Page 4 EFG Active - Frame assembly EFG Active - Acessories (Gables) Step 5 - Observe and finish. Below you can see recommended distance to table top edge on gables for enabling other acessories to be added. 120 mm SUITED ACESSORIES: - TAB Screens (Ex: A29F01)
- Page 5 EFG Active - Sliding top (without screen) EFG Active - Sliding top (without screen) Exploded overview of the different parts used for a sidebar with sliding Start with doing steps 1 and 2 from Frame assembly (Page 2 and 3).
- Page 6 EFG Active - Sliding top (with screen) EFG Active - Sliding top (with screen) Exploded overview of the different parts used for a sidebar with sliding Start with doing steps 1 and 2 from Frame assembly (Page 2 and 3).
