Comparison with the AN-X2

If you are familiar with the AN-X2, or are replacing an AN-X2 with an AN-X4, you should be
aware of the following:

The power and Data Highway Plus cables are the same, but may need to be rotated 180
degrees.

The configuration files are similar but are saved in different locations on the microSD
card

The web interface is improved

The errors displayed on the LEDs have changed

You can run different versions of the same firmware, e.g., Data Highway Plus firmware,
for example for debugging

As shipped, searches for a DHCP IP address at startup for 10 seconds, then reverts to
static IP address 192.168.0.246

Case is smaller
