Updating The Firmware - ProSoft Technology AN-X4-AB-DHRIO User Manual

54 AN-X4-AB-DHRIO (DH+)
Page
The AN-X4 firmware files are supplied in files that begin with AN-X4 and have extension qtf.
AN-X4 can have multiple versions of the same firmware, for example, different versions of the
the Data Highway Plus qtf. You can use the web interface to:

download firmware files to the AN-X4

select which version is to run

remove firmware files using the web interface.
Run the command Administration/Select AN-X Firmware to select the file you wish to run.
WARNING!
You must restart the AN-X4 to run the firmware that you selected or transferred to the AN-X.
WARNING!
You can also copy firmware files to the directory /Firmware on the microSD card using a card
reader in your computer. If you do so, you will also need to update the file FirmwareCfg.txt in the
same directory to run the file you copied over. The contents of FirmwareCfg.txt must match
exactly the name of one of the firmware files on the AN-X, including the version.
Example
AN-X4-AB-DHP.v4.12.54.qtf
Do not update firmware to the AN-X while applications that use the
AN-X are running.
It is essential that you do not disrupt power while updating firmware,
especially maintenance firmware, to the AN-X4 or while the AN-X4 is
restarting following a firmware update.
Interrupting power at some points in the update process could render the
AN-X inoperative and it would have to be returned to the factory for
reinitialization.

Updating the Firmware

Nov 2022
