8 AN-X4-AB-DHRIO (DH+)
Page

Package Contents

•
AN-X4-AB-DHRIO module
• Phoenix Power and Data Highway Plus connectors

Using the MicroSD Card

The AN-X4 microSD card stores configuration data and firmware.
There are no restrictions on the size or speed of the card. The format must be FAT-16 or FAT-32.
The microSD card must be present while the AN-X4 is running.
WARNING!
There are several configuration files on the SD card.
Function
Ethernet configuration
Data Highway Plus Configuration
Alias Configuration
Router Configuration
Firmware to run
All files should be created and editied with a plain text editor such as Windows Notepad.
If the AN-X4 is inaccessible from Ethernet because of its settings, or is in an unknown state, you can
power down the AN-X4, remove the microSD card and edit the file IPConfig.txt. Refer to page 14
for details.
When you have finished editing the file, reinsert the card in the slot at the back of the AN-X4 and
restart the AN-X4.
WARNING!
Do not remove the microSD card while the AN-X4 is powered on!
File
IPCfg\IPConfig.txt
Dhp\AnxDhpCfg.txt
Dhp\AnxDhpCfgHmiAlias.txt
Dhp\AnxDhpCfgRouter.txt
Firmware\FirmwareCfg.txt
If you remove the card to edit the configuration file, push the card in
straight or the card might fall inside the case and you will have to
disassemble the AN-X4 to retrieve it .
