- Page 1 Installation Manual for CL-65e...
-
Page 2: Table Of Contents
Table of Contents Safety Information ..................................Pg. 3 Parts List ....................................... Pg. 4 Warranty Information ................................Pg. 5 Return Policy ....................................Pg. 6 Installation ....................................Pg. 7 Paneling & Cable Management ..............................Pg. 10 TV Mounting ....................................Pg. 16 Adjustments & Fine Tuning ................................. Pg. 19 Version: 1.1.1 Date:... -
Page 3: Safety Information
Disclaimer: Nexus 21 disclaims any liability for modifications, improper installations, or installations over the specified weight range. Nexus 21 will not be liable for any damages arising out of the use of, or inability to use, Nexus 21 products. Nexus 21 bears no responsibility for incidental or consequential damages. This includes, but is not limited to, any labor charges for the servicing of Nexus 21 products performed by anyone other than Nexus 21. -
Page 4: Parts List
Parts List CL-65e Lift System (Bottom View) Installation Hardware Pack Contents (16) #10 - 32 x 1-1/4” FHMS (4) #8 x ¾” FHWS (1) 14” Long T-Handle (16) #8 x 1-1/4” BHWS Square Drive (4) 3/8” x 2.5” Lag Bolt (1) 5/16 Hex 6”... -
Page 5: Warranty Information
In the event that you do need a replacement part or system, we’ll ship it to you right away, along with a prepaid UPS return shipping label and a package for the defective part or system to be returned to our offi ce. Nexus 21 will cover the shipping cost of the replacement part or system within the continental United States and Canada (excludes Hawaii, Alaska and Puerto Rico). -
Page 6: Return Policy
Within 30 Days of Delivery: Customers may return a Nexus 21 product(s) for any reason within 30 days of the date it is received for a full refund of the purchase price. Shipping charges associated with your order are not eligible for refund. To initiate a product-return request, please review the following conditions: •... -
Page 7: Installation
Installation The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. - Page 8 1. Raise your system into the ceiling and fasten it to your trusses, joists, all-thread, etc. using either of the mounting methods shown above. Important Note: Do not lift the system from the Inner Frame (shown in red) as this will cause damage to the motors.
- Page 9 Alternate Control Panel Location Power Port 2. Connect the Power Cord to the Control Box and lower the Lift System by pressing the “Down” button on the Wired Backup Switch. If necessary, press “Up” at any time to stop. Ensure the Wired Backup Switch remains accessible at all times during and after installation. If necessary the Wired Backup Switch can be extended using a coupler and standard CAT Cable.
-
Page 10: Paneling & Cable Management
Paneling & Cable Management The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. - Page 11 3. Remove the (4) Phillips Screws below the Cable Cover, then loosen the top (4) Phillips Screws and slide the Cable Cover up and off. Note: Leave the top (4) Phillips Screws in place, do not remove them as they will help relocate the Cable Cover when you put it back on.
- Page 12 = Remove these Screws = Loosen these Screws 4. Using the image above, remove the screws indicated by a circle and loosen the screws indicated by a diamond, then slide each of the panels up to remove them. Note: If you are unable to access these screws, press and hold the “Down’ button on the Wired Backup Switch for 5 seconds to initialize the system.
- Page 13 Top of Sub Frame Through-Bolt x 12 Wood-Screws x 12 x 12 5. Align your Flip-Down Panel with the Top of the Sub-Frame, center it, then fasten it to the Sub-Frame using either of the mounting methods listed below: Through-Bolt: Mount your Flip-Down panel using (12) #10-32 x 1.25” FHMS Screws to through-bolt it to the Sub-Frame from the back side. Wood Screw: Mount your Flip-Down panel to the Sub-Frame using (12) #8 x 1.25”...
- Page 14 6. Route your cables along the path indicated in the image above. Several Cable Straps are provided along the way to secure your cables in place. Note: If needed, your cables can also be routed to the left side of the lift system by passing the cables behind the Actuator and through the other side.
- Page 15 7. Ensure you have enough cable slack to connect your AV Cables then replace the (3) Cover Panels followed by the Cable Cover. Note: The Cable Cover must go on last. Replacing it first will obstruct the placement of the other panels...
-
Page 16: Tv Mounting
TV Mounting The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. - Page 17 8a. Attach the Vertical Mounting Bars to the back of your TV using the provided Assorted TV Hardware Pack. 8b. Place the Screen Locks into one of the three hooks on each of the Vertical Mounting Bars and secure them by tightening both Philips Screws. Note: 3 sets of hooks are available on the Vertical Mounting Bars to allow adjustment to the Vertical Position of your TV.
- Page 18 9. Adjust the vertical position of your Screen Back Plate, hang your TV on the it, then connect all AV cables ensuring enough slack is available. Once the cables are connected, center your TV, then secure it to the Screen Back Plate by tightening the Hex Screw on the Screen Locks.
-
Page 19: Adjustments & Fine Tuning
Adjustments & Fine Tuning The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. - Page 20 Fine Adjustment Screw Tighten the Fine Adjustment Screw to raise the Flip-Down Panel Socket Cap Screws Loosen the Fine Adjustment Screw to lower the Flip-Down Panel Socket Cap Screws Tighten the Socket Cap Screws when the Flip-Down Panel is Flush 10a.
- Page 21 Flip-Down Panel Trim Panels 1/4” Gap 11. Size your Trim Panels or bring the surrounding ceiling in, so there is a 1/4” gap between them and the Flip-Down Panel.
- Page 22 Your installation is now complete, reference the documentation contained in your lift system controls for information regarding Controls and Integration.
- Page 23 (Intentionally Left Blank)
