Summary of Contents for Nexus 21 CL-65e
- Page 1 CL-65e Installation Manual...
- Page 2 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs.
-
Page 3: Table Of Contents
The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. Table of Contents Safety Information ................................Pg. 2 Parts List ....................................Pg. 3 Before you Begin ................................Pg. 4 Installation ................................... Pg. 6 Cable Management & Paneling ............................Pg. 9 TV Mounting .................................. -
Page 4: Safety Information
Nexus 21 disclaims any liability for modifications, improper installations, or installations over the specified weight range. Nexus 21 will not be liable for any damages arising out of the use of, or inability to use, Nexus 21 products. Nexus 21 bears no responsibility for incidental or consequential damages. This includes, but is not limited to, any labor charges for the servicing of Nexus 21 products performed by anyone other than Nexus 21. -
Page 5: Parts List
The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. Parts List: Front Rear Bottom CL-65e Lift System Installation Hardware Pack (4) 3/8” x 2.5” Lag Bolt (16) #10 - 32 x 1-1/4" FHMS (4) 3/8” Flat Washer (16) #8 x 1-1/4"... -
Page 6: Before You Begin
The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. Before you Begin... - Page 7 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs.
-
Page 8: Installation
The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. Installation... - Page 9 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. 1. Raise your system into the ceiling and fasten it to your trusses, joists, all-thread, etc. using either of the mounting methods shown above. Important Note: Do not lift the system from the Inner Frame (shown in red) as this will cause damage to the motors.
- Page 10 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. Wired Backup Switch 2. Connect the Power Cord to the Control Box and lower the Lift System by pressing the “Down” button on the Wired Backup Switch. If necessary, press “Up” at any time to Stop it.
-
Page 11: Cable Management & Paneling
The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. Cable Management & Paneling... - Page 12 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. 3. Remove the (4) Phillips Screws below the Cable Cover , then loosen the top (4) Phillips Screws and slide the Cable Cover up and off. Phillips Screws Cable Cover Note: Leave the top (4)
- Page 13 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. See Note 4. Using the image above, remove the screws indicated by a circle and loosen the screws indicated by a diamond, then slide each of the panels up to remove them. Note: If you are unable to access these screws, press and hold the “Down’...
- Page 14 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. #2 Square Drive 5. Align your Flip-Down Panel with the Top of the Sub-Frame, center it, then fasten it to the Sub-Frame using either of the mounting methods listed below: Through-Bolt: Mount your Flip-Down panel using (12) #10-32 x 1.25”...
- Page 15 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. 6. Route your cables along the path indicated in the image above. Several Cable Straps are provided along the way to secure your cables in place. Note: If needed, your cables can also be routed to the left side of the lift system by passing the cables behind the Actuator and through the other side.
- Page 16 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. 7. Ensure you have enough cable slack to connect your AV Cables then replace the (3) Cover Panels followed by the Cable Cover. Note: The Cable Cover must go on last replacing it first will obstruct the placement of the other panels.
-
Page 17: Tv Mounting
The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. TV Mounting... - Page 18 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. 8a. Attach the Vertical Mounting Bars to the back of your TV using the provided Assorted TV Hardware Pack 8b. Place the Screen Locks into one of the three hooks on each of the Vertical Mounting Bars and secure them by tightening both Philips Screws. Note: The 3 sets of hooks on the Vertical Mounting Bars allow you to adjust the Vertical Position of your TV when you hang it on the system.
- Page 19 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. 9. Adjust the vertical position of your Screen Back Plate, hang your TV on the it, then connect all AV cables ensuring enough slack is available. Once the cables are Hex Screw connected, center your TV, then secure it to the Screen Back Plate by tightening the on the Screen Locks.
-
Page 20: Adjustments & Fine Tuning
The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. Adjustments & Fine Tuning... - Page 21 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. 10a. Raise the system into the ceiling to determine whether your Flip-Down Panel is too high or too low. 10b. Loosen the Socket Cap Screws then use the Fine Adjustment Screws to adjust the position of your Flip-Down Panel. Reference the image above. 10c.
- Page 22 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. Flip-Down Panel 1/8” Gap Ceiling/Trim Panels 11. Size your Trim Panels or bring the surrounding ceiling in, so there is an 1/8” gap between them and the Flip-Down Panel. Important Note: Reference the Dimensional Drawing found on the next page for additional information.
- Page 23 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs. Your installation is now complete, reference the manual provided with your remote controls for information regarding integration and system setup.
- Page 24 The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs.
