BEFORE YOU BEGIN 安装之前 All information is based on the latest product information available at the time of publication. Kohler Co. reserves the right to make changes in product characteristics, packaging, or availability at any time without notice. Please leave these instructions for the consumer.
Page 2
注意事项 Notes: Flush the water supply pipes thoroughly to remove debris. Faucet is designed for tap water or potable water. Do not strike the faucet with rough strength to avoid being damaged and failure. 3. Do not damage the surface of sensing window when installing or cleaning the faucet.
2. Install Faucet 二 安装龙头 2. Move a distance of the escutcheon forward 3. Secure 装饰盖(3) 1451063-T01-B...
Page 6
3.Fasten control valve assembly 三 控制阀组件的安装固定 Unscrew valve cover screws (4) by 拧松 screwdriver, open valve cover (5). Determine control box assembly (6) installation location per rough-in; then drill holes, and punch plastic expansion tube (10) in. Place valve box against the wall and then mount control valve assembly on the wall by expansion screws (11).
Page 7
Connect to Connect to Connect to Connect to Faucet electrical Source electrical Source Faucet 接交流电源 接交流电源 AC220V接入直流DC接线端。 Note: Not allowed connect AC 220V electrical source to DC wire connector of AC/DC transformer 注: 交流电源盒需另购。 Note: AC/DC transformer need to buy separately. 1.
Page 8
电源盒组件 Power unit assebly 1. Assemble AC or DC power unit 1. 将交流或直流电源盒组件放入 assembly into control box. 控制盒内。 2.Cabing and tidying wires such as 2.如图所示,将电源线,龙头感应器线 power wire assembly,senor wires 及电磁阀线与相应的接线端相连 assembly and solenoid wire assembly 接。然后整理好线束并锁紧控制盒 to right position. Then lock the control box.
Page 9
(2) 香港版 (2) Hongkong Version 型号: EX27462H-NW-CP等 SKU: EX27462H-NW-CP,etc Screw off the drain flange (20) from drain. 旋下排水器盘片(20)在其底面沿周 Apply a ring of plumbers putty around 围涂上一圈密封油灰。把排水本 underside of the drain flange (20).Insert 体(21)由底下插入面盆。 the drain body (21) into the lavatory from Apply plumbers putty the underside.
Note: Please let users prepare the hose and tee by themselves. 注:软管、三通请用户自备。 It is recommended to use Kohler TEE inlet hose assembly, 建议使用科勒推荐的三通进水软管 otherwise there is a risk of cold and hot water mixing problem. 组件,否则有冷热水互窜的风险。 HOW TO CHANGE TO THERMOSTATIC SENSOR 如何转换成恒温阀感应龙头...
Page 14
: Indicate only partial product series contains this substance. Note: the information provided is based on the supplier data and Kohler inspection results. The product is designed not to hurt the environment. Under current technology, all hazardous materials have been used in the smallest amounts possible. Kohler will strive to reduce the use of these hazardous materials used in this product.
