Universal Screens
Installation Instructions
Tools Needed:
1/8" Allen Wrench
Drill
Tape Measurer
#2 Phillips Driver
1/4" Hex Driver
Driver Extension
Index
Screen Overview
U - Bracket Installation
1 . Side Mount Lateral
2 . Front to Back Lateral
3 . Top Mount Lateral
4 . Elevated
(HUSUPMB1 | HUSUPMB2)
5 . Sit on Surface
6 . Empower
(HUSEMPB1 | HUSEMPB2)
7 . Gravitation
(HUSGRVB1)
Above/Below Screens
Gravitation Modesty Screen - Fabric
Gravitation Modesty Screen - Hard Surface
Gravitation Screen - PET
Modesty Screens
Alignment Clip Installation
Hardware Chart
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
1430120100_A
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
(HUSFSMB1 | HUSFSMB2)
(HUSLATB1 | HUSLATB2)
(HUSTOPB1 | HUSTOPB2)
(HUSSOSB1 | HUSSOSB2)
(HUSABMB1 | HUSLABF27## | HUSFABF#### | HUSAABF27##)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
(HUSGRVB5)
(HUSFMOD13## | HUSLMOD13## | HUSMODB1)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
(HUSGRVB2)
. . . . . . . . . . . . . . . . . . . . . . . . . .10
(HUSGRVB3)
. . . . . . . . . . . . . . . . . . . . . . . . . 11-12
. . . . . . . . . . . . . 7-8
Muscatine, Iowa 52761-0071
www.hon.com
07/2022

Advertisement

loading
Need help?

Need help?

Do you have a question about the Universal Screens and is the answer not in the manual?

Questions and answers

Related Manuals for HON Universal Screens

Summary of Contents for HON Universal Screens

  • Page 1 Universal Screens Installation Instructions Tools Needed: 1/8” Allen Wrench Drill Tape Measurer #2 Phillips Driver 1/4” Hex Driver Driver Extension Index Screen Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 U - Bracket Installation .

  • Page 2: Screen Overview

    Universal Screens Installation Packet Screen Overview NOTE: Not all configurations shown. Side Mount Lateral Top Mount Lateral Front to Back Above/Below Acrylic Modesty Gravitation Fabric Gravitation Laminate/ Modesty Acrylic Modesty NOTE: Most Universal Screen Bracket types include a U-Bracket sub assembly (shown to the right).
  • Page 3 Universal Screens Installation Packet U-Bracket Installation NOTE: Steps 1 - 7 are applicable to all U bracket models unless otherwise noted. Verify that set screws are flush or subflush with inside face of bracket . Step 1 - Loosen set screws using 1/8” Allen wrench if necessary. Ensure that set screws are flush or sub flush from the inside face of the bracket .
  • Page 4 Universal Screens Installation Packet U-Bracket Installation (Continued) Select the appropriate Step 3 below for your specific bracket type. Model numbers listed as reference. Side Mount Lateral Front to Back Lateral HUSFSMB1 HUSLATB1 HUSFSMB2 HUSLATB2 Step 3a - Align Bracket on surface and tighten (2) bottom set screws per Step 3a - Align Bracket on surface and tighten (2) bottom set screws per bracket with 1/8”...
  • Page 5 Universal Screens Installation Packet U-Bracket Installation (Continued) Elevated Sit on Surface HUSUPMB1 HUSSOSB1 HUSUPMB2 HUSSOSB2 Urethane Step 3a - Attach 2 urethane pads to the bottom of each bracket in the approximate location shown . Step 3a - Secure to surface using (4) #10 x 7/8” Hex Head wood screws per bracket .
  • Page 6 Universal Screens Installation Packet U-Bracket Installation (Continued) Gravitation HUSGRVB1 Kerf Line Step 3a - Lower brackets onto beam . Bend along kerf line until holes are Step 3b - Secure brackets using (2) #8-32 x 3/4” Thread Cutting screws aligned on the bottom of the beam .
  • Page 7 Universal Screens Installation Packet Above/Below Screens Adjustable Fabric Screens HUSABMB1 Step 1 - Slide brackets on both ends of the screen Step 2 - Position the screen in the desired location in desired location and secure by turning on the worksurface . Attach mounting the thumb screw clockwise .
  • Page 8 Universal Screens Installation Packet Above/Below Screens (Continued) Laminate Screens HUSLABF27## NOTE: Ensure correct screw is used for each step as to not damage screen Step 1 - Attach (2) Brackets at pilot holes in Laminate Panel using (6) #10 x 3/4” Hex Head Screws (H) per bracket .
  • Page 9 Universal Screens Installation Packet Create Gravitation Modesty Screen- Fabric | HUSGRVB2 NOTE: Do not overtighten screws as to not damage screen 1-3/4” Step 1 - Mount small U brackets to the bottom of the fabric screen so that the edge of the bracket coincides with the edge of the corner radius (1-3/4”...
  • Page 10 Universal Screens Installation Packet Gravitation Modesty Screen - Hardsurface | HUSGRVB3 Thread pin into button as shown Step 1 - Attach U brackets to underside of Gravitation beam using (2) #8-32 x 3/4” Thread Cutting Screws per bracket . Step 2 - Install pins into two of the round buttons . Slide the modesty panel up into the U channel until the holes are aligned and feed the pin through the U bracket and modesty panel until it protrudes from the opposite side .
  • Page 11 Universal Screens Installation Packet Create Modesty Screens Fabric Screens HUSFMOD13## Step 1 - Position panel in desired location. Attach first bracket and then look down the edge of the modesty panel to verify that it is straight before securing the second bracket. If the panel appears bowed, adjust the placement of the second bracket to straighten it out .
  • Page 12 Universal Screens Installation Packet Modesty Screens (Continued) Acrylic Modesty HUSMODB1 NOTE: Do not overtighten screws as to not damage screen Note: Verify straightness of screens Step 1 - Attach mounting brackets to screen using (2) #8 X 1/2” pan head screws and (2) washers per bracket .

  • Page 13: Hardware Chart

    Universal Screens Installation Packet Create Hardware Chart 1/4-20 UNC Thread 1/8” Hex Set Screw 3500106500 #8 x 7/8” Hex Head Screw 0500256000 #10 X 1” Flat Head Screw 3500005000 #8-32 X 3/4” Thread Cutting Screw 3500005000 #12-8 X 1” Phillips Pan Head Screw 3500081400 #8 X 1/2”...
