Assembly Instructions
Caution : You should read this carefully before you proceed
Please look in the third support leg for hardware packs
Parts List
Label
A
B
C
D
E
F
G
H
I
J
K
L
Bed
Second Side Rail
First Support Bar
Second Support Bar
First Support Leg
First Slat Frame
Second Slat Frame
Second Support Leg
Noble House Home Furnishings LLC
Description
Headboard
Right Leg
Left Leg
Footboard
First Side Rail
QTY
1
1
1
1
2
2
1
1
2
1
1
5
Page 1 OF 8
Advertisement
Table of Contents
Related Manuals for Noble House Home Furnishings Bed
Summary of Contents for Noble House Home Furnishings Bed
- Page 1 Description Headboard Right Leg Left Leg Footboard First Side Rail Second Side Rail First Support Bar Second Support Bar First Support Leg First Slat Frame Second Slat Frame Second Support Leg Page 1 OF 8 Noble House Home Furnishings LLC...
- Page 2 Bolt (M8 x 25 mm) ③ Bolt (M6 x 25 mm) ф ④ 4 x25 mm Screw ( ⑤ Allen Key (K5) ⑥ Allen Key (K4) ⑦ Connection Metal ⑧ Screwdriver (not provided) Page 2 OF 8 Noble House Home Furnishings LLC...
- Page 3 FRONT FACING Footboard (D) This Bed has multiple parts and may require up to some 30 minutes to assemble. To give you an overview of the Bed parts, the above picture is provided to help you put the various parts into perspective.
- Page 4 Bolts (②) and the Allen Key (⑥) as shown above. Repeat the same process with the remaining First Side Rail (E) and the Second Side Rail (F). Do not fully tighten the Bolts at this stage. Page 4 OF 8 Noble House Home Furnishings LLC...
- Page 5 With the help of your adult partner, attach the Footboard (D) to the frame from step 4, then secure it using Bolts (①) and the Allen Key (⑤) as shown above. Do not fully tighten the Bolts at this stage. Page 5 OF 8 Noble House Home Furnishings LLC...
- Page 6 7.2 The Second Support Bar (H) to under the First Slat Frame (J) using Bolts (③) and the the Allen Key (⑥) as shown above. Do not fully tighten the Bolts and screws at this stage. Page 6 OF 8 Noble House Home Furnishings LLC...
- Page 7 9.2 First Slat Frame (J) to the Second Side Rail (F) using Screw (④) and a Screwdriver (not provided) as shown above. . Do not fully tighten the Bolts and screws at this stage. Page 7 OF 8 Noble House Home Furnishings LLC...
- Page 8 With assistance from your adult partner, adjust the levellers to the desired height to avoid wobbles. To adjust the Levellers, get assistance from an adult partner to lift/lean and hold the Bed while you are working. Your Bed is ready for use.
