- Page 1 Caution: You should read this carefully before you proceed Barstool Part List Label Picture Description Backrest (with Legs) Left Armrest (with Leg) Right Armrest (with Leg) Foot Rest Seat Panel Hardware Noble House Home Furnishings LLC Page 1 OF 8...
- Page 2 Label Picture Description Bolt (M6*20mm) ① Bolt (M6*40mm) ② Bolt (M6*65mm) ③ Washer ④ ⑤ Allen Key ⑥ Assembly Preparation Before Beginning Assembly: Assembly Steps Noble House Home Furnishings LLC Page 2 OF 8...
- Page 3 Foot Rest (D) FRONT FACING This Barstool has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Barstool parts, the above picture is provided to help you put the various parts into perspective.
- Page 4 Place the Right Armrest(C) on the clean, non-marring surface. Using the Allen Key(6), attach the Seat Panel(E) to the Right Armrest(C) with Bolts(2) and Washers( 4 ) as shown above. Do not fully tighten the Bolts. Noble House Home Furnishings LLC Page 4 OF 8...
- Page 5 Right armrest(C) facing upwards. Attach the Left Armrest(B) to the Seat Panel(E) with Bolts(2) and Washers( 4 ), using the Allen Key(6) as shown above. Do not fully tighten the Bolts. Noble House Home Furnishings LLC Page 5 OF 8...
- Page 6 Turn the stool on its back by placing the Backrest(A) on the clean, non-marring surface. Attach the Foot Rest(D) to the Backrest(A) with Bolts(1) and Washers( 4), using the Allen Key(6) as shown above. Do not fully tighten the Bolts. Noble House Home Furnishings LLC Page 6 OF 8...
- Page 7 Keep your feet and toes well away from the drop zone. Drop the Barstool freely and vertically with the four legs hitting the ground at the same time. This Drop Test will help to ensure that all the Bolts and gaps all reach full alignment status.
- Page 8 Step 10 Left Armrest(B) Armrest Right Your Barstool is ready for use. This Barstool should only be used on a flat, level surface. Noble House Home Furnishings LLC Page 8 OF 8...
