Assembly Instructions
Caution: You must read this before you proceed
Please look in the Leg Frame for Hardware packs
Barstool
Caution: This Barstool is NOT a TOY.
Keep your child/children at bay during the assembly process.
Whenever moving/lifting the Barstool and to prevent any possible damage to it,
two adults are required to execute these actions.
Noble House Home Furnishings LLC
1
Advertisement
Table of Contents
Related Manuals for Noble House Home Furnishings Barstool
Summary of Contents for Noble House Home Furnishings Barstool
- Page 1 Caution: This Barstool is NOT a TOY. Keep your child/children at bay during the assembly process. Whenever moving/lifting the Barstool and to prevent any possible damage to it, two adults are required to execute these actions. Noble House Home Furnishings LLC...
- Page 2 Part List Label Picture Description Seat Panel Leg Frame Leg Support Bar Seat Support Bar Hardware Label Picture Description Screw ① (M6x45mm) ② Bolt (M6x15mm) ③ Bolt (M6x45mm) Washer ④ (M6.5/16x1mm) ⑤ Allen Key Noble House Home Furnishings LLC...
- Page 3 Assembly Preparation Before Beginning Assembly: Noble House Home Furnishings LLC...
- Page 4 This Barstool has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Barstool parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 5 Align the Leg Support Bar(D) to the Leg Frame(B) as shown in the above picture. Attach the Leg Support Bar(D) to the Leg Frame(B) using 4 Bolts(②), 4 Washers(④) and the Allen Key(⑤) as shown in the above picture. Do not fully tighten Bolts. Noble House Home Furnishings LLC...
- Page 6 Place the Seat Panel(A) onto a table or a box as shown in the above picture. You will have the Barstool bottom and legs facing up. Attach the Leg Frame(B) to the Seat Panel(A) using 4 Bolts(③) and the Allen Key(⑤) as shown in the above picture.
- Page 7 Inspect it and make sure all parts are adequately connected. Carefully sit onto the Barstool. This pressure will help align all parts at all joints. Then get off the Barstool and proceed to tighten the Bolts and Screws in a sequential manner.
- Page 8 Noble House Home Furnishings LLC...
