ADTRAN 500 Series Quick Start Manual

DUAL/QUAD T1/PRI MODULE
Quick Start Guide
DUAL T1/PRI
1
MON
1
MON
N C
ETWORK ONNECTION
Pin Name
1 R1 RXDATA
2 T1 RXDATA
3 Unused
4 R TXDATA
5 T TXDATA
6, 7, 8 Unused
Quick Start Guide, 61200314L2-13A, April 2003
All manuals and user guides at all-guides.com
2
QUAD T1/PRI
2 3
4
MON
P
INOUT
Description
Receive data from the network ring
Receive data from the network tip
n/a
Send data towards the network ring
Send data towards the network tip
n/a
Technical Support 1-888-4ADTRAN (1-888-423-8726)
For more detailed documentation, visit us online at
I I
NSTALLATION NSTRUCTIONS
1. Remove the cover plate from the appropriate option slot in the
500 Series
ATLAS 550 rear panel.
2. Slide the Dual/Quad T1/PRI Module into the option slot until the module
is firmly positioned against the front of the chassis.
3. Secure the thumbscrews at both edges of the module. Tighten with a
screwdriver.
4. Connect the cables to the associated device(s).
500 Series
5. Complete installation of remaining modules and Base Unit as specified
in the Installation chapter of the ATLAS 550 System Manual.
S
PECIFICATIONS
Line Rate
Capacity
Line Codes
Framing
Tests
Connectors
Terminating Impedance 100 ohms ± 5%
P/N 1200314L2/1200755L2
1.544 Mbps, ± 75 bps
T1: 1-24 DS0s
PRI: 23 B+D
AMI (alternate mark inversion) or B8ZS (bipolar
return to zero)
D4 or ESF
Self-test, line loopback, payload loopback
RJ-48C (eight-position, modular jack)
