TOWER
SECURITY UNIT
I M P O R TA N T !
Assembly may require the assistance of
another person.
Before you begin assembly:
READ THE DIRECTIONS all the way through one
time. This will speed up the process and help you
understand the sequence of steps.
COUNT THE PARTS AND HARDWARE before
assembly. This ensures you have received all
necessary parts before you begin.
TOOLS: You may need a Phillips head screwdriver,
a medium slotted screwdriver or a plastic mallet. To
protect your new furniture from damage during
assembly, it is recommended to work on a
carpeted surface.
0908
TSU
In the event any parts are missing from
this package, send your name, address,
telephone number, and a description of
the missing part(s) to: PARTS, Box 1420,
Missoula, MT 59806 or call:
1-800-769-5693 or FAX 1-800-445-5281.
CAUTION: On assemblies requiring glue, make
sure the unit is assembled correctly before gluing.
Once this unit is assembled with glue, the
manufacturer will not be responsible for damaged
parts. Keep a damp cloth or sponge handy to wipe
off excess glue.
To care for this furniture, simply wipe with a cloth
dampened with glass cleaner containing ammonia-D.

Advertisement

loading
Need help?

Need help?

Do you have a question about the TSU and is the answer not in the manual?

Questions and answers

Summary of Contents for Ironwood TSU

  • Page 1 TOWER SECURITY UNIT I M P O R TA N T ! In the event any parts are missing from Assembly may require the assistance of this package, send your name, address, another person. telephone number, and a description of Before you begin assembly: the missing part(s) to: PARTS, Box 1420, Missoula, MT 59806 or call:...
  • Page 2: Parts Diagram

    PARTS DIAGRAM Left Side 06005641 1 ea. Right Side 06005641 1 ea. Back 06005657 2 ea. 06005601 1 ea. Bottom 06005611 1 ea. Monitor Shelf 06005631 1 ea. Divider 06005644 1 ea. Right Door 06005673 1 ea. Left Door 06005673 1 ea.
  • Page 3 HARDWARE Minifix Cam 909810 26 ea. Wood Dowel 195000 22 ea. CD Rack 286420 2 ea. Minifix Bolt 909834 26 ea. #6 x 5/8" 901216 8 ea. Panhead Screw Hinge H0590 4 ea. Varianta Screw 988060 12 ea. Swivel Casters 402640 4 ea.
  • Page 4 LOCKSET 250-HP #6 x 5/8" 901216 2 ea. Catch Plate 452340 1 ea. Panhead Screw #8 x 5/8" 988056 4 ea. Panhead Screw 1 ea. 452310 Lock & Key Set 452320 1 ea. Stop Plate 452330 1 ea. 452350 1 ea. Using the Minifix System: Insert the Minifix Cams into the appropriate holes with the arrow...
  • Page 5 Place the Divider (L) on a clean, carpeted surface with the pre- drilled holes facing up. Insert two Minifix Cams (H1) into the Divider with the arrows of the cams facing out. Place Left Side (A) and Right Side (B) with the pre-drilled holes facing up.
  • Page 6 Screw nine Minifix Bolts (H3) into each Side (A & B) where indicated. Attach a CD Rack (H4) to each Side (A & B) using #6x5/8" Flathead Screws (H16) as shown. NOTE: The nubs on the CD Rack should face up as indicated. With a screwdriver, attach the Hinges (H6) to the Left Side (A) using the #8 x 5/8"...
  • Page 7 With a screwdriver, attach the Hinges (H6) to the Right Side (B) using the #8 x 5/8" Flathead Screws (H17) in the pre-drilled holes. The screws must be centered in the slots of the Hinges as shown. Attach the two left Slide Channels (S1) to the Left Side (A) using six Varianta Screws (H7) into the pre- drilled holes where indicated.
  • Page 8 # 10 Insert six Dowels (H2) into the Bottom (E) where indicated. # 11 Screw eight Minifix Bolts (H3) into the Bottom (E) where indicated. # 12 Insert six Minifix Cams (H1) into Top (C), four cams into both Backs (D), where indicated with the arrows of the cams facing out.
  • Page 9 # 14 Attach a Catch Plate (H8) to the Monitor Shelf (G) as shown using two #8x5/8" Panhead Screws (H9). # 15 With the aid of an assistant, position the cams of the Top (C) onto the bolts and dowels of the Left Side (A) as shown.
  • Page 10 # 18 FINISHED EDGE Position the other Back (D) onto the Left Side (A) with the finished edge facing up, and turn arrows of the cams (H1) clockwise to secure. # 19 With the help of an assistant, position the bolts and dowels of Right Side (B) into the cams of the Top (C), Both Backs (D), Monitor Shelf (G) as shown.
  • Page 11 # 21 Attach four Plate Casters (H10) to the Bottom (E) using the #14x3/4" Panhead Screws (H11) in the pre-drilled holes as shown. # 22 With the assistance of another person, turn the unit upright. Position the Divider (L) onto the bolts and dowels of the Bottom (E) as shown.
  • Page 12: Hinge Assembly

    # 24 Attach a Door Pull (H13) to the Left Door (I) and Right Door (J) using the 1" Machine Screws (H14). # 25 Position the Lock (H15) onto the inner side of the Right Door (J) oriented as shown. Secure the Lock in place using two #6x5/8"...
  • Page 13 # 27 Attach the Right Door (J) using four #8 x 5/8" Flathead Screws (H17) in the pre-drilled holes as shown. SIDE DOOR PANEL # 28 HORIZONTAL VERTICAL To make adjustments, loosen screws just enough ADJUSTMENT ADJUSTMENT to move horizontally or vertically. Tighten screws when adjustment is appropriate.
  • Page 14 # 30 Place the Keyboard Shelf (K) with pre-drilled holes facing up as shown. Attach left and right Shelf Slides (S3 & S4) using the #6 x 5/8" Panhead Screws (H5) as shown. # 31 Place the Printer Shelf (P) with pre-drilled holes facing up as shown.
