Specifications

Monitor
Specifications
LCD Module
Native Resolution (Pixel Count):
Input Signal
Display Colors
Synchronization
Range
Image Formation Time
Resolutions Supported
Active Display Area
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
* 1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each
dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
: Trademarks apply to appropriate countries.
*
MultiSync
Monitor
Diagonal: 46 cm / 18.1 inch
Viewable Image Size: 46 cm / 18.1 inch
1280x1024
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. Positive/Negative
Sync on Green (Video 0.7V p-p and Sync Negative 0.3V p-p)
Analog input: 16,777,216
Horizontal: 31.0 kHz to 82 kHz
Vertical: 50 Hz to 85 Hz
33 ms (Typ.)
Landscape: 720 x 400*
640 x 480*
800 x 600*
832 x 624*
1024 x 768*
1152 x 870*
1280 x 1024 at 60 Hz to 75 Hz ................ optimal display performance.
Portrait: 480 x 640*
600 x 800*
624 x 832*
768 x 1024*
870 x 1152*
1024 x 1280 at 60 Hz to 75 Hz ................ optimal display performance.
Landscape : Horiz. : 359 mm/14.1 inches
Vert. : 287 mm/11.3 inches
Horizontal : Horiz. : 287 mm/11.3 inches
Vert. : 359 mm/14.1 inches
AC 100 -
0.65 A @ 100V–0.30 A @ 240 V
387.0 mm (W) x 394.3 ~ 504.3 mm (H) x 179.6 mm (D)
Landscape:
15.2 inches (W) x 15.5 ~ 19.9 inches (H) x 7.1 inches (D)
315.2 mm (W) x 430.2 ~ 540.2 mm (H) x 179.6 mm (D)
Portrait:
12.4 inches (W) x 16.9 ~ 21.3inches (H) x 7.1 inches (D)
Without stand: 387.0 mm (W) x 315.2 mm (H) x 62.2 mm (D)
15.2 inches (W) x 12.4inches (H) x 2.4 inches (D)
Height Adjustment: 110 mm / 4.3 inches
8.2 kg
18.1 lbs
Without stand: 4.9 kg
10.8 lbs
Operating Temperature: 5°C to 35°C/41°F to 95°F
Humidity: 30% to 80%
Feet: 0 to 4850 m / 0 to 15,912 Feet
Storage Temperature: -10°C to 60°C/14°F to 140°F
Humidity: 10% to 85%
Feet: 0 to 13600 m / 0 to 44,619 Feet
® * LCD ™
1880SX
Active matrix; thin film transistor (TFT)
liquid crystal display (LCD); 0.28 mm dot
pitch; 240 cd/m
350:1 contrast ratio, typical
Digital Input: DVI
Depends on display card used.
Automatically
Automatically
1 : VGA-Text Some systems may not support
1 at 60 Hz to 85 Hz all modes listed.
1 at 56 Hz to 85 Hz
1 at 75 Hz
at 60 Hz to 85 Hz NEC-Mitsubishi Electronics Display cites
1
1 at 75 Hz recommended resolution at 60 Hz for
1 at 60 Hz to 85 Hz Some systems may not support
1 at 56 Hz to 85 Hz all modes listed.
at 75 Hz
1
1 at 60 Hz to 85 Hz NEC-Mitsubishi Electronics Display cites
at 75 Hz recommended resolution at 60 Hz for
1
@ 50/60 Hz
240 V
16
Notes
2 white luminence;
