  • Page 1 MultiSync LCD1860NX User’s Manual...

  • Page 2: Declaration Of The Manufacturer

    Therefore, it should be read carefully in order to avoid any problems. Caution: When operating the MultiSync LCD1860NX with a 220-240V AC power source in Europe, use the power cord provided with the monitor. In the UK, a BS approved power cord with a moulded plug has a Black (five Amps) fuse installed for use with this equipment.

  • Page 3: Canadian Department Of Communications Compliance Statement

    C-UL: Bears the C-UL Mark and is in compliance with Canadian Safety Regulations according to CSA C22.2 No. 950. FCC Information Use the attached specified cables with the MultiSync LCD1860NX (L182R4) colour monitor so as not to interfere with radio and television reception.
  • Page 4 Contents Your new NEC MultiSync LCD monitor box* should contain the following: • MultiSync LCD1860NX monitor with height adjustable base • Power Cord(s) • Video Signal Cable • User’s Manual • Cable Management Cover • NEC LCD Setup Software, User’s Manual and other helpful files.

  • Page 5: Quick Start

    NOTE: If you have any problems, please refer to the Troubleshooting section of this User’s Manual. NOTE: Refer to User’s Manual in the NEC LCD Setup Software CD case for installation and operation of this software. Macintosh Cable Adapter (not included) Figure B.1...

  • Page 6: Raise And Lower Monitor Screen

    INPUT2 INPUT1 INPUT2 INPUT1 Figure C.1 Figure C.2 Vacation Switch Power Button Figure D.1 Raise and Lower Monitor Screen The monitor may be raised or lowered in either Portrait or Landscape mode. To raise or lower screen, place hands on each side of the monitor and lift or lower to the desired height (Figure RL.1). Figure RL.1 English-5...

  • Page 7: Remove Monitor Stand For Mounting

    Tilt Grasp both sides of the monitor screen with your hands and adjust the tilt as desired (Figure TS.1). Warning: Take care not to trap fingers between monitor bezel and stand. Remove Monitor Stand for Mounting To prepare the monitor for alternate mounting purposes: 1.

  • Page 8: Brightness/Contrast Controls

    Controls OSM (On-Screen Manager) control buttons on the front of the monitor function as follows: To access OSM menu, press any of the control buttons (EXIT, To change signal input, press the SELECT button. NOTE: OSM must be closed in order to change signal input. Menu EXIT Exits the OSM controls.
  • Page 9 FINE (Analog input only) Improves focus, clarity and image stability by increasing or decreasing this setting. Should the “Auto Adjust function” and the “H.Size” function do not give you a satisfactory picture setting, a fine tuning can be performed using the “Fine” function. It improves focus, clearity and image stability by increasing or decreasing this setting.
  • Page 10 Tools 2 Language: OSM control menus are available in seven languages. OSM Position: You can choose where you would like the OSM control image to appear on your screen. Selecting OSM Location allows you to manually adjust the position of the OSM control menu left, right, down or up.

  • Page 11: Recommended Use

    Recommended use Safety Precautions and Maintenance • DO NOT OPEN THE MONITOR. There are no user serviceable parts inside and opening or removing covers may expose you to dangerous shock hazards or other risks. Refer all servicing to qualified service personnel. •...
  • Page 12 • Adjust the monitor’s brightness and contrast controls to enhance readability. • Use a document holder placed close to the screen. • Position whatever you are looking at most of the time (the screen or reference material) directly in front of you to minimize turning your head while you are typing.

  • Page 13: Specifications

    60 Hz to 85 Hz 1152 x 870* at 75 Hz 1280 x 1024 at 60 Hz to 75 Hz... NEC-Mitsubishi Electronics Display cites 1280 x 1024 at 60 Hz... Digital Input AC 100-120 V/220-240 V @ 50/60 Hz 0.8 A@100-120 V, 0.4 A @ 220-240 V...
  • Page 14 Features ambix Technology: Dual input technology allowing both analog and digital inputs off of one connector (DVI-I) as well as additional legacy analog support off of a traditional 15-pin VGA connector. Provides traditional MultiSync technology compatibility for analog as well as DVI-based digital compatibility for digital inputs. DVI-based digital interfaces include DVI-D, DFP and P&D.

  • Page 15: Troubleshooting

    NOTE: As with all personal display devices, NEC-Mitsubishi Electronics Display recommends using a screen saver at regular intervals whenever the screen is idle. Message “OUT OF RANGE” is displayed (screen is either blank or shows rough images only) •...
  • Page 16 TCO’99 MultiSync LCD1860NX (L182R4) Congratulations! You have just purchased a TCO’99 approved and labeled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
