Apollo Sprayers PRECISION-5 PRO Limited Edition PLUS Instruction Manual page 21

Diagram # Part #
1 A4554
2 A4555
3 A4556
4 A4558
5 A4374
6 A4551
7 A4559
8 A4560
9 A4364
10 A4300
11 A4308
12 A4198
13 A4998
14 A4503
15 A4033
16 A2116
17 A2119
18 A4026
19 A4320
20 A4553
21 A4318
22 A4307
23 A4051
24 A4557
25 A4197
26 A4053
27 A4028
28 A4178
29 A4552
30 A4900
31 A4006
32 A4042
Description
Cart Base Plate Paint Blue
Cart Axle (Zinc Plated
Wheel Spacer (6061 Alum.)
10" X 1 ¾" Wheel
½" Axle Cap
Frame Tube (Chrome)
Rubber Tip For Frame Tube
Handle Button
¼" X 20 X 1 ¼" Hex Bolt Plated .5.
¼" SAE F/W Plated Washer
¼" X 20 Hex Nuts Plated
110v Mini Compressor Unit
Pressure Regulator
1/8" Male NPT X ¼" Male Hose Barb 90°
Air Hose Clip S.S.
¼" Air Hose, Per Foot
¼" X ¼" Female Swivel Barb
Quick Connect Female With ¼" Male Thread
1/4" X 20 X 1/2" Hex Bolt Plated .5.
Pressure Pot Deck
6-32 X 1/2" Phillips Pan M/S Plated
6-32 Hex M/S Nuts Plated
Cable Clamps, Black
Outlet Box (Plastic)
Outlet 15 amp-125 Volt
Flexible Cord Protector
8 Foot Power Cord
Large Ring Terminal
Support Ring For Pressure Pot.
2.5 Gallon Pressure Pot
Handle (Chrome)
Handle Grip
Page 21
Quantity
1
1
2
2
2
2
2
2
4
20
20
1
1
1
2
3
1
1
16
1
4
2
2
1
1
1
1
3
2
1
1
2
