- Page 1 CORDLESS DRILL HPV12V2A ORIGINAL INSTRUCTIONS WARNING: Read thoroughly the instruction manual before use WARNING: READ THE FOLLOWING INSTRUCTIONS BEFORE USING THIS MACHINE.
-
Page 2: Table Of Contents
CONTENTS 1. INTENDED USE 2. SAFETY INSTRUCTIONS 3. EXPLANATION OF SYMBOLS 4. YOUR PRODUCT 5. OPERATION 6. MAINTENANCE AND STORAGE DISPOSAL CE DECLARATION 9. WARRANTY 10. PRODUCT FAILURE 11. WARRANTY EXCLUSIONS... -
Page 3: Intended Use
1. INTENDED USE This power tool is designed for drilling as well as for tightening and loosening screws. This power tool should not be used for purposes other than those described. 2. SAFETY INSTRUCTIONS 2.1 GENERAL POWER TOOL SAFETY WARNINGS WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. - Page 4 e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts.
- Page 5 6) Service a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained. b) Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer or authorized service providers.
- Page 6 2. Hearing damage if effective hearing protection is not worn. 3. Body injuries caused by vibration emissions if the electrical appliance is used improperly or for a prolonged or poorly maintained period. WARNING! This device produces an electromagnetic field during operation. This field may interfere in certain circumstances with active or passive medical implants.
- Page 7 Charger Use the charger provided with the tool only to charge the battery. Never attempt to charge non-rechargeable batteries. Have defective cords replaced immediately. Do not expose to water. Do not open the charger. Do not probe the charger. ...
-
Page 8: Explanation Of Symbols
3. EXPLANATION OF SYMBOLS To reduce the risk of injury, the user must read and understand this manual before using this product. Conforms to relevant safety standards Do not expose batteries to temperatures exceeding 40 degrees. Do not dispose of batteries in fire. They could explode and cause injury Do not dispose of batteries in water. -
Page 9: Your Product
4. YOUR PRODUCT a. Description 1. Keyless chuck 2. Torque control 3. Built in lamp 4. Trigger 5. Forward/Reverse switch 6. Handle 7. Battery release knob 8. Battery pack 9. Charger 10. Charger indicator light 11. Battery capacity indicator a. Technical data Voltage 12Vd.c No load speed... -
Page 10: Operation
of the need to identify safety measures to protect the operator that are based on an estimation of exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trigger time). Wear hearing protection. - Page 11 Tighten the chuck jaws on the drill bit. Make sure that the bit is well installed in place. Failure when installation will create accidents and injuries 5.6 REMOVING BITS Switch off the tool and put the reverse/forward switch in the center position. Open the chuck jaws and then pull the bit straight out.
-
Page 12: Maintenance And Storage
When the selected torque is reached, the chuck will stop rotating. The proper setting depends on the type of material and the size of screw you are using. Note: always start on the lowest setting. The drill symbol gives the highest torque setting and is used when drilling and for driving larger screws. Rotate the torque ring until the bit symbol aligns with the arrow on the drill body for drilling action (as show in below picture). -
Page 13: Ce Declaration
ZI, 32, rue Aristide Bergès- 31270 Cugnaux-France Tel: + 33 (0) 5.34.502.502 Fax: + 33 (0) 5.34.502.503 Declares that the machinery designated below: CORDLESS DRILL HPV12V2A Serial number: 20210625208-20210629807 Complies with the provisions of the Directive «machinery» 2006/42/CE and national laws transposing it:... -
Page 14: Warranty
9 . WA R R A N T Y WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. -
Page 15: Product Failure
10. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank if your product has one. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. -
Page 16: Warranty Exclusions
11. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •... - Page 17 NOTES...
- Page 18 NOTES...
- Page 19 NOTES...
