Stereo Microscope
BS-3001, 3002 Series
Instruction Manual
Please read the manual before using the microscope.
Contents:
I, Applications
II, Names of the parts and accessories
VII, Optional accessories
I, Applications:
BS-3001 and BS-3002 series stereo microscope are economical models. They are
widely used in electronics industry, assembling and inspection of precise
instruments and meters, educational experiments, observation and research. It
can be used in the schools, research institutes, factories and families to study the
geology, outside appearance of objects.
II, Names of the parts and accessories:
BS-3001A:
Focusing knob, clamp thumb screw, pole, eyepieces, diopter adjustment ring,
prism housing, objective, clipper, black & white glass stage.
Advertisement
Table of Contents
Related Manuals for BestScope BS-3001 Series
Summary of Contents for BestScope BS-3001 Series
- Page 1 Stereo Microscope BS-3001, 3002 Series Instruction Manual Please read the manual before using the microscope. Contents: I, Applications II, Names of the parts and accessories III, Major technical parameters IV, How to use V, Lamp and fuse replacement VI, Maintenance and general care of your microscope VII, Optional accessories I, Applications: BS-3001 and BS-3002 series stereo microscope are economical models.
- Page 2 BestScope International Limited BS-3001B: Incident illuminator, focusing knob, clamp thumb screw, pole, eyepieces, diopter adjustment ring, prism housing, objective, power switch, specimen clipper, black & white glass stage. BS-3001C: Power switch, incident illuminator, focusing knob, clamp thumb screw, pole, eyepiece, diopter adjustment ring, prism housing, objective, power switch, specimen clipper, frost glass stage, transmitted illuminator.
- Page 3 BestScope International Limited 4) incident and transmitted illuminator 12V/10W 5) incident and transmitted halogen illuminator 12V/10W The above 5 types are optional 3, structure parameter: Vertical binocular head, Inclined 45 degree binocular head are optional. Diopter adjustment +/- 5 °, inter-papillary distance adjustable 55-75mm .
- Page 4 BestScope International Limited side. Make this adjustment without moving the focusing knob. Then grasp the right and left prism housing and move them closer or farther apart in order to match your pupil distance. Adjustment is proper when the field of view becomes comfortable and presents a full single field.
- Page 5 BestScope International Limited 7, Apply a little bit grease regularly to the mechanical parts. 8, When not in use always cover the microscope with the dust cover and place it in a cool and dry place., VII, Optional parts: 1, eyepieces: WF5×/20mm, WF15×/15mm, WF20×/10mm 2, Objectives: 1×, 3×, 4×, 6×...
