Backyard Creations BAZEMORE 272-1027 Assembly Instructions

IMPORTANT!! PLEASE READ ENTIRE INSTRUCTION SHEET BEFORE ASSEMBLY!!
TO EXPEDITE ANY FUTURE WARRANTY CLAIMS, PLEASE KEEP INSTRUCTION SHEET, WARRANTY CARD, AND RECEIPT.
Remove all protective materials and set parts on a flat,
Step 1:
non-abrasive surface. Identify the parts packed in the
carton against the parts list. If you are missing any parts or
unsure how to proceed with assembly, call our Customer
Service Center at 1-800-416-3511.
assembly if any parts are missing or damaged.
Step 2: Place the table top upside down on a flat, non-abrasive
surface. Attach three table legs to the table top by using six
bolts and Ø20xØ6.5x2.0mm washers as shown in
F igure 1
. Guide the bolts through the holes in the leg
into the pre-drilled holes in the table top.
only 2-3 turns.
C
I
D
F
A
Step 3: Attach three legs to the leg connector bracket by carefully
guiding the bolts already in place on the table legs
(each leg has two bolts) through the holes in the leg
connector bracket. Add a washer and a nut to the end
F igure
of each bolt as shown in the
2-3 turns only.
H
G
E
B
Step : Repeat above process( 4
shown in the
Do not attempt
Hand tighten
FOOT CAP
Figure 1
Step 5: After making any necessary adjustments to the
alignment of the table top, use the hex bolt driver to
tighten all bolts.
few revolutions at a time. In order to apply equal
pressure to all bolt joints, we recommend working in a
cross corner (X fashion). Repeat until all bolts are tight.
2 Hand tighten
Do not over tighten
.
Cover all bolts and nuts with covers.
With the help of another person, turn the table in the
Step 6:
upright position. Your table is now ready for use. If you
have any questions, please call our Customer Service
Figure 2
Center at 1-800-416-3511.
IMPORTANT NOTE: Damage to welds or frames resulting
from over tightened bolts or improper assembly is not covered
under our warranty. Please read all instructions carefully
before assembly. If you have any questions regarding your
assembly, call our Customer Service Center at 1-800-416-3511.
ANT00517K01
Figure 1
& 2) for the last leg as
F igure 3
.
C
Figure 3
Note: each bolt must be tightened a
. Over tightening may strip bolts.
Page 2
* NOTE: PARTS SHOWN ON PARTS LIST ARE NOT TO SCALE
PARTS LIST DESCRIPTION
A
TABLE TOP
LEG CONNECTOR
B
BAR
C
TABLE LEG
D
1/4" X 30 MM BOLT
Ø6.5 X 1.0 MM
E
WASHER
Ø 20 X Ø6.5 X 2.0 MM
F
WASHER
G 1/4" NUT
NUT COVER
H
BOLT COVER
I
HEX BOLT DRIVER
J
HEX WRENCH
K
UMBRELLA HOLE
PROTECTIVE RING
FACTORY ASSEMBLY
FOOT CAP
FACTORY ASSEMBLY
ORDER PART # QTY
AT53120 1
AT53121 1
AT53122
4
HW0038
8
HW0004 8
8
HW0594
8
HW0014
8
HW0027
8
HW0105
HW0006 1
HW0009
1
G0157
FC0607
