2 KNX System

In this section, a common description for all IntesisBox KNX series gateways is given, from the point of view of KNX
system which is called from now on internal system. Connection with the Fujitsu system is also called from now on
external system.

Description

IntesisBox KNX connects directly to the KNX TP-1 bus and performs as one more device into the KNX system, with the
same configuration and operational characteristics as other KNX devices.
Internally, the circuit part connected to the KNX bus is opto-isolated from the rest of the electronics.
IntesisBox KNX receives, manages and sends all the telegrams related to its configuration to the KNX bus.
On receiving WRITE telegrams of KNX group addresses associated to communication objects, the corresponding
messages are sent to the external system (Fujitsu installation).
When a change in a signal of the external system is detected, a WRITE telegram is sent to the KNX bus (addressed
with the group address associated to the corresponding group object), in order to maintain both systems synchronized
in every moment.
The status of the KNX bus is checked continuously and, if a bus drop-down is detected, for example due to failure in
the bus power supply, after the KNX bus is restored again, IntesisBox will send READ telegrams to group addresses of
all communication objects marked with flag 'Ri'. The behavior of each individual point into IntesisBox is determined by
the flags configured for the communication object. See details below.

Points definition

Every group object in configuration has following KNX properties:
Property Description
Description Descriptive information about the communication object or signal.
Object Information on range of values for the group object.
function
DPT Datapoint type. It is the KNX data type used to encode the signal's value. It will depend
on the type of signal associated in the external system in every case.
Group It is the KNX group to which the point is associated. It is also the group to which the
read (R), write (W), transmit (T), update (U) and read on init (Ri) flags are applied. It is
the sending group.
Listening They are the addresses that can write on the group object, a part of the main group
addresses address.
R Read. If this flag is activated, READ telegrams of this group address will be accepted.
Ri Read on Init. If this flag is activated, the object will trigger corresponding READ request
(on associated group address) on initialization.
W Write. If this flag is activated, WRITE telegrams on this group object will be accepted.
T Transmit. If this flag is activated, when the group object value changes, due to a change
in the external system, a WRITE telegram of the associated group address will be sent
to the KNX bus.
U Update. If this flag is activated, UPDATE telegrams (response to READ telegrams) on
this group object will be accepted.
Active If activated, the point will be active in IntesisBox, if not, the behavior will be as if the
point is not defined. This allows deactivating points without the need of delete them for
possible future use.
