9 Appendix A – Communication Objects Table
TOPIC
Control_Gateway ES
ENERGY SAVING
Status_Gateway ES
Status_Gateway error
GATEWAY ERROR
Status_Gateway error code
On/Off (all units)
ON/OFF
GLOBAL
Operating Mode (all units)
SIGNALS
OP MODE
Operating Mode (all units)
Fan Speed (all units)
FAN SPEED
Fan Speed AUTO (all units)
Temperature Setpoint (ºC) (all units)
SETP TEMP
Remote control disablement
REMOC.
Control_Capacity save
CAPACITY SAVE
Status_Capacity save
OUTDOOR
UNIT
Control_Forced off
SIGNALS
FORCE OFF
Status_Forced off
Status_Error
ERROR
Status_Error code
Status_Exists
EXISTS
Control _On/Off
ON / OFF
Status _On/Off
Control _Operation mode
OP MODE
Status _Operation mode
Control _Operation mode
This information is subject to change without prior notice
IntesisBox is a registered trademark of Intesis Software S.L.U.
NAME LEN
1 bit
1 bit
1 bit
2 byte
1 bit
1 byte DPT_HVACContrMode
1 byte
1 byte
1 bit
2 byte
1 bit
1 byte
1 byte
1 bit
1 bit
1 bit
2 byte
1 bit
1 bit
1 bit
1 byte DPT_HVACContrMode
1 byte DPT_HVACContrMode
1 byte
DATAPOINT TYPE
DPT_NAME DPT_ID R
DPT_Enable 1.003
DPT_Enable 1.003 R
DPT_Alarm 1.005 R
Non-standarized 8.x R
DPT_Switch 1.001
20.105
Non-standarized 5.x
Non-standarized 5.x
DPT_Switch 1.001
DPT_Value_Temp 9.001
DPT_Bool 1.002
DPT_Scaling 5.001
DPT_Scaling 5.001 R
DPT_Bool 1.002
DPT_Bool 1.002 R
DPT_Alarm 1.005 R
Non-standarized 8.x R
DPT_Switch 1.001 R
DPT_Switch 1.001
DPT_Switch 1.001 R
20.105
20.105 R
Non-standarized 5.x
FLAGS FUNCTION
W T U
W 0-Disable energy saving, 1-Enable energy saving
T 0-Disable energy saving, 1-Enable energy saving
T 0-No error, 1-Error
T 0-No Error, X-Error
W 0-Off, 1-On
W 0-Auto, 1-Heat, 3-Cool, 9-Fan, 14-Dry
W 0-Auto, 1-Heat, 2-Dry, 3-Fan, 4-Cool
W 1-Quiet, 2-Low, 3-Med-Low, 4-Med-High, 5-High
W 1-Set auto fan; 0-Stop auto fan
W 0..63.5 ºC
W 0-No disabled, 1-Disabled
Thersholds (0%; 1%..40%; 41%..50%; 51%..60%;
W
61%..70%; 71%..80%; 81%..90%; 91%..100%)
Thersholds (0%; 40%; 50%; 60%; 70%; 80%; 90%;
T
100%)
W 0-Not forced, 1-Forced off
T 0-Not forced, 1-Forced off
T 0-No error, 1-Error
T 0-No Error, X-Error
T 0-Not exist,1-Exists
W 0-Off,1-On
T 0-Off,1-On
W 0-Auto, 1-Heat, 3-Cool, 9-Fan, 14-Dry
T 0-Auto, 1-Heat, 3-Cool, 9-Fan, 14-Dry
W 0-Auto, 1-Heat, 2-Dry, 3-Fan, 4-Cool
