USER MANUAL
Avonic 4K60 PTZ Camera with 30x Zoom
CM93-NDI
www.avonic.com
•
© January 2023
•
Version 1.0 (preliminary)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CM93-NDI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avonic CM93-NDI

Summary of Contents for Avonic CM93-NDI

  • Page 1 USER MANUAL Avonic 4K60 PTZ Camera with 30x Zoom CM93-NDI www.avonic.com • © January 2023 • Version 1.0 (preliminary)

  • Page 2: Disclaimer, Contact, Ip Rating, Marking

    “look and feel” and arrangement of such Content, contained in this Manual is owned, controlled or licensed by or to Avonic, and is protected by trade dress, copyright, patent and trademark laws, and various other intellectual property rights and unfair competition laws.

  • Page 3: Important Information

    IMPORTANT INFORMATION Liability Avonic will NOT be held responsible for any damage or injury caused by unqualified persons carrying out these tasks, or by not following the instructions in this Manual. Intended Use and Non-Intended Use Installation The following applies to the installation of the camera: •...

  • Page 4: Acronyms

    Symbol Meaning Description Listed Not following this information or instructions may lead to injury and/or damage to the product. Read the instructions in the user manual first before you use the product! Important The information associated with this symbol requires special attention.

  • Page 5: Table Of Contents

    Contents DISCLAIMER, CONTACT, IP RATING, MARKING................... ii IMPORTANT INFORMATION........................iii Liability............................iii Intended Use and Non-Intended Use..................iii Installation.......................... iii Operation.......................... iii Important Precautions...................... iii Symbols Used in This Manual..................... iii Acronyms............................ iv INTRODUCTION............................8 Purpose of This Manual......................8 Target Audience......................... 8 Document Structure........................
  • Page 6 g. Zoom + -........................43 h. Set & Clear Preset...................... 44 i. PTZ Keys (up/down/left/right)..................44 j. Home..........................44 k. BLC ON/OFF........................ 44 l. Menu..........................44 m. Function Keys (F1/F2/F3/F4)..................44 n. Blank Buttons....................... 44 Other Key Combinations......................45 Tally Light Functionality......................45 OSD Menu..........................46 1.
  • Page 7 APPENDIX C - HTTP API........................72 How to use HTTP API.........................72 Curl........................... 73 {"GetEnv"}......................... 74 HTTP API code list........................75 IR Remote Control......................75 PTZ............................. 75 Audio..........................77 Video..........................78 Network..........................86 System..........................88 APPENDIX D - CMOS SENSOR CHARACTERISTICS................91 APPENDIX E - DATASHEET (SPECIFICATIONS)..................92 SPECIFICATIONS.........................

  • Page 8: Introduction

    This Manual describes the safety precautions and the instructions for safe unpackaging, installation, operation, maintenance and disposal of the Avonic CM93-NDI camera. In this Manual, the Avonic CM93-NDI camera is referred to as the 'Product'. Target Audience This Manual is developed for installation technicians who install the Product at client sites, and for IT professionals who are responsible for operating the Product.

  • Page 9: Safety Instructions

    • Set up this Product on a hard, stable surface or mount it to a wall or ceiling. • ONLY use an Avonic mount for mounting to a wall or ceiling. • Ensure the mounting construction is capable of supporting four times the weight of the Product. (See 'General Specifications >...

  • Page 10: Ventilation

    • Don’t open this Product and don’t attempt to repair it yourself. Disassembling the Product may damage it or may cause injury to you. • If this Product is damaged, malfunctioning, or if it comes into contact with liquid, contact Avonic or an Avonic Authorized Service Provider.

  • Page 11: Product Overview

    Fluent 4K60 video With 60 frames per second, the Avonic CM93 delivers high-quality 4K Ultra HD output. A big difference with the standard 4K 30fps PTZ cameras being used in fixed installations. Processing image with 60 frames per second, provides a pristine image quality via simultaneous video outputs.

  • Page 12: Unpacking

    2. Handling Precautions 3. Unpacking the Camera 4. Return Procedure Package Contents The following tables contains an overview of the package contents of the Product. Quantity Description Avonic SKU 1 pc PTZ Camera AV-CM93-NDI-B/W 1 pc Remote Control AV-CM40-RC 1 pc...

  • Page 13: Handling Precautions

    The camera should be in its protective foam as follows: Figure 5: Camera in Foam 3. Verify that the plastic camera bag is sealed. If this is NOT the case, contact Avonic and stop here. 4. Break the seal of the sealed camera bag.

  • Page 14: Mounting And Installation

    • Set up this Product on a hard, stable surface, or mount it to a wall or ceiling. • ONLY use an Avonic mount for mounting to a wall or ceiling. • Ensure the mounting construction is capable of supporting four times the weight of the Product. (See 'General Specifications >...

  • Page 15: Connecting The Components To The Camera

    Connecting the Components to the Camera Execute the following steps to connect the components to the camera: 1. Connect all provided components (see Package Contents) to the ports at the rear of the camera. The figure below shows the applicable ports. 1.

  • Page 16: Connecting A Controller To A Camera

    Connecting a Controller to a Camera You can connect one or more cameras to a VISCA (serial) controller. https://avonic.com/en/product-categorie/controllers/ for an overview of the available controllers. A controller gives you direct control over the most important camera settings (e.g., Pan, Tilt, Zoom, Focus, White Balance).

  • Page 17: Serial Connecting Via Rs-232 Or Rs-485

    Serial Connecting via RS-232 or RS-485 COM Port Settings In default working mode, the camera can connect to a VISCA controller via an RS-232 or RS-485 serial interface. The applicable COM port settings are (where '*' stands for 'Default value'): RS-232 RS-485 (half-duplex mode) •...

  • Page 18: Connecting Via Lan

    ONE camera, the impedance resistor is not needed. Figure 11: RS-485 Network Connection Diagram Connecting via LAN Avonic IP cameras can be controlled by any device using the Visca over IP protocol (see the command list in Appendix A - VISCA Settings and Command List).

  • Page 19: Operation

    OPERATION This chapter describes all the camera features to help you to understand how the camera can be used. This is subdivided into the following sections: WebGUI Using the Remote Control Other Key Combinations OSD Menu Using the System Select If you want to read more about the functionality of the camera than is documented in this chapter, it is recommend to read the support articles...

  • Page 20: Preview (Local)

    Preview (LOCAL) In this tab, you can see a preview of the camera IP video output. Figure 14: WebGUI > Preview Next to the preview you see: 1. PTZ keys to move the lens of the camera and Focus keys (works only when the focus is set to manual). You can adjust the PTZ speed (the speed when the camera moves) by using the bar below the PTZ keys.

  • Page 21: First Time Usage

    First time usage If you are using the camera for the first time, it is helpful for you first to setup the basic camera settings before explaining the functionalities of the camera in detail. According to the light conditions in your room or on stage, you can follow instructions at: Basic Camera Setup Basic Camera Setup using (semi)manual settings...
  • Page 22 4. Exposure Navigate to Exposure tab and set the Gain Limit (G.Limit). The higher the Gain Limit, the lighter will become the picture. 5. Color Navigate to the Color tab and set the WB Mode to Auto. 6. Image Navigate to Image tab and set the sharpness.
  • Page 23 3. Focus • Navigate to Video > Camera Settings > Focus • If you have difficulties to focus, choose Focus Mode > Manual. Otherwise set the Focus Mode to Auto and choose at AF-Zone > Moving Objects if the filmed person or object is moving a lot, or Meeting for general meeting purposes.

  • Page 24: Audio

    AUDIO Connect first an audio cable with XLR connectors to the 5 pins Phoenix connector and connect the cable to the camera. See Balanced Audio Connection on page 15 Figure 15: WebGUI > Audio Make your settings as follows: 1. Enable (checked) or disable (blank) embedding of audio input (camera rear). 2.

  • Page 25: Video

    VIDEO You can use the VIDEO tabs (described below) to define your settings for the video output, including the main settings of the camera's OSD. VIDEO - Video Encoder Figure 16: WebGUI > VIDEO > Video Encoder The Video Encoder settings are listed below. Video Encoder Option Main Stream Sub Stream...
  • Page 26 Read this article from Youtube and the article from Facebook for setting up a correct stream, if you want to stream via Youtube or Facebook. VIDEO - Streaming Video Figure 17: WebGUI > VIDEO > Streaming Video The recommended Streaming Video settings are listed below. See for more Streaming on the website.
  • Page 27 Next to multicast, there is also unicast allowing you to stream video (via RTSP) to one single users IP address. For more information read also Unicast, Multicast and Broadcast on the website. Figure 18: WebGUI > VIDEO > Multicast Streaming The recommended Multicast Streaming settings are listed below.
  • Page 28 1. Use the Camera Settings tabs (described below) to change the OSD settings as if you are using the remote control. 2. If you have changed a value with the remote control, update the WebGUI using the REFRESH button. A picture is shown ONLY if the main video stream is set to H264. Focus Figure 20: WebGUI >...
  • Page 29 AF-Sensitivity Sets the level of speed with which the autofocus responds. This can be useful if you have people walking through the picture. If the setting is ‘High’, the camera will respond immediately. If the setting is ‘Low’ or ‘Medium’, the camera will not react to sudden and short changes.
  • Page 30 Figure 23: WebGUI > VIDEO > Camera Settings > Manual Exposure Mode In Manual exposure mode, you can manually set the shutter, Iris and DRC options. Shutter The shutter setting determines the amount of time per second that the sensor is exposed. The range of the shutter speed setting is 1/25th of a second (40 milliseconds) to 1/10000th of a second (0.1 milliseconds).
  • Page 31 SAE Mode (Shutter Auto Exposure) The shutter speed is user-adjustable in this mode. The camera automatically decides the best Iris F-stop value for an optimal exposure setting. Note that this setting will come with a cost. The higher the shutter speed, the more sharp the picture become, but also the more dark the picture will be.
  • Page 32 Figure 27: WebGUI > VIDEO > Camera Settings > Bright Exposure Mode In this mode, you should keep the Bright level, Gain limit and DRC as low as possibly acceptable to avoid getting too much noise in the picture. If the level of noise in the image becomes unacceptable, you can use noise reduction to smooth the picture over.
  • Page 33 Image Figure 29: WebGUI > VIDEO > Camera Settings > Image These are settings that have an effect on the image post-processing. Basically, these settings are all artificial: they don’t affect the optical parts of the camera itself. The settings are listed below. Bright The amount of detail that is visible in darker areas of the image.
  • Page 34 Be careful when adjusting the noise reduction, as it can take away the natural ‘crispness’ of the image. You will lose the natural 'crispness' of the image, if you set the dynamic contrast and gain too high (this will cause more noise).
  • Page 35 Fields You can enable or disable Show Time and Show Title can be enabled or disabled by marking or unmarking the checkbox next to the respective setting (the time and name settings can be found under the tab SYSTEM, sections Attributes and Time). You can use the dropdown menus Time Font Color and Title Font Color to set the desired font colors.
  • Page 36 SRT Listener Mode and Caller Mode are both supported. You can define the Listener mode settings here, whereas the Caller Mode settings can be defined in the Streaming Video tab. See the respective figures below for the Listener and Caller Mode Settings, respectively. Figure 34: WebGUI >...
  • Page 37 NDI®| HX Settings This part concerns the NDI®| HX functionality of your Avonic NDI®| HX camera. With the NDI enabled and NDI control enabled, you can easily control every device with NDI®| HX functionality in your IP network. See also Studio Tools on the website .
  • Page 38 Attributes Figure 39: WebGUI > SYSTEM > Attributes Specifying a specific device name to be displayed in the OSD can be useful when using multiple cameras on the same LAN. The Device-ID is always 1 (addressing is done via IP). The language cannot be changed. The ONVIF protocol does NOT accept spaces in the camera name.
  • Page 39 You can define different users with specific permission levels and different username / passwords combinations. There are 2 levels of users: administrators with access to all features, and user-1 and user-2 with access to the preview and PTZ controls. Click SAVE to apply your settings. It is also possible to fill in automatically your user name and password using your browser.
  • Page 40 Figure 44: WebGUI > SYSTEM > Reboot Click on the button Reboot to reboot the camera. It will be ready for use again after the boot cycle. Follow instructions below if you want to create a new reboot schedule. 1. Enable "create new reboot: status". 2.
  • Page 41 MJPEG Snapshot The Avonic CM93 camera is equipped with a MJPEG snapshot feature to, for example, implement into third party software. Every time the page is refreshed, the picture will be updated. To access the MJPEG snapshot feature, use the following format: http://IP/img/capjpg/snapshot.jpg.

  • Page 42: Using The Remote Control

    Using the Remote Control The Product is provided with an IR Remote Control for full control of the camera and use of the OSD menu. Figure 48: Remote Control The various options (a. through n.) are described below. a. Power 1.

  • Page 43: Camera Select

    c. Camera Select Up to 4 different cameras can be controlled with one IR remote Control. You can use the camera select buttons [1,2,3,4] to select the IR channel that the remote control is using. The default camera IR channel is 1. 1.

  • Page 44: Set & Clear Preset

    h. Set & Clear Preset A preset is a specific position of a camera that you save in the camera. A preset is assigned to a number from 0-9. 1. To set a preset, first point the camera in a specific directing and a specific zoom position. 2.

  • Page 45: Other Key Combinations

    Other Key Combinations The following key combinations on the Remote Controller have specific functions. These are: Combination Function [*] → [#] → [4] Menu set to English [*] → [#] → [6] Restore factory defaults [*] → [#] → [9] Flip switch (just temporary flip to view the image flipped) [*] →...

  • Page 46: Osd Menu

    The OSD Menu is visible on the HDMI and SDI outputs. The OSD menu can be accessed by the Remote Control or an Avonic PTZ controller. See also How can I open the OSD menu of my camera on the website.

  • Page 47: Menu

    1. MENU Figure 51: OSD - MENU 1. Press the MENU button to display the main menu on the screen. 2. Use the arrow buttons to move the cursor to the item to be set. Press the HOME button to enter the corresponding sub-menu.

  • Page 48: Exposure

    3.1 EXPOSURE Figure 54: OSD - EXPOSURE 3.2 COLOR Figure 55: OSD - COLOR 3.3 IMAGE The Flip function can be set, although the camera has an automatically flip function. Figure 56: OSD - IMAGE...

  • Page 49: Focus

    3.4 FOCUS Figure 57: OSD - FOCUS 3.5 NOISE REDUCTION Figure 58: OSD - NOISE REDUCTION 3.6 STYLE Figure 59: OSD - STYLE 4. PTZ Figure 60: OSD - PTZ...

  • Page 50: Video Format

    5. VIDEO FORMAT Figure 61: OSD - VIDEO FORMAT 6. NETWORK SETTINGS Figure 62: OSD - NETWORK SETTINGS 7. VERSION Figure 63: OSD - VERSION 8. RESTORE DEFAULT Figure 64: OSD - RESTORE DEFAULT...

  • Page 51: Using The System Select

    Using the System Select The rear of the Product is provided with a System Select that can be used to manually select a video format. This System Select is important for the video quality during video recording or streaming. See the table below for a description of the possible settings and the associated video output quality. 1080p60 4K60 (only over HDMI) 1080p50...

  • Page 52: Maintenance

    MAINTENANCE Camera Maintenance Take the following actions to maintain the camera: • If you will not be using the camera for a long time, turn off the power switch and disconnect the AC powercord of the AC adaptor to the outlet. •...

  • Page 53: Transport And Storage

    TRANSPORT AND STORAGE The camera must be transported in its original packaging box. Inside the box, it is recommended to wrap the camera in the original plastic bag and to place it in the protective foam. Specific guidelines apply to the environmental temperature and humidity when operating and storing the camera.

  • Page 54: Disposal And Recycling

    In general, the term 'E-Waste' applies to items of all types of electrical and electronic equipment and its parts that have been discarded by the owner as waste without the intention of re-use. Avonic outsources the disposal and recycling of its E-Waste camera materials to the Stichting Open. https://stichting-open.org/...

  • Page 55: Troubleshooting

    TROUBLESHOOTING General 1. Turn the camera off and on again and check if the problem persists. 2. If it does, restore to the factory default. Power Issues If the camera does NOT perform a self-test and / or if the power LED is OFF: 1.

  • Page 56: Autofocus Issues

    Autofocus Issues • Check the autofocus (position, speed etc.) before streaming • Check Video/Camera Settings in de WebGUI or the OSD menu (for example: if the image is too bright, too dark, or too noisy, the camera will have difficulties to focus Check environmental conditions and the subject of focussing.

  • Page 57: Appendix A - Visca Settings And Command List

    You can use Hercules SETUP Utility application and a serial connection to make this work. VISCA over IP Avonic IP cameras are implemented with a TCP and an UDP server. The TCP as well as the UDP port are by default set to port 1259.
  • Page 58 To control the camera, you need an TCP or UDP supported application, like Hercules SETUP utility or Packet Sender for example. Follow the instructions below: 1. Open the TCP/ UDP supported application. 2. Fill in the camera's IP Address, TCP/UDP port number and connect the application to your camera. Once the connection between client and server is set up, the client will be able to send PTZ commands to the server.

  • Page 59: Visca Over Ip Using The Full Sony Visca Protocol

    VISCA over IP using the full Sony VISCA protocol All Avonic cameras are capable of being controlled using the UDP Sony version of VISCA consisting of long VISCA commands, including headers and message counters. The advantage of using this version of VISCA is the fact that the camera responds with the same header counter as was used in the command.

  • Page 60: Camera Return Commands

    = Camera Address + 8 • This is one list for all Avonic PTZ Cameras (CM40 series, CM70 and CM90 series). Some features are CM70 and/or CM90 series specific and will not work in the CM40 series cameras. Return/complete Command...

  • Page 61: Camera Control Commands

    Camera Control Commands All parameter values are in HEX x = Camera Address • y = Socket Number • z = Camera Address + 8 • Camera Control Commands Command Function Command Packet Comments Address Set Broadcast 88 30 01 FF Address setting CAM_Power 8x 01 04 00 02 FF...
  • Page 62 Camera Control Commands Command Function Command Packet Comments CAM_Bgain Reset 8x 01 04 04 00 FF Manual Control of BGain 8x 01 04 04 02 FF Down 8x 01 04 04 03 FF Direct 8x 01 04 44 00 00 0p 0q FF pq: B Gain CAM_Rgain Reset...
  • Page 63 Camera Control Commands Command Function Command Packet Comments CAM_BackLight 8x 01 04 33 02 FF Back Light Compensation On/Off 8x 01 04 33 03 FF CAM_NR(2D)Level (CM40 8x 01 04 53 0p FF p: NR Setting (0: Off, and CM70 series only) level 1 to 7, 8 = AUTO) CAM_NR(3D)Level 8x 01 04 54 0p FF...
  • Page 64 Camera Control Commands Command Function Command Packet Comments Pan_tiltDrive 8x 01 06 01 VV WW 03 01 FF VV: Pan speed 0x01(low speed) to 0x18 (high speed) Down 8x 01 06 01 VV WW 03 02 FF WW: Tilt speed 0x01(low speed) to 0x14 (high speed) Left 8x 01 06 01 VV WW 01 03 FF...
  • Page 65 Camera Control Commands Command Function Command Packet Comments CAM_AFZone Front Focus 8x 01 04 AA 00 FF AF Zone select Back Focus 8x 01 04 AA 01 FF Meeting 8x 01 04 AA 02 FF Moving Objects 8x 01 04 AA 03 FF Center Focus 8x 01 04 AA 04 FF CAM_ColorHue...
  • Page 66 Camera Control Commands Command Function Command Packet Comments CM90 Comments CM40/ CM70 VideoSystem_Set 8x 01 06 35 00 pp FF pp: Video Format (CM40 series: It is possible to set the video 00: 1080p60 format, but since the video format is dictated 01:1080p50 by the computer the camera is connected with, the picture will NOT change to that...

  • Page 67: Inquiry Commands

    Inquiry Commands all parameter values are in hex x = camera address • y = socket number • z = camera address + 8 • Inquiry Commands Command Function Command Packet Comments CAM_ZoomPosInq 8x 09 04 47 FF 90 50 0p 0q 0r 0s FF pqrs: Zoom Position CAM_FocusAFModeInq 8x 09 04 38 FF...
  • Page 68 Inquiry Commands Command Function Command Packet Comments CAM_Aperture-ModeInq 8x 09 04 05 FF 90 50 02 FF Auto Sharpness (Sharpness) 90 50 03 FF Manual Sharpness CAM_ApertureInq(Sharpness) 8x 09 04 42 FF 90 50 00 00 0p 0q FF pq: Aperture Gain CAM_PictureEffectModeInq 8x 09 04 63 FF 90 50 00 FF...
  • Page 69 Inquiry Commands Command Function Command Packet Comments Pan-tiltPosInq 8x 09 06 12 FF 90 50 0w 0w 0w 0w wwww: Pan Position 0z 0z 0z 0z FF zzzz: Tilt Position CAM_GainLimitInq 8x 09 04 2C FF 90 50 0q FF p: Gain Limit 8x 09 04 2C FF 90 50 07 FF...
  • Page 70 Inquiry Commands Command Function Command Packet Comments CAM_WBModeInq 8x 09 04 35 FF 90 50 00 FF Auto 90 50 01 FF Indoor mode 90 50 02 FF Outdoor mode 90 50 03 FF OnePush mode 90 50 05 FF Manual CAM_RGainInq 8x 09 04 43 FF...

  • Page 71: Appendix B - Dimensions

    APPENDIX B - DIMENSIONS...

  • Page 72: Appendix C - Http Api

    APPENDIX C - HTTP API With the HTTP API you can control the camera by using a web browser like Microsoft Edge or Google Chrome for example. It is possible to change multiple settings at once using this feature. This document is available as an Appendix in the CM70/ CM90 series manual and as a separate document that can be downloaded on the product website.

  • Page 73: Curl

    7. In case of a failed return, check the following: • Brackets in the code. Have you copy and paste the first and the last bracket? • Syntax errors in the code/ correct numbers in the key values. Some camera settings are having a specific range.

  • Page 74: Getenv

    {"GetEnv"} You can also use the HTTP API to display the current settings of the camera in your browser or in the Command Prompt application. To do this, you need the {"GetEnv"} codes from the HTTP API code list. If correct you get the following result: Web browser Command Prompt...

  • Page 75: Http Api Code List

    HTTP API code list IR Remote Control IR Enable/Disable Command Code Command Setting szCmd {"SetEnv":{"ArmPtz": bIrCtrlEnable 0: ON {"bIrCtrlEnable":0}}} 1: OFF PTZControl Code: http://192.168.5.126/ajaxcom?szCmd={"SysCtrl":{"PtzCtrl":{"nChanel":0,"szPtzCmd":"left_start","byValue":50}}} Command Setting Function Command nChanel byValue 0,100 used to control the speed of ptz szPtzCmd left start left_start left stop left_stop...
  • Page 76 Speed by Zoom Set Speed By Zoom Command Code Command Setting szCmd {"SetEnv":{"ArmPtz":{"bSpeedByZoom":0}}} bSpeedByZoom 1: on 0: off Image Freezing Set Image Freezing Command Code Command Setting szCmd {"SetEnv":{"ArmPtz":{"bImageFreezing":0}}} bImageFreezing 1: on 0: off Low power mode Set Low Power Mode Command Code Command...

  • Page 77: Audio

    Focus Mode Commands emAFMode 2: Auto 3: Manual 4 OnePush Zoom and focus Code {"SysCtrl":{"PtzCtrl":{"nChanel":0,"szPtzCmd":"zoomdec_start","byValue":0}}} Command Setting Function Command nChanel byValue szPtzCmd Zoom add start zoomadd_start Zoom add stop zoomadd_stop Zoom decrease stop zoomdec_start Zoom decrease stop zoomdec_stop Focus add start focusadd_start Focus add stop focusadd_stop...

  • Page 78: Video

    Audio Configure Encode {"SetEnv":{"Audio":{"nAEncType":7}}} nAEncType 6: Mp3AAC Type 7: G.711A Sample {"SetEnv":{"Audio": nSampleRate (Only 16000 Rate {"nSampleRate":32000}}} supporting these sample 32000 rates and gy11a can only 44100 be 8000.) 48000 Sample Bits {"SetEnv":{"Audio":{"nSampleBits":16}}} nSampleBits Bit Rate {"SetEnv":{"Audio":{"nBitRate":96}}} nBitRate Channel {"SetEnv":{"Audio":{"nChannel":2}}} nChannel 1: Mono 2: Stereo...
  • Page 79 Video Encode Settings Rate Control {"SetEnv":{"VideoEncode":[{"stMaster": emBitRateCtrl 0: CBR {"emBitRateCtrl":1},"nChannel":0}]}} 1: VBR Video Encode Settings Function Code Command Setting Image Quality {"SetEnv":{"VideoEncode":[{"stMaster": byImageQuality 0: worst quality {"byImageQuality":5},"nChannel":0}]}} 1: between 2: between 3: between 4: between 5: Best quality Bit Rate {"SetEnv":{"VideoEncode":[{"stMaster": dwMaxBitRate [64, 40960]...
  • Page 80 Stream Publish Stream Name {"SetEnv":{"StreamPublish":[{"stMaster": szStreamName user-defined {"wHostPort":19355,"nProtolType":3,"szStreamName":"live/1213"}, "nChannel":0}]}} User Name {"SetEnv":{"StreamPublish":[{"stMaster": szUserName user-defined {"wHostPort":19355,"nProtolType":3,"szUserName":"123"}, "nChannel":0}]}} {"SetEnv":{"StreamPublish":[{"stMaster": szPassword user-defined {"wHostPort":19355,"nProtolType":3,"szPassword":"123"}, "nChannel":0}]}} Password SrtKey (SRT Effectie) {"SetEnv":{"StreamPublish":[{"stMaster": szSrtKey user-defined {"wHostPort":19355,"nProtolType":3,"szSrtKey":"0123456789"}, "nChannel":0}]}} SrtKeyLen {"SetEnv":{"StreamPublish":[{"stMaster": wSrtKeyLen [0-32] (SRTEffectie) {"wHostPort":19355,"nProtolType":3,"wSrtKeyLen":"0"}, "nChannel":0}]}} (RTP) Multicast Streaming RTP Multicast Get rtp multicast parameters Code...
  • Page 81 Video Parameters Focus Mode {"SetEnv": emAFMode Auto {"VideoParam":[{"stAF": Manual {"emAFMode":2},"nChannel":0}]}} OnePush AF-Zone {"SetEnv": emAFZone Front Focus {"VideoParam":[{"stAF": Back Focus {"emAFZone":1},"nChannel":0}]}} Meeting Education Tracking Moving Objects Center Focus AF-Sensitivity {"SetEnv": nSensitivity High {"VideoParam":[{"stAF": Middle {"nSensitivity":1},"nChannel":0}]}} Exposure Camera Settings Exposure Mode {"SetEnv":{"VideoParam":[{"stExp":{"stExpMode": emExpMode Auto {"emExpMode":0}},...
  • Page 82 Camera Settings Iris {"SetEnv":{"VideoParam":[{"stExp":{"stIris": nIris [0, 12] {"nIris":12}},"nChannel":0}]}} {"SetEnv":{"VideoParam":[{"stExp": [0, 8] {"drc":8},"nChannel":0}]}} Exposure: SAE shutter {"SetEnv":{"VideoParam":[{"stExp":{"stShutter": nShutter [0, 16] {"nShutter":16}},"nChannel":0}]}} {"SetEnv":{"VideoParam":[{"stExp": [0, 8] {"drc":7},"nChannel":0}]}} Camera Settings Exposure: AEE Flicker {"SetEnv":{"VideoParam":[{"stExp": Antiflicker {"antiflicker":0},"nChannel":0}]}} 50HZ 60HZ G.Limit {"SetEnv":{"VideoParam":[{"stExp": gainLimit [0, 15] {"gainLimit":5},"nChannel":0}]}} Iris {"SetEnv":{"VideoParam":[{"stExp":{"stIris": nIris...
  • Page 83 Camera Settings {"SetEnv":{"VideoParam":[{"stColor": [0, 14] {"hue":14},"nChannel":0}]}} {"SetEnv":{"VideoParam":[{"stColor": awbsens Sensitivity {"awbsens":0},"nChannel":0}]}} Middle High Image Bright {"SetEnv":{"VideoParam":[{"stImg": luminance [0, 4] {"luminance":0},"nChannel":0}]}} Contrast {"SetEnv":{"VideoParam":[{"stImg": contrast [0, 14] {"contrast":0},"nChannel":0}]}} Sharpness {"SetEnv":{"VideoParam":[{"stImg": sharpness [0, 15] {"sharpness":1},"nChannel":0}]}} Gamma {"SetEnv":{"VideoParam":[{"stImg": gamma [0, 4] 0: Default 3: 0.55 {"gamma":0},"nChannel":0}]}} 1: 0.45 4: 0.63...
  • Page 84 Video OSD Video OSD Get video parameters Code {"GetEnv":{"VideoOsd":{"nChannel":-1}}} Set set video parameters Code {"SetEnv":{"VideoOsd":[{"stTime":{"bEnable":1,"nIndex":0,"nXPos":0,"szText":"","nYPos":10000, "stFtColor":{"byAlpha":128,"byRed":255,"byGreen":255,"byBlue":255},"stBkColor":{"byAlpha":0, "byRed":0,"byGreen":0,"byBlue":0}},"stTitle":{"bEnable":0,"nIndex":0,"nXPos":0,"szText":"", "nYPos":0,"stFtColor":{"byAlpha":128,"byRed":255,"byGreen":255,"byBlue":255},"stBkColor": {"byAlpha":0,"byRed":0,"byGreen":0,"byBlue":0}},"nChannel":0}]}} NOTE: All params can be saved by this command and also you can set one param alone. Function Code Command Setting Show Time {"SetEnv":{"VideoOsd":[{"stTime": bEnable...
  • Page 85 OSD Font Size Code {"GetEnv":{"TTFFontSize":{"nChannel":-1}}} Set video parameters Code {"SetEnv":{"TTFFontSize":{"nFontSize":[48,48],"bAutoSize":1}}} Function Code Command Setting bAutoSize 0: off,1: on nFontSize [8,200] Output Format (Video) Output Format Get video out parameters Code {"GetEnv":{"VideoOut":{"nChannel":-1}}} Set video out parameters Code {"SetEnv":{"VideoOut": {"nNetMode":2,"emVoutSdiFormat":10,"nHdmiMode":0,"nHdrMode":0,"emVoutHdmiFormat":10,"byFormaHdmiList": [50,52,49,47,51,48,10,20,9,8,21,7,4,22,3,6,23,5],"byFormaSdiList":[10,20,9,8,21,7,4,22,3,6,23,5]}}} Function Code Command Setting...

  • Page 86: Network

    (Video) Output Format 1080P25 Same as Hdmi 720P60 Same as Hdmi 720P59 Same as Hdmi 720P50 Same as Hdmi Get network SRT parameters Code {"GetEnv":{"NetWork":{"nChannel":-1}}} Set network SRT parameters Code {"SetEnv":{"NetWork":{"stSrt":{"wSrtLen":0,"wSrtPort":9000,"szSrtPin":"xxxxxxxxxx"}}}} Function Code Command Setting crypto key length in bytes wSrtLen [0-32] Port SRT...
  • Page 87 Command Setting Preferred DNS Server {"SetEnv":{"NetWork":{"stDns": {"szDns1":"8.8.8.8"}}}} Alternative DNS Server {"SetEnv":{"NetWork":{"stDns": {"szDns2":"8.8.8.8"}}}} Get NDI parameters Code "GetEnv":{"NetWork":{"nChannel":-1}}} Set NDI parameters Code {"SetEnv":{"NetWork":{"stNdi":{"szNdiName":"Avonic-82342","bNdiControlEnable":1,"bNdiEnable":1,"szNdiGroup":"public"}} Function code command setting Ndi Enable {"SetEnv":{"NetWork":{"stNdi":{"bNdiEnable":1}}}} bNdiEnable 0: off 1: on Ndi Control {"SetEnv":{"NetWork":{"stNdi":{"bNdiControlEnable":1}}}} bNdiControlEnable 0: off...

  • Page 88: System

    System System Configure Get sysattr parameters Code {"GetEnv":{"SysAttr":{"nChannel":-1}}} Set sysattr parameters Code {"SetEnv":{"SysAttr":{"nLanguage":0,"szDeviceID":"1","emVideoStandard":1,"szDevName":"testname"}}} Function Code Command Setting Device Name szDevName user-defined, cannot use white space Device ID szDeviceID cannot modify Language nLanguage 0: Simplified Chinese 2: English License License (CM70 series ONLY) Get License parameters Code :{"QueryState":{"QueryLicenseState":{}}}...
  • Page 89 SysTime Function Code Command Setting Zone {"SetEnv":{"SysTime":{"nZone":0}}} nZone [0, 32] 6: GMT+04:30 0: GMT 7: GMT+05:00 …… 1: GMT+01:00 13: GMT+08:00 …… 2: GMT+02:00 20: GMT-01:00 …… 3: GMT+03:00 31: GMT-11:00 4: GMT+03:30 32: GMT-12:00 5: GMT+04:00 SysTime Hour Type {"SetEnv":{"SysTime":{"nHourType":0}}} nHourType 0: 24 Hours...
  • Page 90 Update Code Get the return value and split it like this: szText.Format(“%d.%d.%d%d-%d-%d”, (stVersion.dwCamVersion >> 16) & 0xFF, (stVersion.dwCamVersion >> 8) & 0xFF, (stVersion.dwCamVersion 0xFF), (stVersion.dwCamDate >> 16) & 0xFFFF, (stVersion.dwCamDate >> 8) & 0xFF,(stVersion.dwCamDate & 0xFF)); Set update parameters Not supported update with API, you can do this through webpage. Default and Reboot Default Code...

  • Page 91: Appendix D - Cmos Sensor Characteristics

    APPENDIX D - CMOS SENSOR CHARACTERISTICS The following occurrences that may appear in images are specific to CMOS (Complementary Metal Oxide Semiconductor) image sensors. They do not indicate malfunctions. White Flecks Although the CMOS image sensors are produced with high-precision technologies, fine white flecks may be generated on the screen in rare cases.

  • Page 92: Appendix E - Datasheet (Specifications)

    CM93-IP-W • CM93-NDI-W H.264 Profiles base, main, high Main stream resolution 1920x1080/ 1280x720/ 3840x2160 CM93-NDI Only Main stream max framerate 60fps NDI standard ® Main stream bitrate 64 ~ 81920 Kbps Sub stream resolution 1920x1080/ 720x480/ 640x480/ 640x360/ 320x240...

  • Page 93: Index

    Index AAE Mode (Aperture Auto Exposure) 31, G.Limit (Gain Limit) 29, 48, 62, AF Mode Gamma AF Sensitivity 29, 49, 64, Gateway AF Tactics AF Version 39, 50, AF Zone 65, Audio 24, H264 20, 25, 27, Auto Exposure Mode H265 AWB Mode HDMI 15, 16, 16, 35, 44, 46, 50,...
  • Page 94 Password 18, 19, 38, 80, XLR 15, PELCO-D 40, PELCO-P 40, PoE 15, Port Zoom 43, Power Zoom Speed 41, 49, Preset 41, 44, 49, 65, 76, PTZ 20, 41, 44, 49, 64, Reboot 39, Reboot Schedule Reset IP configuration (IP Address, Gateway, DNS server) RG Tuning 32, 48, 55, 62, 65, RJ45 RS-232 15, 16, 17, 56,...
  • Page 95 Avonic 4K60 PTZ Camera with 30x Zoom CM93-NDI © January 2023 • Version 1.0 Exportweg 11a • 2645 ED Delfgauw • The Netherlands +31(0)15 7112 712 • info@avonic.com • www.avonic.com...
