Summary of Contents for Vivotek AM-21C
- Page 1 Mounting kit VIVOTEK fixed dome series User manual Using the mounting adapter AM- 21C and compatible accessories Rev. 1.1b IP surveillance lance...
- Page 2 Wall mount installation Below is a general sample procedure with a wall mount bracket: 1. Locate the position where you want to install the wall mount bracket and the camera. Drill holes in the wall to secure the bracket and to route the cables. Secure the bracket by hammering anchors into the wall and then tightening the screws through it.
- Page 3 5. Secure the connection with the included hex key. 6. Attach the mounting adapter to the pendant tube by turning it clockwise until snug. 7. Secure the connection with the included hex wrench. 8. For models using A-holes (see mounting hole diagram on page 8), attach your mounting plate to the mounting adapter above. •...
- Page 4 Corner mount installation Below is a general sample procedure with a corner mount bracket: 1. Combine the two brackets with the included nuts and washers. 2. Align the assembled brackets with the desired position. Align the screw holes in the brackets against the wall. Drill holes in the wall to secure the bracket and to route the cables. Hammer anchors on the wall.
- Page 5 Pole mount installation Here is a general sample procedure with a pole mount bracket: 1. Route power lines and other cables through the included cable gland, route them through conduit (purchased separately), and install the cable gland on the pole mount bracket.
