Wurth Elektronik Proteus-I User Manual
Family evaluation board for radio modules
Hide thumbs
Also See for Proteus-I:
- User manual (192 pages) ,
- Manual (33 pages) ,
- User manual (29 pages)
Related Manuals for Wurth Elektronik Proteus-I
Summary of Contents for Wurth Elektronik Proteus-I
- Page 1 SER MANUAL AMILY EVALUATION BOARD FOR -I, -II, RADIO MODULES ROTEUS -III, -III-SPI, S -I, T ETEBOS HYONE 2608011 24000, 2608011 24010, 26110110240 0, 26110110210 ERSION 14, 2022 EPTEMBER...
- Page 2 *************** MUST READ Check for firmware updates Before using the product make sure you use the most recent firmware version, data sheet and user manual. This is especially important for Wireless Connectivity products that were not purchased directly from Würth Elektronik eiSos. A firmware update on these respective products may be required.
- Page 3 WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual Revision history Manual Notes Date version version June 2022 • Initial version Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs...
- Page 4 Serial Peripheral Interface Serial Wire Debug Through-Hole Technology Universal Asynchronous Receiver Transmitter Universal Asynchronous UART allows communicating with the module of a Receiver Transmitter specific interface Universal Serial Bus Voltage Drain Drain Supply voltage Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs...
-
Page 5: Table Of Contents
3.3.6 SMA ........18 3.3.6.1 Proteus-I/-II ....... 18 3.3.6.2 Smart antenna . - Page 6 Miscellaneous ........46 Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022...
-
Page 7: Supported Radio Modules
- smart antenna configuration 2.4 GHz proprietary radio module - smart 2611011021000 Thyone-I antenna configuration Order code Product Name 2608049024001 Family Board Proteus-I 2608049024011 Family Board Proteus-II 2611149024001 Family Board Proteus-III 2611149024011 Family Board Proteus-III-SPI 2611149024021 Family Board Setebos-I... -
Page 8: Content Family Board Proteus-I
WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual Quantity Content 2608049024001 Family Board with Proteus-I integrated PCB antenna Table 2: Content Family Board Proteus-I Quantity Content 2608049024011 Family Board with Proteus-II integrated PCB antenna Table 3: Content Family Board Proteus-II... -
Page 9: Functional Description
In that way, a COM port can be detected and installed on the PC. In the device manager, the COM port name of the TTL-232R-3V3 FTDI cable can be found. A COM port shall appear for example: "COM12" in Windows systems or "/dev/ttyUSB0" in Linux systems. Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 10: Taking Into Operation - Host Controller
P1, P2 and P3 can be used to connect the module pins and host. The detailed module specific quick start instructions can be found in the corresponding radio module user manuals [5, 6, 7, 8, 9, 11]. Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 11: Development Board
2.54 mm UART or SPI pin header (3.3 V logic) 2.54 mm pin Reset LEDs header button Connector (VIN, GND) Alternate power supply (1.8 - 3.6 V) Figure 2: Block diagram Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 12: Additional Assembly
WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual 3.2 Additional assembly Figure 3: Additional assembly Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... - Page 13 CON1 External antenna connection 60312002114503 CON2 Debugging interface 2X10 61302021121 Table 8: Additional assembly components Holes with 2 mm diameter on all the four corners are available for spacer or standoff connections Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs...
-
Page 14: Connectors And Ports
WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual 3.3 Connectors and ports Figure 4: Connectors Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 15: P1: Module Communication Access Pins / Ttl-232R-3V3 Ftdi Cable Connector
WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual 3.3.1 P1: Module communication access pins / TTL-232R-3V3 FTDI cable connector 3.3.1.1 Proteus-I, Proteus-II nRF52832 Board connection Proteus-I,-II P0.04 Module pin 14 /RTS 5V0 (Board power supply) P0.03 Module pin 13 URXD P0.02... -
Page 16: Proteus-Iii, Proteus-Iii Spi, Setebos-I, Thyone-I
P1 pin header can also be used for direct host connection. In case of Setebos-I, the pin B1/RPS on pin header P1 is used to select the ® radio protocol (proprietary or Bluetooth LE 5.1). Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 17: P2: Power Supply / Current Measurement
For instance, a jumper can be set on P2 pin 6-7 providing V_IN access on the pin header P2 Pin 8,9,10. 3.3.3 P3: Module debug access pins Function Module connection P0.21 (Proteus-I, Proteus-II) RESET P0.18 (Proteus-III, Proteus-III-SPI, Setebos-I, Thyone-I) SWDIO... -
Page 18: P4: Module Gpio Access Pins
WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual 3.3.4 P4: Module GPIO access pins 3.3.4.1 Proteus-I, Proteus-II Board nRF52832 Proteus-I,-II connection P0.10 Module pin 8 MODE_1 P0.09 Module pin 9 BUSY Module pin P0.00 LED_1 Module pin P0.02 LED_2... -
Page 19: Proteus-Iii, Proteus-Iii-Spi, Setebos-I, Thyone-I
Table 14: Pin header P4 3.3.5 CON2: Debugging Interface-2x10 pin header Function CON2 nRF52840 SWDIO SWDIO SWCLK SWCLK P0.21 (Proteus-I, Proteus-II) P0.18 (Proteus-III, RESET Proteus-III-SPI, Setebos-I, Thyone-I) 4,6,8,10,12,14,16,18,20 2,3,5,11,13,17,19 Table 15: JTAG debugging interface Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022... -
Page 20: Sma
4 x GND Table 16: Pin header SMA 3.3.6.1 Proteus-I/-II For Proteus-I and Proteus-II modules the integrated antenna variant is assembled on the Family Board. For these radio modules, the use of the external antenna is not possible on the Family Board. -
Page 21: Capacitor Connection To Internal Antenna
WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual Figure 6: Capacitor connection to internal antenna Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 22: Jumpers
Family evaluation board user manual 3.4 Jumpers Figure 7: Jumpers Pins Function Default state P2 Pin (5-6) Current measurement P1 Pin (9-10) Setebos-I functions not set P2 Pin (3-4) Boot mode not set Table 17: Jumpers Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 23: Current Measurement
After boot up, the modules stays in the selected mode until a reboot is triggered. Function B1/ RPS (Radio Protocol Select) V_IN Table 19: Pin header P1 Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 24: Boot Mode
• For Thyone-I module (2611011021000), boot loader mode allows firmware update via UART. • For Setebos-I module (2611011024020), the boot loader of the Proteus-III is used. nRF52840 Function P0.02 BOOT Table 20: Pin header P2 Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 25: Reset Button
On IC level, the active low reset input is configured with a pull up resistor. The module provides a /RESET pin that is connected to this button, so that the module can be restarted properly. Please refer to the module specific manual for detailed information [8, 9, 11]. Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 26: Function Blocks
The development board can be powered by an external power supply through the pin header P2 Pin (1 to 3) GND, P2 Pin-6 (V_IN). If the module is powered, the Power LED lights up. Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022... -
Page 27: Uart / Usb
LED_2, respectively. If an LFXO is assembled to the EV board, the resistors R3 and R5 shall be assembled, therefore the LED1 and LED2 function is no longer available. Refer to the Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022... -
Page 28: Power Supply Option 4 And 5 Through Pin Header P2
3V_LDO Radio (Pin 6) module V_IN Current / multimeter (Pin 1,2,3) (Solder bridge) Power LED Figure 10: Power supply option 4 and 5 through pin header P2 figure 11 for necessary modification. Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 29: Lfxo Assembly
The load capacitance of LFXO is given by 9 + 10 10 = C, then whereas, 10 = = Load capacitance of LFXO crystal. = Input capacitance of Pad LED_1 (4 pF) Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... - Page 30 C9 and C10 results in 12 pF which was also tested on Family Board. Depending on parasitic capacitance of PCB, a capacitance of 12 pF may be a good starting value for C9 and C10. Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs...
-
Page 31: Programming Interface
3.6.7 LEDs 3.6.7.1 Proteus-I, Proteus-II, Proteus-III, Proteus-III-SPI, Thyone-I, Setebos-I For Proteus-I, Proteus-II, Proteus-III, Proteus-III-SPI, Thyone-I, Setebos-I radio modules, the resistors R6 and R7 are assembled and the resistors R1 and R2 are not assembled. Figure 12: LED resistor R6, R7 assembly Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022... -
Page 32: Schematic - Proteus-Iii, Proteus-Iii-Spi, Thyone-I, Setebos-I
WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual 3.7 Schematic - Proteus-III, Proteus-III-SPI, Thyone-I, Setebos-I Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 33: Schematic Sheet
WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual Figure 13: Schematic sheet Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 34: Schematic -Proteus-I, Proteus-Ii
WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual 3.8 Schematic -Proteus-I, Proteus-II Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... - Page 35 WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual Figure 14: Schematic sheet Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs...
-
Page 36: Layout
WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual 3.9 Layout no metal antenna NO METAL 12.5mm Figure 15: Assembly diagram Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 37: Top, Bottom & Internal Layers
WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual Figure 16: Top, bottom & internal layers Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 38: Bill Of Materials
WIRELESS CONNECTIVITY & SENSORS Family evaluation board user manual 3.10 Bill of materials Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... - Page 39 Thyone-I Würth Elektronik 2611011021000 n.m. n.m. n.m. 61001018221 8.5mm Würth Elektronik 61001018221 61001018221 8.5mm Würth Elektronik 61001018221 n.m. n.m. n.m. n.m. n.m. 10KR 1K5R 1K5R 430152043826 4.3mm Würth Elektronik 430152043826 n.m. n.m. Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs...
-
Page 40: Regulatory Compliance Information
Notwithstanding the above, Würth Elektronik eiSos makes no representations and warranties of any kind related to their accuracy, correctness, completeness and/or usability for customer applications. No responsibility is assumed for inaccuracies or incompleteness. Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 41: References
[3] FTDI driver installation guidelines. InstallGuides.htm . [4] hterm. Terminal programm. https://www.der-hammer.info/pages/terminal.html . https://www.we-online.de/katalog/de/ [5] Würth Elektronik. Proteus-I user manual. manual/2608011024000 . [6] Würth Elektronik. Proteus-II user manual. https://www.we-online.de/katalog/de/ manual/2608011024010 . [7] Würth Elektronik. Proteus-III-SPI user manual. https://www.we-online.de/katalog/de/ manual/2611011024010 . -
Page 42: Important Notes
Necessary information is available on request. In this case, the field sales engineer or the internal sales person in charge should be contacted who will be happy to support in this matter. Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 43: Product Improvements
6.8 General terms and conditions Unless otherwise agreed in individual contracts, all orders are subject to the current version of the "General Terms and Conditions of Würth Elektronik eiSos Group", last version available at www.we-online.com. Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 44: Legal Notice
7.4 Usage restriction Würth Elektronik eiSos GmbH & Co. KG products have been designed and developed for us- age in general electronic equipment only. This product is not authorized for use in equipment Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... - Page 45 By using Würth Elektronik eiSos GmbH & Co. KG products, the customer agrees to these terms and conditions. Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs...
-
Page 46: License Terms
Firmware are neither designed nor intended for use in areas such as military, aerospace, aviation, nuclear control, submarine, transportation (automotive control, train control, ship con- trol), transportation signal, disaster prevention, medical, public information network etc. You Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 47: Ownership
USED. INFORMATION PUBLISHED BY WÜRTH ELEKTRONIK EISOS REGARDING THIRD- PARTY PRODUCTS OR SERVICES DOES NOT CONSTITUTE A LICENSE FROM WÜRTH ELEKTRONIK EISOS TO USE SUCH PRODUCTS OR SERVICES OR A WARRANTY OR ENDORSEMENT THEREOF. Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... -
Page 48: Limitation Of Liability
By ordering a wireless connectivity product, you accept this license terms in all terms. Proteus-I,-II,-III,-III-SPI, Setebos-I, Thyone-I Version 1.0, September 2022 www.we-online.com/wcs... - Page 49 Order codes ........Content Family Board Proteus-I .
- Page 50 Contact Würth Elektronik eiSos GmbH & Co. KG Division Wireless Connectivity & Sensors Max-Eyth-Straße 1 74638 Waldenburg Germany Tel.: +49 651 99355-0 Fax.: +49 651 99355-69 www.we-online.com/wireless-connectivity...
