Wurth Elektronik PROTEUS-I User Manual

Evaluation board/kit for radio modules
Hide thumbs Also See for PROTEUS-I:

Advertisement

Quick Links

U
SER MANUAL
E
VALUATION BOARD
P
MODULES
ROTEUS
P
-II
ROTEUS
2608011024000 /
2608011124000 /
2608011024010 /
2608011124010
V
1.4
ERSION
O
17, 2024
CTOBER
/
KIT FOR RADIO
-I
AND

Advertisement

loading
Need help?

Need help?

Do you have a question about the PROTEUS-I and is the answer not in the manual?

Questions and answers

Summary of Contents for Wurth Elektronik PROTEUS-I

  • Page 1 SER MANUAL VALUATION BOARD KIT FOR RADIO MODULES ROTEUS ROTEUS 2608011024000 / 2608011124000 / 2608011024010 / 2608011124010 ERSION 17, 2024 CTOBER...
  • Page 2 *************** MUST READ Check for firmware updates Before using the product, make sure you use the most recent firmware version, data sheet, and user manual. This is especially important for Wireless Connectivity products that were not purchased directly from Würth Elektronik eiSos. A firmware update on these respective products may be required.
  • Page 3: Revision History

    November 2016 Initial version February 2019 New corporate design and structure Added chapter Regulatory compliance February 2019 information Added marketing name Proteus-I and March 2019 Proteus-II Added radiation characteristics in chapter 3.8 May 2023 New corporate design October 2024 Added chapters Marking and UART / USB Proteus-I and Proteus-II Version 1.4, October 2024...
  • Page 4 Low signal level Describes everything relating to the wireless Radio frequency transmission. Universal Universal Asynchronous Receiver Transmitter allows Asynchronous UART communicating with the module of a specific Receiver interface. Transmitter Supply voltage Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 5: Table Of Contents

    Exemption clause ........20 6 Important notes 7 Terms of Use for Würth Elektronik eiSos GmbH & Co. KG EV-Boards, evaluation kits and evaluation modules 8 Legal notice 9 License terms Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 6: Supported Radio Modules

    It can be connected to an USB port of a PC. For the connection to a micro controller system the development board is equipped with a multi-pin connector which is connected to all pins of the RF module. Jumpers allow the module Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 7: Taking Into Operation

    After the module is powered through the USB jack or an alternative power supply, the reset button should be pressed to ensure a clean start-up of the module. Please refer to the module user manual to get the detailed module specific quick start instruc- tions. Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 8: Development Board

    WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual 3 Development board 3.1 Block diagram Figure 2: Block diagram Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 9: Jumpers

    Figure 3: Jumpers, defaults Module Pin Function Jumper set (default) BOOT LED3 LED2 UART TX 9,10 UART RX 11,12 Wakeup Module Pin Function Jumper set (default) Connect BOOT pin to GND if set Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 10 WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual Function Jumper set (default) Power bridge CBUS Connections Jumper set (default) Reset Wake-up Boot Function Jumper set (default) Connect SWCLK to GND if set Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 11: Connectors And Pin Headers

    3.3 Connectors and pin headers Figure 4: Connectors Function Mini-USB connector for host connection and VCC bus supply Function P0.28 / AIN4 P0.04 / AIN2 P0.09 / NFC1 P0.10 / NFC2 VCC 3V Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 12 WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual Function VCC 3V VCC 5 V Function 1-20 2×10 JTAG/SWD Connector Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 13: Buttons

    3.4.2 Wake-up button Some modules use the wake-up button connected to their WAKE-UP pin to exit from sleep mode of the module. Please refer to the module specific manual for detailed information. Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 14: Function Blocks

    When a baud rate is configured in the FTDI chip, the prescaler is chosen that meets the closest baud rate. In that case, the real baud rate differs from the configured one, introducing a UART clock error, which may lead to UART communication issues. Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 15: Uart Direct

    Beware of IO level incompatibility. The host must obey the values stated in the module’s man- ual. Especially the IO level restrictions must be implemented by a host system (i.e. using a level shifter to use the allowed IO levels). Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 16: Lfxo Crystal

    Using standard firmware NFC is not supported. To enable use of the NFC a custom firmware is required and an antenna and antenna matching network needs to be connected to the corresponding pins. Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 17: Programming Interface

    Unplug and replug the USB connection of the device. Press the reset button on the EV-Board. P3 Pin SWD Function SWDIO SWCLK /RST 2, 3, 5, 7, 11, 13, 17, 19 n.c. 6, 8, 10, 12, 14, 16, 18, 20 Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 18: Schematic

    WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual 3.6 Schematic Figure 7: Circuit diagram Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 19: Layout

    WIRELESS CONNECTIVITY & SENSORS Evaluation board/kit user manual 3.7 Layout Figure 8: Assembly diagram Figure 9: Top & bottom Layer Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 20: Internal Antenna Radiation Characteristics

    Figure 10: Antenna characteristic from integrated antenna measured on official EV-Board Radiation characteristic shown is valid for the module on the EV-Board. It is important to be aware that size of groundplane and placement of module has influence on the radiation pattern. Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 21: Marking

    The currently installed firmware can be requested from the module using the cor- responding product specific command. The firmware version as well as the hardware version are restricted to show only major and minor version not the patch identifier. Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 22: Regulatory Compliance Information

    Notwithstanding the above, Würth Elektronik eiSos makes no representations and warranties of any kind related to their accuracy, correctness, completeness and/or usability for customer applications. No responsibility is assumed for inaccuracies or incompleteness. Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 23: Important Notes

    The EVB is provided in the "as is" state. WE disclaims all express and implied warranties, in particular those concerning the suitability for a certain purpose, the absence of defects or non-violation of third-party rights. The EVB is intended for experienced developers to develop Proteus-I and Proteus-II Version 1.4, October 2024...
  • Page 24 EVB may cause interference with radio communication. In this case, the costs incurred for necessary measures to remedy the interference are to be borne by the user. As the EVB is not a finished product, it may not comply with applicable regulatory, safety or certification standards that are normally as- Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 25: Legal Notice

    By using Würth Elektronik eiSos GmbH & Co. KG products, the customer agrees to these terms and conditions. Proteus-I and Proteus-II Version 1.4, October 2024...
  • Page 26: License Terms

    Applicable law to these license terms shall be the laws of the Federal Republic of Germany. Any dispute, claim or controversy arising out of or relating to these license terms shall be resolved and finally settled by the court competent for the location of Würth Elektronik eiSos registered Proteus-I and Proteus-II Version 1.4, October 2024...
  • Page 27 We recommend you to be updated about the status of new firmware and software, which is available on our website or in our data sheet and manual, and to implement new software in your device where appropriate. By ordering a product, you accept these license terms in all terms. Proteus-I and Proteus-II Version 1.4, October 2024 www.we-online.com/wcs...
  • Page 28 Lot number details ........19 Proteus-I and Proteus-II Version 1.4, October 2024...
  • Page 29 Contact Würth Elektronik eiSos GmbH & Co. KG Division Wireless Connectivity & Sensors Max-Eyth-Straße 1 74638 Waldenburg Germany Tel.: +49 651 99355-0 Fax.: +49 651 99355-69 www.we-online.com/wireless-connectivity...
