14.2.2 Resistance Measurements

Table 9: DC resistance accuracies with 50V/7.5A DC power supply
I
test
5.0 - 7.5A
1.0 – 5.0A
0.5 – 1.0A
0.1 - 0.5A
25 - 100mA
< 25mA
< 25mA
Table 10: DC resistance accuracies with 12V/30A DC power supply
I
test
25.0 – 30.0A
20.0 – 25.0A
20.0 – 25.0A
15.0 – 20.0A
10.0 – 15.0A
5.0 – 10.0A
1.0 – 5.0A
0.5 – 1.0A
0.1 - 0.5A
50 - 100mA
< 50mA
< 50mA

14.2.3 Temperature Measurement

Range
0 – 70°C
90297-0.22 Instruction Manual mini-ATOS
Range
0.00µΩ ... 10Ω
0.00µΩ ... 50Ω
0.00µΩ ... 100Ω
0.00µΩ ... 500Ω
0.00µΩ ... 2kΩ
2kΩ ... 10kΩ
10kΩ ... 100kΩ
Range
0.00µΩ ... 0.48Ω
200µΩ ... 0.60Ω
0.00µΩ ... 200µΩ
0.00µΩ ... 0.80Ω
0.00µΩ ... 1.2Ω
0.00µΩ ... 2.4Ω
0.00µΩ ... 12Ω
0.00µΩ ... 24Ω
0.00µΩ ... 120Ω
0.00µΩ ... 240Ω
240Ω ... 1kΩ
1kΩ ... 10kΩ
Table 11: Output voltage accuracy
Accuracy
±0.2°C ± 1 LSD
Accuracy
±0.10% Rdg ± 1.6µΩ
±0.10% Rdg ± 8.0µΩ
±0.10% Rdg ± 16µΩ
±0.10% Rdg ± 80µΩ
±0.10% Rdg ± 320mΩ
±0.10% Rdg ± 50Ω
±1% Rdg ± 500Ω
Accuracy
±0.10% Rdg ± 0.4µΩ
±0.10% Rdg ± 0.1µΩ
±0.10% Rdg ± 0.3µΩ
±0.10% Rdg ± 0.6µΩ
±0.10% Rdg ± 0.8µΩ
±0.10% Rdg ± 1.6µΩ
±0.10% Rdg ± 8.0µΩ
±0.10% Rdg ± 16µΩ
±0.10% Rdg ± 80µΩ
±0.10% Rdg ± 1.2Ω
±0.10% Rdg ± 5Ω
±1% Rdg ± 50Ω
Resolution
5 Digits or 0.01µΩ
5 Digits
5 Digits
5 Digits
5 Digits
5 Digits
5 Digits
Resolution
5 Digits or 0.01µΩ
5 Digits
5 Digits
5 Digits
5 Digits
5 Digits
5 Digits
5 Digits
5 Digits
5 Digits
5 Digits
5 Digits
Resolution
0.1°C
