1. Confirm 110V outlet cord and CO2 tubing will reach target install area,
which is as close as possible to swimming pool on the return lines.
2. Plug in electrical timer or Ecosmarte Programmable Controller.
3. Select are and measure 7", mark pipe.
4. Cut PVC and clean pool pipe ends & chamber fittings.
5. Using PVC glue, install chamber fittings to the pool pipe ends. Let dry,
then screw the chamber onto the fittings.
6. Screw flow regulator into CO2 cylinder, and connect 1/2" pressure hose
from regulator to the solenoid. NOTE: CO2 cylinder must be standing up.
7. With solenoid "OFF," open valve on CO2 tank slowly until open all the way.
Then turn 1/4 turn back. Test all fittings between tank and solenoid for
leads using soapy water. Tighten any loose fittings.
8. Start using 30 minutes per day on pools, 3 minutes on spas. Modify as test
results dictate with twice weekly testing.
• Manual: 110V, 60 Hz
• Programmable: 12V
• CE, UL Listed Solenoid
• Power Cord
• Maximum tank PSI: 3000
• Maximum operating PSI: 60
• CGA 320 valves, tanks, fittings
• Indoor installations require
vented rooms
• Northern units should avoid
freezing; 5lb cylinders fit inside
the cabinet
• Direct sunlight above 120 de-
grees fahrenheit on Southern
units should be avoided
10
CO2 Swimming Pool Installation Guide
Specifications
ELECTRICAL
PLUMBING
CO2
CO2 Assembly Components
